Fluorescence Imaging
• Utilizes interchangeable professional fluorescence cubes
to create images compatible with most existing camera
systems.
• Much lower cost and smaller (more compact) than a tradi-
tional microscope.
• Field of view up to 9.2 mm with a 2/3" CCD in macro
mode.
• Micro mode utilizes professional infinity corrected objec-
tives.
• Remote UV light source includes a long-life metal halide
bulb.
• Zoom and fixed systems available. Fine focus included
with both systems.
Advertisement
Related Manuals for Navitar ZFL
Summary of Contents for Navitar ZFL
- Page 1 Fluorescence Imaging • Utilizes interchangeable professional fluorescence cubes to create images compatible with most existing camera systems. • Much lower cost and smaller (more compact) than a tradi- tional microscope. • Field of view up to 9.2 mm with a 2/3” CCD in macro mode.
- Page 2 • Art restoration. • Other non-destructive testing. http://machinevision.navitar.com Navitar Video Fluorescent Scope Navitar’s Video ZFL Scope is a Macro/Micro fluorescent vision system that utilizes inter- changeable professional fluorescent cubes and internal focus to create an image compat- ible with most existing camera systems. It is...
- Page 3 All other components are optics and mechanics that permit varia- tion of the magnification (field of view) and resolution, along with a means of achieving critical focus. The Navitar system is suitable for operation in either Macro or Micro mode. Macro Mode In the Macro mode, a fixed lens system provides up to a 9.2 mm...
- Page 4 ZFL System Diagram 1-6270 1-62922 Mounting Clamp 2X F-Mount Adapter 3-15818 Mounting Block Support 2-14048 Stand 8-16383 Olympus BX2 Mounted Filter Set Endow GFP Longpass Emission (Visit www.chroma.com for other filter options Micro Mode Objective Adapters 2-50026 2-51370 2-50025 0.800 x 36T M25 x 0.75T...
