Video Wall Station
User Manual
2.0.7
Information in this document is subject to change without notice.
© Copyright 2021. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VD Series and is the answer not in the manual?

Questions and answers

Related Manuals for Digiever VD Series

Summary of Contents for Digiever VD Series

  • Page 1 Video Wall Station User Manual 2.0.7 Information in this document is subject to change without notice. © Copyright 2021. All rights reserved.

  • Page 2: Table Of Contents

    Table of Contents Chapter 1. Introduction ................4 Hardware Description ................5 1.1.1 VD Series ..................5 1.1.2 VD UHD Series.................. 6 1.1.3 VD UHD+ Series ................7 LED Indicators Status ................8 1.2.1 VD Series ..................8 1.2.2 VD UHD Series.................. 9 1.2.3...
  • Page 3 Log in Station ..................48 1.1.1 Anonymous login ................49 1.1.2 Virtual Keyboard ................50 Liveview ....................51 3.2.1 Select View Modes on Liveview Page ........... 51 3.2.2 Main Functions for Live View ............52 3.2.3 Right Click Functions on Video Window ........62 3.2.4 Zooming with Mouse Scroll ............
  • Page 4 4.4.4 Date &Time ..................96 4.4.5 Reboot &Shutdown ................ 99 Chapter 5. Remote Controller (optional) ..........100 Overview ..................100 Connect to Video Wall Station ............ 101 Instruction of Liveview Interface (Side A) ........102 Instruction of Mouse and Keyboard (Side B) ......103 Chapter 6.

  • Page 5: Introduction

    Chapter 1. Introduction Before You Use This Product When you first open the product’s package, verify that all the accessories listed on the “Package Contents” of “Quick Installation Guide” are included. Before installing the video wall station, please read the instructions in the “Quick Installation Guide” to avoid misuse.

  • Page 6: Hardware Description

    1.1 Hardware Description 1.1.1 VD Series VD-0025 / VD-0036/ VD0049/ VD-0064 Figure1. Front & Rear View of VD Series Power button USB 2.0 x 2 Audio output (reserved) Audio mic input (reserved) USB 2.0 x 2 Gigabit LAN x 1...

  • Page 7: Vd Uhd Series

    1.1.2 VD UHD Series VD-0025 UHD/ VD-0036 UHD/ VD-0049 UHD/ VD-0064 UHD Figure2. Front & Rear View of VD UHD Series 1. Power button 2. USB 3.0 3. USB 3.0 Type C Port (reserve) 4. HDMI 1.4 x 1 5. HDMI 2.0 x 1 6.

  • Page 8: Vd Uhd+ Series

    1.1.3 VD UHD+ Series VD-0025 UHD+ / VD-0036 UHD+ Figure3. Front & Rear View of VD UHD+ Series 1. Power button 2. Power LED Indicator 3. USB 3.2 4. USB 3.2 x 2 5. HDMI 2.0 x 1 6. HDMI 2.0 x 1 7.

  • Page 9: Led Indicators Status

    1.2 LED Indicators Status 1.2.1 VD Series VD-0025/ VD-0036/ VD-0049/ VD-0064 Figure1. VD Series Front Panel Note: **To turn off your video wall station, long pressing power button at least 2 seconds. **To turn on your video wall station, long pressing power button at least 3 seconds.

  • Page 10: Vd Uhd Series

    1.2.2 VD UHD Series Figure2. VD UHD Series Front Panel LED on Front Panel LED Color & Status Indicate Power Off Power Blue Power On LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow...

  • Page 11: Vd Uhd+ Series

    1.2.3 VD UHD+ Series Figure3. VD UHD+ Series Front Panel LED on Front Panel LED Color & Status Indicate Power Off Power Blue Power On LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow...

  • Page 12: Dual Display Solution

    1.3 Dual Display Solution 1.3.1 VD Series VD-0000 series provides HDMI and DVI-I port for local display. Users can connect both of HDMI and DVI-I at the same time for video output. Scenario A: If both monitors are Full HD(1920x1080),those will be shown as Full HD.

