Summary of Contents for Field Tuff FTF-48SHLR
- Page 1 48" Sleeve Hitch Landscape Rake OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Model # FTF-48SHLR 03032020...
- Page 2 Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only.
- Page 3 WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a 48" Sleeve Hitch Landscape Rake. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area.
- Page 4 ASSEMBLY 1. Put the Tines (#4) under the Tongue Bracket (#2) and secure with Tine Bracket (#3). Put Carriage Bolt (#9) through the Tongue Bracket (#2), secure with Nut (#10). 2. Attach the Tongue (#1) with Bolt (#5), Nut (#7), Pin (#6) and R-pin (#8). Adjust the angle by using Pin (#6) and R-pin (#8) when necessary.
- Page 5 MAINTENANCE • Maintain your 48" Sleeve Hitch Landscape Rake. It is recommended that the general condition of any 48" Sleeve Hitch Landscape Rake be examined before it is used. Keep your 48" Sleeve Hitch Landscape Rake in good repair by adopting a program of conscientious repair and maintenance.
- Page 6 DIAGRAM & PARTS LIST Part# Description Qty. Tongue Tongue Bracket Tine Bracket Tine Bolt M20x80 Nut M20 R-Pin Carriage Bolt M10x40 Nut M10 For replacement parts and technical questions, please call 1-218-943-6296. WARRANTY One-year limited parts warranty PO BOX 203 Miltona, MN 56354 Made in China Page of 6...
