ACRITEC Undermount Basins Installation Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Undermount Basins
Installation Manual

Important

• Thoroughly inspect your product before
proceeding with the installation.
• The warranty will be void if the product is
installed with a conspicuous defect.
Caution
• Read all instructions carefully before
starting the installation.
• Save this manual for future reference.
Acritec Industries Corp.
27049 Gloucester Way
Langley, BC V4W 3Y3
Tel: 604.607.0856
Fax: 604.607.0857
Email: info@acritec.com
Website: www.acritec.com
In keeping with our policy of continuing product improvement. Acritec Industries Corp.
reserves the right to change product specifications without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Undermount Basins and is the answer not in the manual?

Questions and answers

Related Manuals for ACRITEC Undermount Basins

Summary of Contents for ACRITEC Undermount Basins

  • Page 1 • Save this manual for future reference. Acritec Industries Corp. 27049 Gloucester Way Langley, BC V4W 3Y3 Tel: 604.607.0856 Fax: 604.607.0857 Email: info@acritec.com Website: www.acritec.com In keeping with our policy of continuing product improvement. Acritec Industries Corp. reserves the right to change product specifications without notice.
  • Page 2 Recommended Fasteners Marble Or Stone Surface Solid Wood Counter-top (Not Supplied) (Not Supplied) 4 x Clips 4 x Clips 4 x Brass Fittings #10 Machine Screws #10-24 Machine Screws Before You Begin Before starting your installation, please Remove the item from its packaging and take a few minutes to read these inspect it thoroughly for damage and instructions carefully.
  • Page 3 Site Preperation Step 1 Place sink upside down on the counter-top in the desired position. Trace the profile of the sink onto the counter-top. Mark the location of the faucet hole centerline on the counter-top. Step 2 Determine the desired amount of overhang, then measure in from the traced profile of the sink (A1).
  • Page 4 Installation & Finishing Step 3 Install undermount clamps in accordance with the clamp manufactures and counter-top manufacturer’s guidelines. After dry-fitting the counter-top and checking the alignment to the opening apply a bead of silicone to the rim of the sink. Center the basin and tighten the screws to secure the bowl to the counter top.
