SCUBATECH

USER MANUAL

Demand regulators

Range of models

R2 TEC, R2 TEC O2, R2 TEC INT, R4 TEC

R4 TEC O2, R4 TEC INT, R5 TEC, V1 ICE

V1 ICE INT, V2 ICE, R1 PRO, R1 PRO O2

R1 PRO INT

REC1, REC1 O2, REC1 OCTO

TEC1, TEC1 O2, TEC1 OCTO

TEC2, TEC2 O2, TEC2 OCTO

Issue 2021/3

Table of Contents

Need help?

Do you have a question about the R2 TEC and is the answer not in the manual?

Questions and answers

Summary of Contents for TecLINE R2 TEC

Page 1 USER MANUAL Demand regulators Range of models R2 TEC, R2 TEC O2, R2 TEC INT, R4 TEC R4 TEC O2, R4 TEC INT, R5 TEC, V1 ICE V1 ICE INT, V2 ICE, R1 PRO, R1 PRO O2 R1 PRO INT...
Page 2: Table Of Contents
Demand Regulator User Manual Series models – R2 TEC, R2 TEC O2, R2 TEC INT, R4 TEC, R4 TEC O2, R 4 TEC INT R5 TEC, V1 ICE, V1 ICE INT, V2 ICE, R1 PRO, R1 PRO O2, R1 PRO INT...
Page 3: Introduction
Scubatech / Tecline demand regulators may be used only in the way presented in this user manual. Scubatech / Tecline demand regulator is a precise device. It must be used with care due to its essential function performed during diving. The guidelines contained in this manual must be followed to ensure the best efficiency and service life of this regulator.
Page 4 - in water temperature higher than 4 C (pressure reducers R2 TEC, R2 TEC O2, R2 TEC INT, R4 TEC, R4 TEC O2, R4 TEC INT, R5 TEC, V1 ICE, V1 ICE INT, V2 ICE and demand regulators TEC1, TEC1 OCTO, TEC1 O2, TEC2, TEC2 OCTO, TEC2 O2).
Page 5: Design And Basic Technical Data
The first pressure reduction stages of Scubatech / Tecline demand regulators (only models: R2 TEC, R2 TEC O2, R2 TEC INT, R4 TEC, R4 TEC O2, R4 TEC INT, R5 TEC, V1 ICE, V1 ICE INT, V2 ICE) are equipped with diaphragm, which protects operating environment of the high-pressure valve and other valve components against external conditions.
Page 6 The second pressure reduction stages of Scubatech / Tecline demand regulators are based on a standard relief pressure reducing system. They are equipped with a Venturi nozzle with a setpoint adjusted by a diver that allows delivery of maximum flow of breathing gases. Using an adjustable deflector that directs appropriately the breathing gas flow in combination with the Venturi nozzle substantially reduces the breathing resistance.
Page 7: Intended Use
Using demand regulators with nitrox mixtures outside the EU (European Union). Standard Scubatech / Tecline demand regulators sold to non-member EU countries are produced with the application of materials, assembly procedures and greases that ensure compatibility with nitrox mixtures of the maximum oxygen content of 40...
Page 8: Using In Cold Water
Demand regulators operating at low temperatures must be properly protected. Dry chamber used in pressure reducers R2 TEC, R2 TEC O2, R2 TEC INT, R4 TEC, R4 TEC O2, R4 TEC INT, R5 TEC, V1 ICE, V1 ICE INT, V2 ICE substantially decreases the risk of freezing.
Page 9: Preparing For Use
7. Preparing for use IMPORTANT Scubatech / Tecline recommends delivering a demand regulator to an Authorized Scubatech / Tecline Dealer for connecting accessories such as: pressure measurement device, medium pressure tubes and second pressure reduction stages of demand regulators. An Authorized Scubatech / Tecline Dealer may also answer to questions regarding the issues presented in these instructions.
Page 10: The Use During Diving
 before diving, perform a routine check of the demand regulator,  check all the demand regulator's connections for possible gas leaks,  check if the gas supplying the demand regulator is odourless,  push the diving regulator's purge button and check for air outflow that stops after releasing the button, ...
Page 11  only original spare parts must be used during repairs and checks,  demand regulators must have technical inspections carried out every year by an Authorized Scubatech / Tecline Service Technician,  inspection and maintenance of the demand regulator's assemblies together...
Page 12: Warranty
Scubatech / Tecline guarantees to the original buyer that its product is free of any defects in materials or workmanship provided that guidelines regarding the use, maintenance or service are observed pursuant to following conditions.
Page 13 WARRANTY CARD SCUBATECH demand regulator, pressure reducing valve, diving regulator SCUBATECH Ltd. warrants to the original owner proper operation of the demand regulator, pressure reducing valve and the diving regulator for a period of 10 years. This warranty card is valid under the following conditions: ...
Page 14 CONTROL INSPECTION CARD Serviceman's Technical condition Inspection date surname Signature and stamp assessment Page 14 / 15...
Page 15: Manufacturer Information
11. Manufacturer information SCUBATECH Ltd. ul. Lubieszyńska 2 72-006 Mierzyn Tel./fax: +48 914 530 017 e-mail: scubatech@scubatech.pl 12. Notes ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………... Page 15 / 15...