  • Page 13: Vd Uhd / Uhd+ Series

    1.3.2 VD UHD / UHD+ Series VD-0000 UHD / UHD+ series provides 2 HDMI ports for local display. On Full HD display, users can connect two HDMI video outputs at the same time. Scenario A: If both monitors are Full HD (1920x1080), those will be shown as Full HD. Scenario B: If both monitors are XGA (1024x768), those will be shown all as XGA.

  • Page 14: Video Wall Station Installation

    Chapter 2. Video Wall Station Installation 2.1 Remote Browser PC System Requirements The following information is the minimum required specification for remote Windows PC, which users can open a remote browser from the PC to access Video Wall Station on the network. ...

  • Page 15: Connect To Video Wall Station

    2.2 Connect to Video Wall Station To begin, please insert the product CD-ROM in a PC to access the Quick Guide, User Manual and install the utilities. As user runs the product CD, the following menu is displayed. 2.2.1 Quick Guide Click “Quick Guide”...
  • Page 16 Click “Next” to continue installation. Read the license agreement and click “I accept the terms of the license agreement”. Click “Next” to continue installation. Select a location of destination and select a folder where the setup can install files. The default location is: C:\Program Files (x86)\NVR\EZ Search. Users can also install EZ Search in other folder by clicking “Change”...
  • Page 17 Once a folder is selected, please click “OK” to continue installation. The window shows that the Install Shield Wizard is installing video wall station Search. Please wait until the Wizard completes the installation.
  • Page 18 The InstallShield has successfully installed EZ Search. Select “Create Desktop Shortcut”/ “Create Quick Launch Shortcut”/ “Create Start Menu Shortcut” and please click “Next” to continue. The installation is complete. Please click “Launch application when done installing” to execute video wall station Search. After finishing the setup, the window of video wall station Search will pop up.
  • Page 19 Users can click “Search” to search device. Introduction of Video Wall Station Search EZ search provides three kinds of toolbars for users: File You can click “Exit” to leave EZ search and close the window.
  • Page 20 2. Setting Configure UPnP and Network by clicking “Setting” in the top left or in the middle right. Note: Users will be prompted to enter the login information of Station before being allowed to change the setting. When accessing the video wall station setting, users will be prompted to enter username and password.
  • Page 21 1) UPnP Universal Plug and Play (UPnP) simplifies the process of adding a video wall station to a local area network. Once connected to a LAN, Video wall station will automatically appear on the internet. You can rename UPnP Name on the video wall station.
  • Page 22 2) Network Two models are provided for setting the network: DHCP and Static IP. 3. Option Option provides several languages Once you click “Connect” or double click the selected video wall station list, IE browser will pop up automatically for the web-based interface.

  • Page 23: Install Upgrade Tool

    2.2.3 Install Upgrade Tool Click “Upgrade Tool” to upgrade several NVR to the latest firmware version. Please follow the instructions to install and Upgrade Tool will run automatically. When installing Upgrade Tool, Shield Wizard window for Upgrade Tool will pop up. Click “Next”...
  • Page 24 Read the license agreement and click “I accept the terms of the license agreement”. Click “Next” to continue installation. The window shows that the InstallShield Wizard is installing Upgrade Tool. Please wait until the Wizard completes the installation.
  • Page 25 The installation is completed. Please click “Launch application when done installing” to execute Upgrade Tool. And click “Finish”. After finishing the setup, the window of NVR Search will pop up. Upgrade Tool shows No., Device Name, Model Name, IP Address, Current Firmware and Password of the connected devices.
  • Page 26 devices. (Please use administers’ password.) If the device password is NOT the default password, user can manually enter the password in the password bar and then press “Enter” on the keyboard. After typing the correct password, the password bar will show “Successful” and current firmware will show automatically.
  • Page 27 If the password is not correct, the password bar will show “Failed”. Select the devices at the left column to upgrade firmware. Users can click “Select All” or “Cancel All” button to select or cancel all the devices.
  • Page 28 Click “Browse” to upload firmware file to upgrade the devices. A window will pop up to ask for the folder to upload the firmware. Select the file and click “Open”.
  • Page 29 After selecting the file, firmware file path will show. Please click “Upgrade” button. A window will pop up to make sure the execution . Please click “Yes” button. The window will show the upgrade process of each device.
  • Page 30 After upgrading successfully, the progress column will show “Successful”. After upgrade successfully, user can double click the device to log in NVR.

