CTM MARINE
CHILLED WATER SYSTEMS
CW MODELS
(24,000 / 36,000 / 48,000 / 60,000 / 72,000 BTU)
AIR HANDLER MODELS
(6,000 / 8,000 / 12,000 / 16,000 / 24,000 BTU)
INSTALLATION & USER MANUAL
CTM-MARINE
info@ctm-marine.com
www.ctm-marine.com
Please visit http://ctm-marine.com/user-manual/
Form No. UM-CW1001123
for the most updated version of this manual.
