Summary of Contents for iMove STADSFIETS FIRST LADY
- Page 1 Operation Instruction Maintenance Manual Warranty Instruction STADSFIETS FIRST LADY STADSFIETS PRESIDENT CITYBIKE FIRST LADY CITYBIKE PRESIDENT Electric Bicycle (Electric Vehicle) | Comply with safety standards - 1 -...
-
Page 2: Table Of Contents
Please Pay Attention: Our electric bicycle is specially designed for city roads. Intensive use of the electric bicycle or riding it not on flat roads can cause damage to the bicycle so that the bicycle will be out of order ahead of time and result in injuries. Like other machine combination, electric vehicles will also be aging due to high pressure and wear. - Page 3 1 Battery: extraction, charge, insertion, use and maintenance Battery is located on the lower-central beam and it should be fully charged before using. If you need to take out the battery, please follow the steps below: 1.1 Extract battery: turning the key clockwise to loose latch.
-
Page 4: Adjust Handlebar Position
1.5 Be sure to lock the battery box tightly against theft. 1.6 Battery debugging period: during the using periods for first 5 to 10 times (fully charging and discharging in about 2 to 5 times), there will be chemical reaction inside the battery. If the reaction is inadequate, the battery can’t achieve the best running status, so charge using in the first time will not exceed 80% of the capacity of electricity. -
Page 5: Tire Inflation
Note: security thread on handlebar should not be exposed. 2.2 Adjust saddle height Adjust the seat post to the ideal position and quickly tighten. Note: security thread on handlebar should not be exposed. 3 Tire Inflation Observe the tire walls and control the tire pressure intensity. Unit: P.S.I. Check if the tire pressure is normal, for under-inflation could affect the travel speed;... - Page 6 power assist level and walk mode: 0-4 files assist level, power from low to high are: OFF, ECO, TOUR, SPORT, TURBO, OFF means no power assist； Current speed and unit show the current riding speed; Subtotal mileage and unit: accurate to one after the decimal point, maximum is 999.9km;...
- Page 7 Turn on/off： ，Function button：M ，Adjust button+ :∧，Adjust button-：∨. Before you start Switch on the battery after making sure that everything is tightly plugged into the controller. Turn on and turn off Press and hold “ ” to turn on; while the bicycle is on, press and hold “ ”...
-
Page 8: Maintenance And Adjustment
Battery status When the battery works normal, the battery power shows 5 levels according to the battery capacity. When the battery power reaches the under voltage warning value, only frame of the battery icon is displayed and flash to remind the user to charge immediately. The battery power is shown as below: 6 Maintenance and Adjustment 6.1 Lubricating Methods... - Page 9 6.3 Adjustment of the Speed Control System When gently stepping on the pedal, make sure the belt matches the freewheel. When detecting connection not well or noise, you can try adjusting the screws. It is recommended not to pedal hard. 6.4 Adjustment of the Brake System To adjust the disc brake, you can use a hex key wrench to adjust the clamp screw (A);...
-
Page 10: Tightening Torque
6.7 Cleaning and Maintenance of Bicycle Scrubbing the bicycle with wet cloth and use it until the bicycle is naturally dry. Never wash it with water to avoid the damage of electronic components. The bicycle should be parked in dry places to avoid damages caused by bad weather.. 7 Tightening Torque For safe riding, it is advised the tightening torque of all parts of the bicycle should meet the following criteria:... - Page 11 Items of Regular Maintenance Items to Check DAYS: 1. If components of the handles and steering gear are tightened and if there is any wear and tear. 2. If the hubs and the bead holder are tightened and if there is any wear and tear 3.
-
Page 12: Accessories
8 Accessories We suggest that you ask professional person to assemble components. If some part are damaged, please replace them immediately. 9 Safety Instructions • For safe riding, you’d better obey the following provisions: • Check carefully if the bicycle is in good condition before departure. •... - Page 13 Error code Error description "04" shown at speed throttle doesn't turn back to zero position (stay on the high position) "05" shown at speed throttle failure "07" shown at speed overvoltage protection "08" shown at speed failure of motor's hall signal wire "09"...
-
Page 14: Warranty
The specification of this electric bicycle’s battery is 36V (the capacity is depending on what’s ordered at iMove B.V., and the discharge rate is constant), and the driving range will be affected by many external factors (load capacity, grade, wind force, external temperature, tire inflation degree, air pressure, etc.). - Page 15 For the daily maintenance of bicycle parts, all special maintenance centers provide services of maintenance and repair. However, for the electronic components in motor, battery and power plant, only iMove B.V. getting our formal authorization and express permission can handle them.
-
Page 16: Keys
The key can lock the battery on your electric bicycle. Please don’t lose the key, or you should change the lock and key immediately. Also inform you insurance company if you have a contract with them. 14 Contact information iMove B.V. DARWINSTRAAT 9-H 6718 XR EDE (NL) PHONE:...
