- Page 1 Showersave® QB1-21 QB1-16 QB1-12 Installation Manual...
-
Page 2: Table Of Contents
Showersave®QB1-21 (heat exchanger) QB1-16 QB1-12 Contents Page 1.0 General information 1.1 Description of heat exchanger 1.2 Safety and legionella 1.3 Maintenance and cleaning 2.0 Points of attention when installing 3.0 Installation of the Showersave®QB1 3.1 Systems A, B en C 3.2 Connections 3.3 Positioning of the Showersave®QB1 3.4 Fixation of the Showersave®QB1... -
Page 3: General Information
QB1-12 1.0 General Information This Installation Manual is about installation of the Q-Blue Showersave®QB1-series. This serie contains the Showersave®QB1-21, the Showersave®QB1-16 and the Showersave®QB1-12. The way these products work is identical, only the lenghts of the heatexchangers differ. Because the lenghts of the heatexchangers differ also the efficiencys and the pressurelosses differ (see points 4.0 and 4.1 of this manual). -
Page 4: Maintenance And Cleaning
Showersave®QB1-21 (heatexchanger) QB1-16 QB1-12 1.3 Maintenance and cleaning Generally no maintenance is required. Efficiency can decrease as a result of dirt accumulating on the inside of the Showersave®QB1. However, the waste water from the showersave flows at a high speed (>1m/s) along the inner pipes wall. -
Page 5: Installation Of The Showersave®Qb1
Showersave®QB1-21 (heatexchanger) QB1-16 QB1-12 3.0 Installation of the Showersave®QB1 3.1 Systems A, B en C The inlet side of the Showersave®QB1 can be connected to the tap water system. The outlet side can be installed in three different ways, namely: System A: Combined connection to the shower mixer tap’s cold water connection and the heater/boiler System B: Connection of the cold water connection from the shower mixer System C: Connection to the water heater/boiler... -
Page 6: Connections
Showersave®QB1-21 (heatexchanger) QB1-16 QB1-12 3.2 Connections The tap water connections should be demountable. Just before the tap water connection a non-return valve and a shut-off valve should Afb. 1 be mounted (type EA) (see afb. 1). Extra aeration aeration pipe Dearation of the Showersave®QB1 is not (relief pipe) necessary, all air will disappear automatically... -
Page 7: Technical Information Of The Showersave®Qb1
Showersave®QB1-21 (heatexchanger) QB1-16 QB1-12 4.0 Technical information of the Showersave®QB1 Specifications QB1-21 QB1-16 QB1-12 Length : 2100 mm 1680 mm 1270 mm Weight : 7,8 kg 6,1 kg 4,5 kg Content water compatiment : 0,52 liter 0,39 liter 0,28 liter Diameter (outer) waste water connection : 50 mm 50 mm... -
Page 8: Dimensioning (Sizes) For Mounting Of The Showersave®Qb1
Showersave®QB1-21 (heatexchanger) QB1-16 QB1-12 4.1 Dimensioning (sizes) for mounting of the Showersave®QB1 QB1-21 QB1-16 QB1-12 Connection to Connection to Connection to shower’s drain, shower’s drain, shower’s drain, Ø50 mm Ø50 mm Ø50 mm Connection for Connection for Connection for preheated water preheated water preheated water pipe female...
