SEIPO 25-30 PA.0112 DX-SX Assembly Diagram

Hide thumbs
1
2
3

Advertisement

Quick Links

Download this manual
Rev.
Emissione
00
Data
Date
Approvazione
03/11/2020
Ferramenta
Componenti
Hardware
Components
Spine in legno 8x30 (G)
Wooden pin 8x30 (G)
n°28
Tirante 7x33.5 (H)
Tie-rod 7x33.5 (H)
n°15
Grano 8x8 (I)
Threaded screw 8x8 (I)
n°15
Barilotto 14x14 (L)
Barrel 14x14 (L)
Piedini regolabili diam.=35 (U)
n°15
Basetta (M)
Hinge base (M)
Serratura (V)
n°4
Cerniera (N)
Hinge (N)
Chiave esagonale
n°4
Reggipiano (O)
Shelf support (O)
n°4
Bullone 4x25 (P)
Bolt 4x25 (P)
n°4
Maniglia (Q)
Handle (Q)
n°4
Vite 4x16 (R)
Screw 4x16 (R)
n°10
Bullone da 6x28 (T)
Bolt 6x28 (T)
n°4
Issuance
Schema di montaggio
Approval
Piano (A)
Top (A)
Ante (E)
Doors (E)
Adjustable feet diam.=35 (U)
n°6
Lock (V)
n°1
Hexagonal key
n°1
Assembly diagram
Fianchi (B)
Sides (B)
Retro (F)
Back
panel (F)
25-30 PA.0112 DX-SX 160x80x73
25-30 PA.0113 DX-SX 180x80x73
25-30 PA.0114 DX-SX 200x80x73
Base-cappello
(C)
Base-top (C)
Fianco (J)
Side (J)
Ripiano (D)
Shelf (D)
Traversa (K)
Cross panel
(K)
