Basketball Arcade Game
Jeu de Basketball Arcade
SP35202
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Scan QR code for
assembly instructions
Advertisement
Table of Contents
Related Manuals for Costway SP35202
Summary of Contents for Costway SP35202
- Page 1 GBR office: Ipswich FRA office: Saint Vigor d'Ymonville USA:cs.us@costway.com If you're having difficulty, our friendly AUS:cs.au@costway.com customer team is always here to help. GBR:cs.uk@costway.com THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. FRA:cs.f r @costway.com...
-
Page 2: Before You Start
1 x2 2 x2 3 x1 Tube-1 Tube-2 Tube-3 Before You Start Ø22x580x440mm Ø22x685mm Ø22x890mm Please read all instructions carefully. Retain instructions for future reference. 4 x1 5 x1 6 x1 7 x2 Tube-4 Tube-5 Tube-6 Tube-7 Separate and count all parts and hardware. Ø22x890mm Ø22x755x580mm Ø22x755x580mm... - Page 3 32 x1 33 x1 34 x2 Wrench Allen Key Self-Stick Strap PRE-INSTALLED PARTS P1 x2 P2 x9 P3 x2 P4 x2 Spring Lock Plastic Pole Lock Pin Insert ASSEMBLY INSTRUCTIONS: FIG.1 &2 1. Find a clean, level place to begin the assembly of your Basketball Game. We 3.
- Page 4 FIG.4 6. Attach the Tube - 5 and Tube - 6 (#5 & #6) to Tube - 3 and Tube - 4 (#3 & #4) using FIG.5 Bolts (#26), Washers (#22) and Nuts (#28), and then attach the Tube - 5 and Tube- 6 8.
- Page 5 FIG.7 11. Attach the Rim (#17) and Rim Support Plates (#18) to the Backboard (#21) using the Bolts (#23), washers (#22) and Nuts (#28). And then attach the Switch Sensors (#15) to the Backboard (#21) using the Bolts (#23), washers (#22) and Nuts (#28). Make sure that you use washers on both sides of the backboard as shown in FIG.7.
- Page 6 FIG.10 With the help of another adult, attach the Backboard (#21) to Top Tubes 1 (#1) with Bolts (#25), Washers (#22), and Nuts (#28) as shown in FIG.10A. Slide Tube 12 (#12) through the sleeve at the back of the Ball Return Net (#20), as shown in FIG.10B. At each bottom hole of the backboard, attach the left side first with Bolts (#25), Washers FIG.9 (#22), Nuts (#28) as shown in FIG.10C.
- Page 7 FIG.11 17. Attach the Control Box (#16) to middle of the Tube - 11 (#11) using two Bolts (#30) as shown in FIG.11A. 18. Run the rest of the Control Wire through the loops on the Ball Return Net (#20). Place the Control Wire on the Tube - 11 (#11) using the Self-Stick Straps (#34) as shown in FIG.11.
-
Page 8: Install Batteries
CHOOSE FROM 8 DIFFERENT GAME OPTIONS ELECTRONIC SCORER OPERATION 1. Beat the Time Clock Install Batteries Press "PLAY" to enter game 1. Battery Box: Unscrew bolt using a screwdriver and open the battery box. Insert 3 "AA" Press "UP/Down" to select single/multiple players (P1/P2/P3/P4). batteries (not included) in the order of polarity as shown on the inside cover. - Page 9 e. First player is allowed to shoot at any hoop (Home or VISITOR). If first player scores in 7. Left and Right Shoot 2 seconds, no letter is given. Press “PLAY" to enter game 7. Game continues for next player. Scoreboard will display "next player (P2P3/P4)" and Press "UP/Down"...
-
Page 10: Instructions De Montage
1 x2 2 x2 3 x1 32 x1 33 x1 34 x2 Tube-1 Tube-2 Tube-3 Clé Clé Allen Sangle auto-adhésive Ø22x580x440mm Ø22x685mm Ø22x890mm PIÈCES PRÉINSTALLÉES 4 x1 5 x1 6 x1 7 x2 Tube-4 Tube-5 Tube-6 Tube-7 Ø22x890mm Ø22x755x580mm Ø22x755x580mm Ø22x830mm P1 x2 P2 x9... - Page 11 FIG. 4C FIG.2 FIG.1 Verrou à ressort Verrou à ressort FIG. 4 FIG.1 & 2 3. Fixez les tubes-2 (#2) au tube-3 et au tube-5 (#3 et #4) à l'aide d'un verrou à ressort (préinstallé) comme illustré à la FIG.1. 4.
- Page 12 FIG. 5 FIG.6 Verrou à ressort FIG. 5A court Verrou à ressort FIG. 5B FIG.5 FIG.6 8. Fixez le tube-12 (#12) aux tubes-2 (#2) à l'aide des boulons (#24), des rondelles 10. Fixez les tubes-10 (#10) aux tubes-9 (#9) à l'aide du verrou à ressort (préinstallé), (#22) et des écrous (#28) comme illustré...
- Page 13 FIG.7 FIG.9A FIG.9B FIG.9 FIG.9C FIG.7 11. Fixez la jante (#17) et les plaques de support de jante (#18) au panneau arrière (#21) à l'aide des boulons (#23), des rondelles (#22) et des écrous (#28). Ensuite, fixez les capteurs de commutateur (# 15) au panneau arrière (#21) à l'aide des boulons (#23), des rondelles (#22) et des écrous (#28).
- Page 14 FIG.11 FIG.11A Boîtier de commande Fil de commande FIG.11 17. Fixez le boîtier de commande (#16) au milieu du tube 11 (#11) à l'aide de deux boulons (#30) comme illustré à la FIG.11A. 18. Faites passer le reste du fil de commande à travers les boucles du filet de retour de balle (#20).
-
Page 15: Installer Les Piles
FONCTIONNEMENT DU SCORE ÉLECTRONIQUE Installer les piles FIG.13 Boîtier à piles : dévissez le boulon à l'aide d'un tournevis et ouvrez le boîtier à piles. Insérez 3 piles "AA" (non incluses) dans l'ordre de polarité indiqué à l'intérieur du couvercle. Fermez ensuite le couvercle à l'aide d'un tournevis. Allumez l'alimentation à... - Page 16 4. Cheval CHOISISSEZ PARMI 8 OPTIONS DE JEU DIFFÉRENTES a. Appuyez sur "PL AY" pour entrer dans la partie 4. 1. Course contre la montre b. Appuyez sur "UP/Down" pour sélectionner plusieurs joueurs (P2/P3/P4). Appuyez sur "PLAY" pour entrer dans le jeu 1. C.
- Page 17 Une fois que le score atteint 10 points ou que le temps atteint 99 secondes, un compte à rebours de 5 secondes avant le tour du joueur suivant lorsqu'un joueur termine la partie. Le joueur qui termine la partie en premier gagne (le LED clignote sur le gagnant). Appuyez sur "PLAY"...
