ALTA POWERWAND Quick Programming Manual

Honeycomb shades, dual shades, roller shades, window shadings
Hide thumbs Also See for POWERWAND:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

QUICK PROGRAMMING GUIDE
Important: Before starting the programing, install the shade following the installation instructions provided.
For Honeycomb Shades, connect the battery cable into the slot located in the endcap, inside the headrail, before hanging the shades on the brackets.
1a. Attach the Wand
1
On Dual Shades, Roller Shades and Window Shadings, with the wand control
buttons facing you, attached the top of the wand on the metal hook support
(1) on the motor control side, then connect the cable into the motor head (2).
Roller and Honeycomb Mode:
• Press the DOWN or UP button to lower or raise the shade. Press the STOP to stop the shade at the desired position.
Window Shadings and Dual Shades Mode:
• Tapping the UP or DOWN button for less than 2 seconds will move the shade in short steps.
• Holding the UP or DOWN button down for more than 2 seconds before releasing will operate the shade at the standard speed.
• Press the STOP button to stop the shade at the desired position.
2
Front of wand
Honeycomb Shades | Dual Shades | Roller Shades | Window Shadings
1b. Attach the Wand — Honeycomb Shades
On Honeycomb shades, the wand will be already connected to the shade (1).
With the wand control buttons facing you, attached the top of the wand into
the plastic hook support on the motor control side (2).
2. Operate the Wand
UP
STOP
DOWN
LED
MICRO USB
CHARGING PORT
Back of wand
POWERWAND™
1
2
PROGRAMMING
BUTTON
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERWAND and is the answer not in the manual?

Questions and answers

Related Manuals for ALTA POWERWAND

Summary of Contents for ALTA POWERWAND

  • Page 1 POWERWAND™ QUICK PROGRAMMING GUIDE Honeycomb Shades | Dual Shades | Roller Shades | Window Shadings Important: Before starting the programing, install the shade following the installation instructions provided. For Honeycomb Shades, connect the battery cable into the slot located in the endcap, inside the headrail, before hanging the shades on the brackets.

  • Page 2: Quick Programming Guide

    QUICK PROGRAMMING GUIDE 3. Set a Favorite Position Press and Press and Release Release the PROG the PROG Move the button button Jog x1 Jog x1 shade to the desired position IMPORTANT: Once the favorite position is set, the shade will always stop at the designed favorite position when passing by it. 4.
  • Page 3 QUICK PROGRAMMING GUIDE Factory Motor Reset Press and Hold the PROG button for 7 seconds Press and Hold Jog x1 Jog x2 the STOP button for 5 seconds IMPORTANT: All limits will be erased. The motor direction will return to default and may need to be adjusted. Reverse UP and DOWN Commands (Only if necessary) Press and Hold Press and Release...

  • Page 4: Troubleshooting

    QUICK PROGRAMMING GUIDE 6. Charge the Battery When the shade begins to operate slower than normal or only beeps when you attempt to operate, it is time to charge the battery. To Charge, connect a standard micro USB cable into the bottom of the wand (A) and into USB 5V/2A (max) power supply. A red LED on the wand indicates that the battery is charging.
  • Page 5 POWERWAND GUIDE DE PROGRAMMATION RAPIDE Stores alvéoles | Stores doubles | Stores à enrouleur | Stores translucides Important : avant de commencer la programmation, installez le store en suivant les instructions d’installation fournies. Pour les stores alvéolés, connectez le câble de la batterie dans la fente située sur le capuchon d’extrémité, à l’intérieur de la traverse supérieure, avant de suspendre les stores sur les supports.

  • Page 6: Programmation Avancée

    GUIDE DE PROGRAMMATION RAPIDE 3. Régler une position préférée Appuyez Appuyez et relâchez et relâchez le bouton le bouton PROG PROG Déplacez le Secoue x1 Secoue x1 store dans la position désirée IMPORTANT : Une fois la position préférée soit définie, le store s’arrêtera toujours à la position préférée conçue lorsqu’il passera devant elle. 4.
  • Page 7 GUIDE DE PROGRAMMATION RAPIDE Rétablir le moteur au mode d’usine Appuyez et maintenez le bouton PROG pendant 7 secondes Appuyez et Secoue x1 Secoue x2 maintenez le bouton ARRÊT pendant 5 secondes IMPORTANT : Toutes les limites seront effacées. La direction du moteur reviendra au défaut et devra peut-être être ajustée. Inverser les commandes HAUT et BAS (seulement si nécessaire) Appuyez et Appuyez et...

  • Page 8: Dépannage

    GUIDE DE PROGRAMMATION RAPIDE 6. Rechargez la batterie Pour recharger, connectez un câble micro USB standard au bas de la baguette (A) et à une alimentation USB 5V/2A (max). Une LED rouge sur la baguette indique que la batterie est en cours de chargement. Pour charger complètement les batteries, laissez-les se charger pendant au moins une heure après que la LED sur la baguette soit devenue verte.