  • Page 31: User Manual

    If the upgrading is not successful, the progress column will show the message. 2.2.4 User Manual Click “User Manual” to open the folder and double-click on user manual file to read. 2.2.5 Browse CD Click “Browse CD” to open the folder of current Autorun.exe file.
  • Page 32 2.2.6 Connect to Video Wall Station 1. Connect to video wall station After setting the EZ Search users can connect to the web-based interface by the following two options: EZ Search or IE browser 1) EZ Search Once you click “Connect” or double click the selected video wall station list, the IE browser will pop up automatically.

  • Page 33: Quick Configuration

    Quick Configuration After users log in system, the system will direct you to set Quick Configuration in four main steps. Follow the instructions of the Overview of wizard to complete system setup. 2.3.1 Start System will lead you to “Start” from the drop-down menu of Configuration Utility to begin.
  • Page 34 Users need to adjust the settings in the Network Setup page in order to let system work properly within network.  There are 2 methods to configure IP address 1. Obtain an IP address automatically (Default) Obtain an available dynamic IP address assigned by a DHCP server. If this option is selected, system will automatically obtain an available dynamic IP address from the DHCP server once it connects to the network.

  • Page 35: Server Settings

    2. Specify an IP address. If there is no DHCP server existing in network environments, the static IP address will be given as192.168.1.245. It should be adaptable in most networking environment, and user can choose to maintain the default IP ddd address or change it in this page.

  • Page 36: Date &Time

    Password Settings Each station comes with a built-in “admin” account with password “admin.” It’s highly recommended to change the password upon the initial login. Enter a new password in the “New Password” field and enter it again in “Retype Password.” Since you confirm “Next,”...

  • Page 37: Camera Settings

    Configure the time and date by verifying and adjusting current local time and daylight saving to avoid the following errors:  Inconsistent display time of event logs and when they actually occur. Please enter the hostname of a valid NTP server to synchronize the server time with an Internet time server.
  • Page 38 Detect: User can enter NVR or camera’s IP Address, username and password. Then, click “Apply” button to start adding device. After clicking “Apply” button, vender, username and password will be automatically filled in by vendor’s default information. Note: By enabling RTSP port, users can edit camera’s RTSP port number, especially when camera is set in the WAN.
  • Page 39 User can add cameras through NVR or directly add camera to station: (1) Add cameras through NVR After applying correct NVR information, user will be directed to “Add all” page. By clicking “Delete” button, user can delete the camera that you do not want to add to station.
  • Page 40 Note: Camera Name, Username and Password are editable. After clicking “Apply” button, vender, username and password will be automatically filled in by vendor’s default information. UPnP Search/ONVIF Search: Click “UPnP Search” to find out UPnP devices within the LAN. Please make sure IP camera supports UPnP Search function. Please go to IP Camera web page to enable UPnP search function.
  • Page 41 Click the camera that you would like to add to station, then click “Add” button. Note: Users can click “All” to add cameras in Added column. User can add cameras through NVR or directly add camera to station: (1) Add cameras through NVR When selecting a NVR to add to station, a window will pop out to ask NVR password.
  • Page 42 Please click “Add All” button to start adding cameras. (2) Directly add cameras to station If user directly adds camera in station, please check camera information in Group add page. Then, Click “Add All” button to start adding cameras Note: Station will automatically fill in default username and password of each vendor.
  • Page 43 Note: ONVIF port may differ from HTTP port, which may cause the camera fail to add to station. You may click “Cancel” button to stop camera adding progress. Status column in camera list will display “Successful” when cameras are successfully added in the station.
  • Page 44 list that is successfully added in the station. If there is any error occurred in entering the following information, the notification window will pop up as below. When an inappropriate address is entered, a window will pop up as below. When an inappropriate user name is entered, a window will pop up as below.
  • Page 45 The Description of Camera Settings: (1) Memorize modified username and password: Station can memorize username and password which is modified by users after users click “Apply” button. Then, the default username and password of that vendor will be replaced by the modified one. Next time when users add new camera of the specific vendor, username and password will be automatically filled in by new modified one.
  • Page 46 Note: It is highly recommend to use “Optimization by Station” to perform the best surveillance quality in both live-view. Note: Station supports settings from camera to below camera brands for now: Brickcom, Canon, Linksys, AXIS(5.00 or below version), VIVOTEK, Messoa, iCantek, Panasonic, PROBE, Samsung, SECUBEST, Provision ISR (3) Multi-channel Video Server Station supports multi-channel video server to connect analog cameras to...
  • Page 47 Follow by entering the Generic URL column with proper RTSP or MJPEG URLs. If Generic RTSP is selected, RTSP port should be filled out too. Click “Apply” button to save setting. The most correct URLs should be provided from each camera vendors. Users may also refer to websites https://www.soleratec.com/rtsp/ http://www.ispyconnect.com/sources.aspx...

