Blu WATER WONDERS Moonshadow Instructions For Use Manual

Hide thumbs

IMPORTANT – RETAIN FOR FUTURE REFERENCE – READ CAREFULLY

Please check the contents of the boxes before attempting to assemble this product. A full checklist of parts

is in this instruction booklet. Check it very carefully. In the unlikely event that any components are

damaged or missing, please contact our customer service hotline at 407‐426‐7674.

This product contains small items and plastic bags. Please be aware of the danger to young children.

No tools necessary for assembly.

635 W. Michigan Street Orlando, FL 32805 ∙ PH 407‐426‐7674 ∙ Fax 407‐426‐7721

Moonshadow

Instruction for Use

www.bluworldusa.com ∙ http://shop.bluworldusa.com

Table of Contents

Need help?

Do you have a question about the WATER WONDERS Moonshadow and is the answer not in the manual?

Questions and answers

Summary of Contents for Blu WATER WONDERS Moonshadow

Page 1 IMPORTANT – RETAIN FOR FUTURE REFERENCE – READ CAREFULLY Please check the contents of the boxes before attempting to assemble this product. A full checklist of parts is in this instruction booklet. Check it very carefully. In the unlikely event that any components are damaged or missing, please contact our customer service hotline at 407‐426‐7674. This product contains small items and plastic bags. Please be aware of the danger to young children. No tools necessary for assembly. Moonshadow Instruction for Use 635 W. Michigan Street Orlando, FL 32805 ∙ PH 407‐426‐7674 ∙ Fax 407‐426‐7721 www.bluworldusa.com ∙ http://shop.bluworldusa.com ...
Page 2 Identification of Components Carefully identify and count all components as shown below. Photos may vary slightly from what you receive. A. Water Disperser B. Pump C. Bowl (Model may vary) E. Rock Tray D. Ring F. Velcro Strips (LED light assembled) G. Rocks H. Slate and Support Strap I. Hose NOTES ON POSITIONING YOUR FOUNTAIN a. Try to position your fountain near an electrical outlet. If being placed outdoors, please use a Ground Fault Circuit Interrupter (GFCI) Outlet. ...
Page 3 Step 3 Remove the screw from the Water Disperser (A). Align the holes in the disperser and elbow then insert the screw and tighten to ensure the Water Disperser (A) doesn’t move. Insert the hose into the other end of the elbow, with the black adapter pointing out. As shown in Fig. 4.A – 4.B. Fig 4. A Fig 4. B Step 4 Locate Pump (B) and make sure that it is set to its highest flow setting. Connect the Pump (B) to the Hose (I). Wrap the LED light (B) power wire around the pump. Place the assembled unit into the center of the Bowl (C). Put the Ring (D) into the center of the Bowl (C). As shown in Fig. 5. A‐ 5.B. Fig 5. B Fig 5. A Step 5 Connect the LED light (E) to the Pump (B). Lay the Rock Tray (E) on the top of the Ring (D). Make sure that the wire from the Pump (B) is placed through the notch in the support Ring (D) and continues outside the Bowl (C) so that the Transformer (B) is not in the Bowl (C). As shown in Fig. 6. A‐ 6.B. ...
Page 4 can react differently with each piece of slate. If you follow these instructions you will be able to make adjustments to your fountain so that it flows properly. Note that one side of the Slate(H) is flat and the other side has a chipped edge. The side with the chipped edge will have a better appearance as the “front” where you will want your main water flow. Position the Slate (H) in the middle of the Water Disperser (A), as shown in the picture to the right, so it lines up over the center of the Rock Dish (E). Step 8 Place the fountain where you wish to display it and fill with water (distilled or purified is recommended) to a level ¼” below the Rock Dish (E). Plug in your pump and observe the water flow. There may be an initial surge and slight splashing so it is a good idea to have a small towel available for this set up to wipe up any splashing. You will find that if you slightly rotate the slate so it catches the water flow from the Water Disperser (A) back and forth or side to side it will find the right position to operate smoothly and without any splashing as shown below. ...
Page 5 Maintenance Check your fountain regularly for the need to add water. Depending on humidity and temperature, water will evaporate at different rates; some people may need to check their fountains daily. Waterfalls that are placed near air conditioning vents and intakes will evaporate at a faster rate.
Page 6 Warranty Bluworld product is warranted against defects that render it unfit for its reasonably intended use. This Warranty is not extended to cover use of the product for a purpose other than as intended, and if the product is used unreasonably, or for purposes other than as intended, or if it is altered, modified or repaired by a party other than Bluworld, then the Warranty shall be null and void.
