Have you got everything?
A
A. Function key
B. Battery LED indicator
C. Bluetooth LED indicator
Operation
Connect via Bluetooth
• Slide the power switch to on to turn the keyboard on. The Bluetooth LED
indicator will light up blue for 3 seconds. Press the Pair button and the
LED indicator will flash blue, indicating it is ready to pair.
• Select the correct Operating System (OS) by referring to below:
• For iOS: Press the Fn and Q button
• For Android: Press the Fn and W button
• For Windows: Press the Fn and E button
• On your device, look for "BAUHN AFKBT-0422" and connect.
• Once connection is successful, the LED indicator will stop flashing and
turn off.
Charging the Keyboard
• When the keyboard is low on battery, the battery LED indicator will flash
red indicating it needs to be charged.
• Connect the supplied USB cable to the USB charging port on the
keyboard and the other end to a power source. The battery LED indicator
will light up red during charging, and will turn off once fully charged.
Touchpad functions
• Note: touchpad functions are not compatible with iOS and Android
operating systems.
Cannot connect to
Bluetooth
Keyboard not
working
B CD
E
D. Caps lock indicator
E. Touch pad
F. Power switch
®
Finger click:
Left mouse
Two finger slide:
Mouse wheel
• Select the correct Operating System (OS)
• The keyboard will automatically go into
standby mode if Bluetooth is not paired.
Press the Pair button to connect.
• Check that the device's Bluetooth is on.
• Check that the power switch is on.
• The keyboard will automatically go into
standby mode after 10 minutes of no
operation. Press any key and the keyboard will
turn back on.
• Slide the power switch to Off and slide back
to On to restart the keyboard.
• Check that the device's Bluetooth is on and
paired with the keyboard.
Foldable Keyboard with Bluetooth
D
Product Overview
F
G
G. Pair button
H. USB charging port
Two Finger click:
Right mouse
Two finger stretch:
Zoom in/out
Troubleshooting
User Guide
Model: AFKBT-0422
A. Foldable Keyboard
B. USB Cable
C. User Guide
D. Warranty Certificate
H
®
Advertisement
Table of Contents
Related Manuals for Bauhn AFKBT-0422
Summary of Contents for Bauhn AFKBT-0422
- Page 1 • For Android: Press the Fn and W button • For Windows: Press the Fn and E button • On your device, look for “BAUHN AFKBT-0422” and connect. • Once connection is successful, the LED indicator will stop flashing and turn off.
- Page 2 Specifications Power Input 5VDC 1A 3.7V, 140mAh Battery Bluetooth Bluetooth connection <10m distance Number of keys 304 x 98 x 8mm (when open) Dimensions 152.5 x 98 x 14mm (when folded) 193g Weight Give us a call What? You mean this User Guide didn’t have ALL the answers? Speak to us! We’d love to help you get up and running as quickly as possible.