  • Page 48: Finish

    A window will pop up to ensure the action. To delete the camera, click “OK” to proceed. The camera has been deleted from camera list. 2.3.6 Finish Please select “Finish” from the drop-down menu of Configuration Utility to begin. Once 4 steps of Quick Configuration are completed, the window will show the completed status.

  • Page 49: Use Video Wall Station By Local Display

    3.1 Log in Station Users have to key in the correct username and password to login station. VD series supports two resolutions: 1920 x1080 and 1024x768. VD UHD series supports three resolutions: 3840 x 2160, 1920 x1080 and 1024x768. Note: If station detects that the monitor does not support 1920x1080 resolution, the resolution option in login page will show 1920x1080(*).

  • Page 50: Anonymous Login

    1.1.1 Anonymous login Anonymous login allows users to login without username and password. Anonymous user can only view live monitoring on local monitor, however, the configuration page will be disable. While anonymous login is applied, system will automatically log in without authorization process after boot up. Start to setup the anonymous login A.

  • Page 51: Virtual Keyboard

    1.1.2 Virtual Keyboard Users can choose to use USB keyboard for typing on local display, or fill out columns with virtual keyboard. The virtual keyboard in local display can be enabled from the right side of each column. There are 3 types of virtual keyboard can be chosen, including Upper case, Lower case and Symbols.

  • Page 52: Liveview

    3.2 Liveview After the Quick Configuration is complete, users can successfully monitor IP cameras. In liveview page, users can monitor cameras in various display modes and control PTZ cameras. 3.2.1 Select View Modes on Liveview Page On top right of live view, users can select four view modes. Mode Description Liveview:...

