Summary of Contents for DigitalHome Smart Lock LS100
-
Page 3: Special Attention
LOCK MANUAL Special Attention: 1. Mechanical keys please keep outdoor, just in case keys lock in doors. 2. Please charge for the battery when low wattage alarm. 3. Reading this manual carefully before installation, and keep it for future reference. www.digitalhome.ph... - Page 4 Lock Structure Door frame direction www.digitalhome.ph...
-
Page 5: Installation Diagram
Step 5 Install the Battery Step6 Install gusset Note： The distance should be controlled at about 2.5mm. If the distance is large, the lock tongue will not buckle the box If the spacing is small, the back panel will be stuck www.digitalhome.ph... -
Page 6: Specifications
Aluminum door Doors Applicable Wooden door Working Voltage 6V/4x AA Batteries Door Thickness to Fit 10-25MM 150 pcs passcode Data Capacity 200 pcs Card 200 pcs fingerprint -25℃-60℃ Working Temperature Working Humidity 20%-90% Low Wattage Alarm Less than 4.5V www.digitalhome.ph... -
Page 7: System Initialization
System Initialization Open the cover plate of the front panel ,long press the "Reset" button on the back panel for 5s, press “000#”,and the initialization is complete Registration www.digitalhome.ph... - Page 8 3) Register a new account (phone number or email) or login with an existing account. 4) Touch the lock screen to light, and click "+” Add Lock 5) The lock nearby will appear on the phone screen, Click "+" 6) Re-name the lock 7) The lock added successfully www.digitalhome.ph...
-
Page 9: User Management
2-4 You can set the effective time and effective number of → → passwords Generate password Input password to unlock. 5.2.6 Unlock records → Click " "as shown in finger 2-1 you can query your unlock record as shown in finger 2-5 www.digitalhome.ph... - Page 10 5.2.7 IC Cards management Click " " as shown in finger 2-1→Click " "→Add IC Cards as finger 2-6 www.digitalhome.ph...
-
Page 11: Packing List
Packing List Picture Name Front Pane Back Panel Strike Box Card Quantity 20MM 40MM 12MM Picture 30MM M4*12mm Screw*1 Screw Screw Screw Name M4*20mm M4*30mm M4*40mm Quantity 50MM Picture User Manual Name M4*40mm Mortise Screws:25*4mm Screw*1 www.digitalhome.ph...
