Summary of Contents for Uniforest 35M
- Page 1 Instructions for use FORESTRY WINCHES 35M / 40eco Instructions for safe work Spare parts list Manufacturer Uniforest d.o.o. Dobriša vas 14/a 3301 PETROVČE www.uniforest.si Valid from serial number onwards: 142004321 40eco 143004101...
- Page 2 Dear customer! We are pleased that you decided to purchase our machine. Forestry winch is a forestry machine of modern design, whose construction enables effective and safe work in the forest. Work in the forest can only be safe if you follow the instructions for safe work and use. Upon following all instructions, the machine will operate flawlessly, and you will avoid unnecessary costs.
-
Page 3: Intended Purpose
2. Intended purpose The machine is intended exclusively for normal work in the forest. Any other use outside of this framework holds as unintended. The manufacturer is not liable for damages, resulting from unintended use. In this case, the user is the sole bearer of risk. Intended use also includes regarding operational, service and maintenance conditions, which are prescribed by the manufacturer. - Page 4 INSTRUCTIONS FOR SAFE WORK When operating the winch, you must devote maximum attention to safety! To prevent accidents, carefully read and follow the instructions below. 1. General: 1. Apart from the instructions in this user manual you should also observe all general safety and accident preventing regulations.
- Page 5 14. If the tractor is not blocked against moving with a brake or wheel blocks, no person should be standing between the tractor and the winch. 15. Do not touch the winch until every part of the winch has stopped. 16.
- Page 6 Figure 3 Figure 4 Figure 5 28. Do not use the winch for unintended purposes (lifting loads, etc.).(Figure 5) 29. Tractor driver and assistant must continuously communicate during their work. 30. The winch operator must continuosly observe the load during the tow. If this is not possible due to the configuration of the terrain, the assistant should help.
-
Page 7: Cardan Shaft
Tow rope Oscillating rope Torn–off pulley Triangle area Pulley Danger area Tree Figure 6 Figure 7 2. Cardan shaft 1. Only use such cardan shafts which are recommended by the manufacturer. 2. The cardan shaft protection pipes, protective funnels and attachment protection must be mounted on the machine and be in perferct condition. - Page 8 Maximum number of revolutions and direction of tractor PTO shaft rotation is 540 min PTO SHAFT ADJUSTMENT Length of PTO shaft needs to be adjusted for different tractors (figure 6). For winch 35M, it is appropriate to use a PTO shaft, torque max. 355 Nm, type W 200E, for 40eco torque max. 500 Nm, type W 300E Walterscheid.
- Page 9 Figure 8 2. Tractor mounting When connecting the winch, do not stand in the danger zone! Forestry winch can be connected to any tractor, which has a three-point hitch, with connection frame of category I or II. Appropriate construction also enables easy connection to the tractor with automatic connection rods.
- Page 10 ATTENTION! Loosely wound steel rope can be damaged (stuck, bent) at greater load, so that it is prohibited to use it again. Warranty does not apply for a steel rope, which is damaged in such manner. Once the winch is correctly connected, we start to unwind the wire rope. We do this so that we pull the wooden handle on the red rope (pos.
- Page 11 SETTINGS 1. Clutch Proper setting of the clutch ensures optimal pulling force. Clutch is factory set upon winch testing, but it is required to set it again due to wear of the friction coating. Readjustment is not allowed during warranty period! Setting is done so that we mount a dynamometer on the black rope.
- Page 12 Figure 12...
-
Page 13: Drive Chain Tensioning
4. Drive chain tensioning After a certain period of operation, the drive chain stretches; therefore it must be checked frequently and tensioned, if required. It must be checked every 60 hours of operation. Tensioning is done according to the following procedure (figure 13). First, remove the protective sheet metal of the PTO shaft (pos. -
Page 14: Maintenance
MAINTENANCE LUBRICATION Before proceeding with maintenance work, shut down the engine, remove the key and wait for all moving parts to stop. There is a grease fitting on the winch, which enables greasing of the upper pulley and guide. The second grease fitting is on the housing of the lower pulley. Greasing is required every 60 hours of operation. - Page 15 REMOVAL OF FAULTS Determined faults Cause Procedure for removal of (malfunctions) faults (trouble) Insufficient Grease on frictional padding Replace clutches. pulling force. of the clutch. Burnt frictional padding of the Clean padding with clutch. sandpaper or grind (thickness approximately 0.5 mm).