  • Page 53: Main Functions For Live View

    3.2.2 Main Functions for Live View Camera status Icon Icon Color & Status Indicate White word with black background Camera name at the top left corner Yellow triangle with an Event is triggered exclamation mark Gray speaker Support Audio Green speaker Audio on (channel is selected) Gray microphone Support microphone...
  • Page 54 System information (1) Firmware version User can easily find out the firmware version in the live view page. (2) System loading indicator: Users can find out system loading directly without entering configuration page. System loading indicator shows blue when loading is 70% or under, and shows red as a warning when it reach to more than 70%.
  • Page 55 Display mode Station supports multi-display modes for monitoring. Click the icon of display mode to monitor liveview. When you click a display mode, the mode icons will turn into blue. Icon Description 1 screen 4 screen 9 screen 12 screen 16 screen 20 screen 2(1x2/2x1)/3/5/6/25/30/32/36/42/49/56/64 screen...
  • Page 56 PTZ Control Panel If the IP camera supports PTZ function, user can use the control panel or joystick to adjust the viewing angle. The following functions are available depending on the camera models. Note: Please check the compatible list before using joystick to adjust PTZ cameras.
  • Page 57 ① Select a Preset Point from up to 128 preset points ② Enter Interval (3~1200 seconds) ③ Select Moving Speed: Fast, Normal, Slow Note: Moving Speed is supported for Canon cameras now. ④ Click “Add” button (Up to 25 preset points can be configured) ⑤...
  • Page 58 Schedule for PTZ: Click “Go” to start PTZ patrol schedule. Option Option button can let users directly to do live-view setting such as warning setting, windows setting and sequential mode setting. 1) General ① Resize all video sizes at the same time Only a right click on the video, users can set "all"...
  • Page 59 ② Highlight video window when event is triggered A warning frame will be shown when an event is detected. A warning frame will be shown when an event is detected. ③ Liveview event notification with video pop-out window Once the feature is enabled, a Single or Quattro window will pop out on Screen1 when an event is triggered.
  • Page 60 Users can select an optional feature to make the pop-out window automatically close after users assigned seconds. (Default is 10 seconds) If user enable event pop-out window for all cameras, all channels in NVR camera list will pop-out a video when events happen. Note: Video Wall Station will pop-out video event window once a time, depending on which event is triggered earlier when more than one event one event is triggered at the same time.
  • Page 61 click and drag one camera channel from monitor 1 to monitor 2. Without installing extra PC, users can use either mirror display (same liveview display mode on two monitors) or dual display (different liveview display modes on two monitors) to guard your place. Note1: Monitor connected with HDMI/HDMI...
  • Page 62 3) Microphone Volume Based on camera site audio volume, users can adjust the volume percentage of USB type microphone on liveview. The volume setting will be saved in Station, even NVR reboots. 4) OSD & Pointer OSD settings Set up to check camera and time information. ...

  • Page 63: Right Click Functions On Video Window

    3.2.3 Right Click Functions on Video Window 1. Video Size: Original or Fit 2. Streaming change: (1) Exchange Streaming Station allows users to setup the dual streaming configurations in camera parameter page if cameras support dual stream. It is suggested stream 1 is set for higher resolution and stream 2 for lower resolution, which helps users to choose the proper streaming in live view with intuitive control.
  • Page 64 (2) Optimize When “Optimize” is enable, streaming type is adjusted automatically in different display modes. When users select the display mode with more than 16ch, Station will automatically change to stream2 for smooth real time viewing experiences. Note: In 4K display mode, when users select the display mode with more than 9ch, NVR will automatically change to stream2 for smooth real time viewing experiences.
  • Page 65 Note: Station supports IP cameras equipped with Immervision’s Lens and VIVOTEK dewarping engine now. (2) Choose camera position (3) Choose display mode 4. Tripwire Display: to show/hide camera’s tripwire 5. Toggle Fullscreen: to execute/exit full screen 6. Camera status bar: to hide/ display camera status bar 7.

  • Page 66: Zooming With Mouse Scroll

    3.2.4 Zooming with Mouse Scroll In addition to digital zoom in/out button, users can use mouse scroll to prevent potential crisis in live-view monitoring. Note: For PTZ cameras, zooming with mouse in live-view is adopted optical zoom in/out. If users would like to view more detailed image, please use zooming with mouse scroll first and then click digital zoom in/out button.

  • Page 67: Playback

    3.3 Playback Video Well Station offers video playback from cameras that are connected via NVR. Users can have up to 5 channels simultaneous playback in below structures: Camera — NVR — Video Wall Station Camera — NVR — Streaming Server — Video Wall Station (NVR, Streaming Server and Video Wall Station need to be in the same LAN) 3.3.1 Steps to Playback Videos Users can easily search recorded videos by following playback steps.
  • Page 68 1. Select cameras from camera list Users can select up to five cameras to play the recorded video. 2. Select date and time Users can designate the specific date and time to playback video. If the selected cameras have recorded videos, the date will be shown in a blue background in default (Normal Record).
  • Page 69 4. Click “Play” Please click play button to start playback. Note: During video playback, NVR will skip the time when video is not existed and jump to play the time that video is existed. Frame by Frame Playback 1 Follow above four steps to playback 2 Click “Pause”...

