Specification
Alarm Volume
Alarm Mode
Wake-Up Cycle
Battery Type
Battery Model
Execution Standard
CO Sensor Type
Interface / Display
Standby Current
Power Supply
Low Voltage Threshold
Working Conditions
Product & Battery Life
Included in Box
Dimensions
Weight
Carbon Monoxide Detector
CODE: QFS-CO
Features
- LCD Screen
- Carbon Monoxide (CO) Alarm
- Sealed Tamperproof
- Compliant with EN50291-1:2018
- Alarm Sounder (85dB)
Lithium Integrated Battery
QFS-CO
>85dB
LED & Buzzer
6 Seconds
4pcs 1.5V Lithium Iron Battery
FR14505
EN50291-1.2018
CO Electrochemical Sensor
Test/Hush Button on Front / LCD Display
<30uA
DC6V
5.6V
-10°C to +50°C, 30% to 90%RH (Humidity)
Wall Hanging
10 Years
2x Screw, 2x Positioning Screw,
1x Easy-Install Bracket
129mm x 74mm x 38mm
140g
Advertisement
Table of Contents
Related Manuals for Qvis QFS-CO
Summary of Contents for Qvis QFS-CO
- Page 1 Carbon Monoxide Detector CODE: QFS-CO Features - LCD Screen - Carbon Monoxide (CO) Alarm - Sealed Tamperproof Lithium Integrated Battery - Compliant with EN50291-1:2018 - Alarm Sounder (85dB) Specification QFS-CO Alarm Volume >85dB Alarm Mode LED & Buzzer Wake-Up Cycle...
- Page 2 Carbon Monoxide Detector CODE: QFS-CO Functions Initialisation Constant Green LED Flash Normal Green LED Flash Once (50 seconds) Alarm Red LED Flashes Quickly, Buzzer Sound Mute Red LED Flashes (10 seconds), No Sound; If After 10 Minutes the CO Concentration Doesn’t Return to Normal Threshold, the Alarm Will Reactivate Automatically.
- Page 3 Carbon Monoxide Detector CODE: QFS-CO Alarm Response Initial Reaction Alarm Activation Hush Function <50PPM Concentration Normal No Alarm Manual Mute Can Be Activated 50 to 100PPM Red Flash Every 2 Full Alarm After Manual Mute Minutes (Silent) 80min (Approx) Can Be...
- Page 4 Carbon Monoxide Detector CODE: QFS-CO Installation 1) Take Out Installation Tools 2) Determine Installation Position (Do Not Obstruct Air Inlets) Ceiling 1.5m to 2m Farthest 3) Fix Wall Bracket to the Alarm, Install Onto Wall with Screws Included in Box Ceiling 4) Install the Battery &...
