NetComm NS4540 Specifications

The device is also self-contained Web Server. Users access the Network Dome Camera just like browsing a website over Internet
and can simply perform all the management, configuration, and monitoring. The device contains an image compression chipset
which is capable of delivering standard JPEG, MJPEG and real-time video onto your network.
Features
> 22X Auto Focus Lens
> Built-in 22X optical zoom lens with focal length
3.9~85.4mm
> 360° continuous rotation; 180° Horizontal Instant Flip
> Automatic/Manual Iris Control
> Up to 128 programmable preset positions;
> Preset positions auto scanning
> High speed rotation and tilt, speed range varies from
0.18°/sec ~360°/sec
The NetComm series of outdoor dome housing is designed to house a single NetComm Network Dome Camera. This decorative
housing features a flame resistant ABS external upper casing and a vandal resistant polycarbonate lower casing. This unique
design provides cameras with complete protection from vandalism. It is available in two models: wall mount and pendant mount.
Both models come with a built-in heater and fan.
> Rust-free aluminum bracket with flame resistant ABS upper casing
> Vandal resistant lower casing (clear or tinted)
> Sealed to protect camera from moisture and dust
> Meets CE and IP68 standards
> Built-in heater and fan
> Heavy-duty construction protects from vandalism
> Available in wall mount or pendant mount
NetComm Limited ABN 85 002 490 486 2-6 Orion Road, LANE COVE, NSW, 2066
phone 02 9424 2070 • fax 02 9424 2010 • email sales@netcomm.com.au
www.netcomm.com.au
The NS4540 Network Dome Camera is an all-in-one Web-Based digital Network Speed Dome
Camera for remote surveillance applications. It features Pan/Tilt/Zoom capabilities and a
CCD module to distribute compressed live video on to your network via an Ethernet
connection. The device can be controlled via the software Pan/Tilt/Zoom functionality (or by
an external hardware controller) to get the best monitoring angle easily via a standard
browser such as Explorer or Netscape.
OUTDOOR DOME HOUSING OUTDOOR DOME HOUSING
OUTDOOR DOME HOUSING OUTDOOR DOME HOUSING OUTDOOR DOME HOUSING
IP DOME CAMERA IP DOME CAMERA IP DOME CAMERA
IP DOME CAMERA IP DOME CAMERA
> 6 alarm inputs, 1 alarm output set as NO (normally
open) or NC (normally close)
> Build in 1/4" CCD high resolution DSP color camera
> 480 TV Lines high resolution;0.8 Lux high sensitivity
> 12V dc voltage input (power supply options: (AC
90~260V or AC 24 V)
> Flexible Mounting: Indoor-embedded and attached
types
> Outdoor-with weather resistant housing