  • Page 70: Description Of Recording Types

    3.3.2 Description of Recording Types Normal Record (gray): Normal Record means there is no special conditions happened such as event, time overlap. It helps users to know at that time whether NVR has recorded videos or not. Event (red): Event means an event is triggered at that time, which helps users to efficiently find event recoded video.

  • Page 71: Main Functions Of Playback

    3.3.3 Main Functions of Playback 1. Display mode Station supports multi-channel simultaneous playback. You can see the recording time of each channel in the top of each grid. Icon Description 1 screen 4 screen 5screen Full Screen 2. Audio control The audio will be played according to the channel selected on the screen.
  • Page 72 3. Digital zoom in and digital zoom out The image can be enlarged by clicking digital zoom-in button. The image can also return to previous sizes by clicking the digital zoom out button. 4. Video playback speed control (1) Stop: to clear playback videos (2) Previous frame: to show the earlier frame (3) Slow motion: to play in slower speed (4) Play/ Pause: to play video file or to temporarily stop the playback...
  • Page 73 6. Seek bar By moving seek bar, users can go to the specific recording time directly. Date and time are shown above seek bar to provide time reference. 7. Video export By clicking video export icon, users can easily export the key video after finding out the recorded video on Video Wall Station, and can review videos on remote PC (with NVRPlayer utility).

  • Page 74: Zooming With Mouse Scroll

    Confirm the video’s start time, end time, and capacity. If the information is correct, please click “Yes”. Please wait for export processing. You may click “Cancel” button to stop exporting videos. After exporting file 100%, it will pop out a window to notice users about record export successfully.

  • Page 75: Configuration

    Chapter 4. Configuration In configuration page, users can configure Quick Configuration, IP Camera, Recording & Event, Network Management and System from each drop-down menu. Note: Station will automatically log out from configuration page after idle for 10 minutes. IP Camera 4.1.1 Camera Settings Please refer to Chapter2 - 2.3.5 Camera Settings.
  • Page 76 Station supports multi-stream for monitoring. Users can modify camera’s configuration such as video format, frame rate and resolution video quality in this page. Note: Camera adding through NVR cannot be edited its parameter. Please go to NVR’s configuration page to edit camera parameter. There are two parts in this section: Parameter and Camera List.
  • Page 77 16-screen and above. Note: It is suggested stream 1 is set for higher resolution and stream 2 for lower resolution, which helps users to choose the proper streaming on live view with intuitive control.  Video Format Choose a video compression format for live view and recording: H.264, H.265, MJPEG and MxPEG.

  • Page 78: Camera Status

    4.1.3 Camera Status Please select “Camera Status” from the drop-down menu of IP Camera to begin.

  • Page 79: Network Setup

    Network Setup 4.2.1 Network Setup Please select “Network Setup” from the drop-down menu of Network to begin. This section explains how to configure network connection with station. Information Network information displays present network configuration including: Computer Name, IP address, Subnet mask, Default Gateway, Primary and Secondary DNS. Setup ①...
  • Page 80  DHCP: Obtain an available dynamic IP address assigned by a DHCP server. If this option is selected, system will automatically obtain an available dynamic IP address from the DHCP server when connecting to the LAN.  Static IP: If no DHCP server exists in the networking environment, t he IP address will be given as192.168.1.245.

  • Page 81: Network Service

    Note: Built-in DHCP server is available when LAN is specified an IP address (static IP). Note: Please do not connect to another device containing DHCP server function such as router when utilizing built-in DHCP server Port Setup Please set up transmission port to access station. Default port for station connection is 80.