- Page 16 Determined faults Cause Procedure for removal of (malfunctions) faults (trouble) The winch pulls, Improper setting. Setting according to despite the instructions. clutch being Crossed, wound rope for control of Installed the rope in parallel disengaged. brake handle. manner. Lever, connecting the brake Check the lever.
-
Page 17: Spare Parts List
SPARE PARTS LIST Forestry winches – 35M / 40eco (Image 1) Pos. Title Plan or standard number 40eco Nr. of Nr. of Frame var. 305.01.00.0 304.01.00.0 Lower pulley kpl. 5006.10.00.A 5006.10.00.A Trailer coupling kpl. 502.12.20.0 502.12.20.0 Brake and clutch kpl. - Page 18 Image 1...
- Page 19 Forestry winches – 35M / 40eco (Image 2) Pos. Title Plan or standard number Nr. of pcs Pre-brake screw 702.00.41.0 Brake wire 5,5 m kpl (red) 1000554 Clutch wire 6.5 m kpl. (black) 1004067 Small single pulley 502.00.40.0 Small double pulley 502.00.41.0...
- Page 20 Nut M10 Zn 1000141 Nut M12 Zn 1000142 Washer M8 Zn 1003473 Washer M8 Zn 1003471 Washer M16 Zn 1000183 Washer M8 Zn 1003465 Image 2...
- Page 21 Forestry winches – 35M / 40eco (Image 3) Pos. Title Plan or standard number Nr. of pcs Main shaft 305.07.10.0 Gear wheel with plate 305.07.00.0 Wire rope drum 305.05.00.0 Spacer 305.05.07.0 Brake compression spring 502.00.30.0 BEARING 6208 2Z 1000301 BEARING 6308 2Z...
- Page 22 Forestry winches – 35M, 40eco (Image 4) Nr. of Pos. Title Number Pin var. 305.00.07.0 Coupling pin var. 305.00.25.0 Protective metal sheet 305.00.50.0 Cover kpl. 305.11.00.0 Cardan shaft protection kpl. 305.35.00.0 Protective screen var. 5006.88.00.A Protective screen bolt 5006.88.15.0 Screw M8x20 Zn...
- Page 23 Image 4...
- Page 24 Forestry winches – 35M, 40eco (Image 5) Nr. of Pos. Title Number Cover var. 305.11.01.0 Leg pin 10 502.00.13.0 Cardan holder 502.11.08.0 Small cover 502.11.09.0 Support leg var. 305.00.10.0 Screw M12x20 Zn 1000055 Screw M8x16 Zn 1000050 Screw M12x55 Zn...
- Page 25 Forestry winches – 35M, 40eco (Image 6) Pos. Title Nr. of pcs Number Upper pulley 305.09.01.0 Pulley wheel 305.09.08.0 Cardan holder 305.09.09.0 Pulley sleeve 305.09.29.0 Bearing 6305 2RS 1000310 Snap ring N62x2 1000237 Washer M12 Zn 1000166 Screw M12x65 Zn...
- Page 26 Forestry winches – 35M, 40eco (Image 7) Nr. of Pos. Title Number Drive shaft with a gear wheel 305.08.01.0 Drivetrain housing 305.08.05.0 Ball bearing 6208 2Z 1000301 Nut KM8 ( M40x1,5 ) 1000145 Washer mb-8 1003510 Image 7 Forestry winches – 35M, 40eco (Image 8) Nr.
- Page 27 Forestry winches – 35M, 40eco (Image 9) Nr. of Pos. Title Number Pin var. 5006.10.01.A Coupling pin var. 5006.10.09.0 Protective metal sheet 5006.10.10.0 Cover kpl. 5006.10.11.0 Cardan shaft protection kpl. 5006.10.12.0 Protective screen var. 5006.10.14.0 Protective screen bolt 5006.10.18.A Screw M8x20 Zn 502.09.08.0...
-
Page 28: Ec Declaration Of Conformity
DOBRIŠA VAS 14, 3301 PETROVČE DESCRIPTION OF DEVICE - MACHINE: WINCH: UNIFOREST 30M, 35M, 40 eco, 50 eco, 40E, 40ER, 40EH, 40Hpro 50E, 50ER, 50EH, 50Hpro, 60E, 60ER, 60EH, 60Hpro, 80E, 80ER, 80EH, 80Hpro WE DECLARE UNDER OUR SOLE RESPONSIBILITY THAT THE ABOVE MENTIONED MACHINE...
