- Page 1 MAGIC LAMP PRO EVAPORATIVE SNOW® MACHINE USER MANUAL 24/7 TECH SUPPORT: (256) 229-5551 Global Special Effects | All Rights Reserved www.GlobalSpecialEffects.com | 256-229-5551...
-
Page 2: Machine Information
WARNING: You must read the following before operating this device. The Magic Lamp PRO is an electrical product, not a toy. To avoid the risk of fire, burns, personal injury, and electric shock, it should not be used in a manner for which it was not designed and should be placed out of reach of small children. -
Page 3: Technical Specifications
Programmable Cycle Timer • Adjustable Flake Size and Quantity • Limited Lifetime Warranty (When using Global Special Effects Fluid) • 24-Hour Tech Support: (256) 229-5551 SAFETY INFORMATION This unit is not a toy. To avoid the risk of fire, burns, personal injury, and electric shock, it should not be used other than as described herein, and always under adult supervision. -
Page 4: Included In The Package
The Magic Lamp PRO must be fully assembled before connection of electric service. The Magic Lamp PRO must be operated on a level and stable surface sufficient enough to support the weight of the unit and any snow fluid or accessories. - Page 5 ASSEMBLY INSTRUCTIONS WARNING: The Magic Lamp PRO should remain unplugged during the assembly process. Remove Lamp Base Sub-Assembly from packaging and place on firm, level surface. Locate the Solution Line Quick Connect and Electric Socket at the top of the Lamp Base Sub-Assembly as shown in Fig.
- Page 6 Fig. 2 ASSEMBLY INSTRUCTIONS Remove lid from the base of the Magic Lamp PRO by rotating the latch shown in Fig. 3 then tilting and lifting the lid away from the base. Fig. 3 Locate the fluid suction line inside the base on the lower left-hand side of the unit.
- Page 7 See Page 10 for more information about Evaporative Snow® Fluid. NOTE: The Magic Lamp PRO base will fit up to a standard 5-Gallon Bucket of Evaporative Snow® Fluid. Smaller containers may be used as desired. Place the Evaporative Snow® Fluid container into the base of the Magic Lamp PRO.
- Page 8 Short Cycles of ON/OFF Activity (5 Minute) – See Table 3 Long Cycles of ON/OFF Activity (15 Minute) – See Table 4 Always On – See Table 5 Using Hard Wire Remote (Sold Separately) – See Table 6 Global Special Effects | All Rights Reserved www.GlobalSpecialEffects.com | 256-229-5551...
- Page 9 Channel 4: Flake Size Smallest Flake <<<<<<<<<<<<<<>>>>>>>>>>>>>> Largest Flake *The Magic Lamp PRO Controller is compliant with DMX-512 standards and is electrically isolated to 1000VAC. The starting address can be set from 1 to 509. TABLE 3 (5 Minute Cycles) Set 3-digit code on rotary dials reading top to bottom.
- Page 10 *There is a red status light on the Hard Wire Remote. If the remote is connected and set to the OFF position, the light will slowly pulse to indicate the unit is in standby mode. When the switch is turned to the ON position, the light will be solid red. Global Special Effects | All Rights Reserved www.GlobalSpecialEffects.com | 256-229-5551...
- Page 11 Global Special Effects fluids are crafted with high quality ingredients to prolong the life of your machine, as well as produce a very dry and high-quality snow. Using cheap, low quality fluid can cause clogging inside the machine which may lead to internal damage.
-
Page 12: General Care And Maintenance
Ensure the Magic Lamp PRO is unplugged prior to any cleaning or maintenance. To clean the Magic Lamp PRO prior to storage: Fill a clean 1-gallon container with water, drop in the fluid line, and run the machine for 3-5 minutes. -
Page 13: Troubleshooting
TROUBLESHOOTING The Magic Lamp PRO will not turn on when the switch is in the ON position. Check that the unit is securely plugged into a GFCI outlet. Make certain that the GFCI outlet is not tripped. Verify that the electrical circuit is active by testing with known good device. - Page 14 Snow generated is very wet or light in volume. NOTE: Allowing approximately two minutes for the Magic Lamp PRO to come on to full operation after an extended storage period or for the first time operating. In many cases, priming the pump with solution using an appropriately sized syringe or other injector pump will ease the start-up process.
-
Page 15: Limited Lifetime Warranty
Running any other fluids or solutions other than Global Special Effects solutions through the pump automatically voids this warranty. Global Special Effects is not responsible for loss of income, labor, or business as a result of a Magic Lamp PRO’s malfunction. Global Special Effects is not responsible for physical damage, scratching, or tube damage after shipping from the Global Special Effects manufacturing facility.