  • Page 82: Management

    Management In Management, users can easily create, modify and change users' liveview and playback access. Also, users can read various log information through log system and quickly save or load configuration of station. 4.3.1 User Management Select “User Management” from the drop-down menu of Management to begin. Station can be accessed by multiple users simultaneously.
  • Page 83 Click “Apply” to add new Power User. After the Power User is created, user list will display the information as below.
  • Page 84 (2) User Administrator can select a group from “Group” drop-down list to assign a new User. Please enter a username and password in “User List.” And select Live View Access for the new User. After User is created, user list will display the information as below.
  • Page 85 Modify Users Please go to Modify User page. Select an account to modify the Power User or User. The selected account will turn to blue and the page for modifying user will appear as below. You can change Live View Access. Please click “Apply” to proceed. After User is modified, user list will display the renewed information.
  • Page 86 To delete the user account, please click “Delete” from User List in Modify Users page. Change Password Each station comes with a built-in “admin” account with password “admin” for administrators. It’s highly recommended to change the password upon the initial login.
  • Page 87 (1) Anonymous access on local display Anonymous user can only view live monitoring page on local monitor with no access of station configuration. Users can enable or disable this function in this page. For more information of anonymous login, please refer to 3.1.1 Anonymous login.

  • Page 88: Log System

    4.3.2 Log System Please select “Log System” from the drop-down menu of Management to begin. Log system provides four types of log record basic information for troubleshooting, including Hardware Log, Event Log, Current User, Historical User Log, and File Access Log. (1) Hardware Log The log information in Hardware Log includes CPU, buzzer, fan, system, sensor and USB.
  • Page 89 (2) System Log The log information in station Log includes time zone, daylight, system, firmware upgrading, configuration IP.
  • Page 90 (3) Historical User Log The log information in Historical User Log records any user who has logged in the system. For example, “Execute detect,” “Motion detected,” “Account is created,” “Execute system shutdown,” etc.
  • Page 91 (4) Current User The log information in Current User shows the current users logged in the system with IP address.

  • Page 92: Save/Load Configuration

    4.3.3 Save/Load Configuration Configuration Backup enables you to accelerate Video Wall Station deployment as well as to respond quickly to hardware failures and disasters. User can save Video Wall Station configuration file to external USB device. User also could save configuration file to PC via remote browser.
  • Page 93 Load Configuration Load configuration can help users duplicate the same settings from one Video Wall Station to another without configuring system manually. Users can select Load Type as “Load Default Settings” or “Load Configuration.” (1) Load Default Settings Camera Setting and Server Settings will reset to default. (2) Load Configuration Please select Volume (Local USB device ) and browse the folder to find the saved configuration.

  • Page 94: System

    System 4.4.1 Device Information Please select “Device Information” from the drop-down menu of System to begin.  System Information System Information shows Product Model, Firmware Version, MAC Address, Operating System, OS Version, CPU, Network Adapter and Locate. Locate Click "Locate", the buzzer will be triggered for 3 seconds. It helps the user to locate the system.

  • Page 95: System Upgrade

     Enclosure Information Enclosure Information shows CPU Temperature and System Fan Speed. Note: Temperature of operation environment for station is 0~40˚C. 4.4.2 System Upgrade Users can do firmware upgrade via Local Display (connect directly to a local monitor via HDMI or DVI connector). Note: Please make sure the model and the firmware version are correct.
  • Page 96 Instructions to format a USB device to FAT32 file system: Click on the "My Computer" shortcut on the desktop of your computer Right-click the flash drive and choose the "Format" option III. Change the selection under "File System" to FAT32 IV.

