INSTRUCTION MANUAL
#14361
4 TON HEAVY DUTY
FLAT TOP JACK STANDS
!WARNING!
Save This Manual
Keep this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the man-
ual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Read this material before using this product. Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 14361 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Pro 14361

  • Page 1 INSTRUCTION MANUAL #14361 4 TON HEAVY DUTY FLAT TOP JACK STANDS !WARNING! Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the man- ual near the assembly diagram (or month and year of purchase if product has no number).
  • Page 2 14361 INSTRUCTION MANUAL !WARNING! To avoid serious personal injury, always wear proper protective gear, such as hard hats, safety glasses, gloves, and steel toe shoes when using hydraulic equipment. Failure to chock the wheels and crib the vehicle can result in Serious injury or death. Always deflate tires before removing a wheel, a rim, or part of a rim clamp or nut.
  • Page 3 14361 INSTRUCTION MANUAL 6. Wear ANSI-approved safety goggles and heavy-duty work gloves during use. 7. Do not use for aircraft purposes. 8. Support vehicle only at manufacturer-recommended locations. 9. Inspect before every use; do not use if parts loose or damaged. 10. Examine Jack Stands for cracks or damage before each use. Do not use if even a minor crack, bend or other damage/deformation appears. Discard Jack Stand if damaged or deformed. 11. Keep work area clean. Cluttered areas invite injuries. 12. Observe work area conditions. Keep work area well lighted. 13. Keep children away. Children must never be allowed in the work area.
  • Page 4 14361 INSTRUCTION MANUAL !WARNING! To avoid serious personal injury, always wear proper protective gear, such as hard hats, safety glasses, gloves, and steel toe shoes when using hydraulic equipment. Operating Instructions Supporting a Vehicle 1. Make sure the vehicle does not exceed the capacity of the Jack Stands. Note: Check that the weight is evenly distributed between the Jack Stands. You must evenly distribute the weight or the Jack Stands may fail, causing severe injury or death. Only apply the load vertically. WARNING! TO PREVENT SERIOUS INJURY: If a vehicle drops on the Jack Stands (even if it is under the weight capacity limit), the principle of “dynamic loading” takes affect. The force of the weight falling...
  • Page 5 14361 INSTRUCTION MANUAL DANGER Do not use Jack Stands as a permanent stand for the vehicle. Use them only while making repairs, then immediately lower vehicle to the ground. Removing the Jack Stands 1. Raise the vehicle with a floor jack to take the load off of the Jack Stands. 2. Remove Safety Pin from the Locking Pin. Remove the Locking Pin from the Post. 3. Lower the Post and remove Jack Stand from underneath vehicle. 4. Use the floor jack to safely lower the vehicle to the ground.
  • Page 6 14361 INSTRUCTION MANUAL Parts Breakdown Item: Part Number: Description: Quantity: 14361-001 Rubber Cushion 14361-002 Post 14361-003 Safety Pin 14361-004 Chain 14361-005 Locking Pin 14361-006 Base...