  • Page 97: Language

    4.4.3 Language Please select “Language” from the drop-down menu of System to begin. Station provides different languages for users. Users can configure the language as AUTO or other languages. Users can select a suitable keyboard language for different regional keyboard layouts.
  • Page 98 Select from the drop-down list and configure the time manually and the setting will be effective when you click “Apply”. 2. Time zone Users can set the time and date according to the correct time zone and adjust clock for daylight saving changes for your preference. Please enter the hostname of a valid NTP server to synchronize with external NTP server.
  • Page 99 selecting “Automatically Sync”. Based on users’ preference, system provide three selections to automatically synchronize with external NTP server: Monthly, Weekly or Daily. (1) Select “Automatically Sync” (2) Set up when to automatically synchronize with external NTP sever (3) Fill in the number to start auto synchronize when time difference is over user defined seconds (4) Click “Apply”...

  • Page 100: Reboot &Shutdown

    4.4.5 Reboot &Shutdown Please select “Reboot & Shutdown” from the drop-down menu of System to begin. Click “Reboot” to restart the station. Click “Shutdown” to turn off the station.

  • Page 101: Chapter 5. Remote Controller (Optional)

    Chapter 5. Remote Controller (optional) Remote controller allows user to select various options such as: Display mode, PTZ control, Sequential, Log, Snapshot, Option, Liveview, Configuration page, Mouse & Keyboard. 5.1 Overview  Band : 2.4 GHz  Distance : 10m ...

  • Page 102: Connect To Video Wall Station

    5.2 Connect to Video Wall Station Step 1. Insert USB dongle: Please insert controller’s USB dongle to your station. Step2. Enter programming mode to connect station: Note: To successfully connect to the station, please stay close to the station. The distance between USB dongle and remote controller should be within 1 meter.

  • Page 103: Instruction Of Liveview Interface (Side A)

    5.3 Instruction of Liveview Interface (Side A) Users can directly operate liveview interface on local display through remote controller. Please refer to below picture for more information.  “FN” button On the side A, there are two functions of some buttons: (1) white word (2) blue word Users are able to alter functions by pressing...

  • Page 104: Instruction Of Mouse And Keyboard (Side B)

    5.4 Instruction of Mouse and Keyboard (Side B)  Enable mouse function: put side B up, and press “Fn” button  Disable mouse function: The mouse function will be disabled in below situations: Press “Fn” button on sideB Turn to Side A for liveview operation No actions, including pressing the button and move the controller, for 10 seconds ...

  • Page 105: Chapter 6. Remote Controller (Via Digimobilev2 Ver.3.0.17)

    Chapter 6. Remote Controller (via DIGIMobileV2 ver.3.0.17) In the same LAN environment, user can use your mobile device to directly and intuitively operate local liveview interface without using the mouse. Note: This feature is available when VD and your mobile device are in the same LAN.
  • Page 106 After saving VD information, the application will bring you to VD page. Connecting Status The status icon can inform users of NVR connecting status in NVR page. Status icon Description Connecting: The application is connecting to the NVR server. Successfully Connected: The application is ready to start remote monitoring.
  • Page 107 Step2. Remote Control Please tap “Search” and one VD that you would like to control. Enter Port, VD Account and Password. Click “Done”.  Controller Introduction: 1. Display mode: To change liveview display mode. Note: The display mode will be adjusted according to the number of cameras.
  • Page 108 2. Change liveview window Please use arrow keys to change liveview window in blue grid. 3. Control bottons: Full Screen Previous Page Next Page Snapshot Mute/ Sound Digital Zoon in Digital Zoom out Sequential Mode Enable PTZ Control 4. PTZ Control PTZ icon will turn into blue if the IP cameras supports PTZ function.
  • Page 109 PTZ Control Page: Home: Back to original monitoring position Optical Zoom in Optical Zoom out...
  • Page 110 Appendix: Notice and Warning Notice ＊This equipment is for home use, and has acquired the electromagnetic conformity registration. So, it can be used not only in residential area, but also other areas. ＊ 이기기는가정용(B 급) 전자파적합기기로서주로가정에서사용하는것을목적으로하며, 모든지역에서사용할수있습니다. Warning ＊Risk of explosion if battery is replaced by an incorrect type. Please dispose of used batteries according to the instructions.
