｢ Please read in advance for your safety｣

In order to use the machine safely and efficiently, be sure to read this manual

thoroughly before use.

(If it is lost, it must be purchased separately. Be careful with storage.)

The product warranty is written in this manual. The appearance and specifications

of the product are subject to change without prior notice for product improvement.

Manual

HS-1000FS

Hydraulic detachable multi-purpose vehicle

HANSEO PRECISION INDUSTRY CO.,LTD

A/S Tel +82 41) 529 3065

Fax +82 41) 529-3005

- 1 -

Table of Contents

Need help?

Do you have a question about the HS-1000FS and is the answer not in the manual?

Questions and answers

Summary of Contents for HANSEO HS-1000FS

Page 1 HS-1000FS Hydraulic detachable multi-purpose vehicle ｢ Please read in advance for your safety｣ HANSEO PRECISION INDUSTRY CO.,LTD A/S Tel +82 41) 529 3065 Fax +82 41) 529-3005 In order to use the machine safely and efficiently, be sure to read this manual thoroughly before use.
Page 2: Table Of Contents
4) Maintenance tips 6. First aid measures 7. Vehicle inspection We sincerely thank you for always using Hanseo Precision Co., Ltd. In order to use it safely and efficiently, please read the instruction manual to the end before use,...
Page 3: Safety Work
1. Safety work Failure to observe the precautions described here may result in injury, accidents, or damage to machinery, including death. Before driving, read these precautions and the markings attached to the machine carefully, and follow these instructions to ensure safe and comfortable work.
Page 4 When lending a machine to another person, explain how to handle it. When lending or transferring the machine to a person other than the user, give this instruction manual together, explain how to use it, and instruct them to read the instruction manual. Incorrect usage will cause accidents.
Page 5 get caught in a rotating object, or slip and fall. 4) Machine modification No mechanical modification Modification of the machine is strictly prohibited. Do not modify. When replacing parts for consumables or repairs, be sure to use our genuine parts. Please purchase and use.
Page 6 When inspecting and cleaning each part, fix the wheels in a flat, hard place, stop the engine, and run. Failure to do so may lead to accidents, injuries, breakdowns and overturns.y lead to accidents, injuries, breakdowns and overturns. Inspection and cleaning should be performed after the overheated part has cooled down.
Page 7 Refueling and refueling are performed after the engine has cooled down. Never open the fuel cap, refuel or refuel while the engine is running or when the engine is hot. Failure to comply will lead to fire. Watch out for fuel leaks. Because the fuel hose is made of rubber, it may be damaged by UV rays, etc.
Page 8 8) Attention when working Pay attention to obstacles in all directions when working. When working, pay attention to obstacles (slope, cliff topography) in all directions. Failure to do so may result in serious accidents, resulting in death, injury, or machine breakdown. Damage occurs.
Page 9 Incorrect usage is the cause of an accident. If you do not understand how to operate with great care and know how to operate without embarrassment, you will not be able to make appropriate judgments in an emergency, and risk avoidance is impossible. This can lead to deaths, injuries and machine breakdowns.
Page 10 When driving slope, when preventing preventing quarantine, reduce the speed sufficiently. Failure to do so may lead to a fall, fall or damage to the machine. On slopes, do not put a full amount of fuel in the fuel tank. When using the machine on a slope, fuel may overflow, so use it without full fuel (two-thirds is appropriate).
Page 11: Name Of Each Part
2. Name of each part ① Outrigger ④ Engine room ② Water tank ⑤ Door ③ Fan ⑥ Remote control - 11 -...
Page 12: Handling And Operation Of Each Part
3. Handling and operation of each part 1) Prevention and control equipment (1) Water tank -The water tank is made of special FRP (synthetic resin), so it can be used permanently due to its strong impact and corrosion resistance. -In the water tank, a strainer and a stirrer were installed to enable the control work.
Page 13 (7) Pump room -It protects key parts and equipment of the vehicle, keeps the user's safety when operating the machine, and prevents outsiders from approaching, freezing in winter, and the inflow of foreign substances. -It is designed to allow easy inspection and maintenance with a structure that opens three sides.
Page 14 ◆ Fire extinguishing and control work through hose reel ◆ Before turning pump switch, check safety, interference, and direction of valves, hoses and nozzles before use. 2. Be sure to turn off the pump switch and turn off the ignition key after finishing the work to prevent discharge.
Page 15 replaced. -If there is insufficient oil in the crankcase oil gland, it is safe to add oil. 2. Unscrew the high-pressure hose wrapped around the reel, install the spray device (nozzle), and open the valve to spray water. 3. A pressure regulator (regulator) is attached to the GX-100A high-pressure pump to adjust the pressure and instantly remove the pressure in case of an emergency.
Page 16 Please be sure to check. ※ In winter, drain water from the tank, etc., and run idle for 20 to 30 seconds to drain the water remaining in the pump and piping to prevent freezing. ◆ How to use the pump for quarantine work. ◆ 1.
Page 17 power through the D.C motor and the electronic clutch and turning on the switch. (3) For safety, the power unit is designed to automatically slip when certain force applied protect workers, hoses equipment. -When unwinding and winding the hose, it is safe to use it when the pump is stopped and there is no pressure in the hose.
Page 18 higher temperatures are in the dangerous range. (2) Against foreign matter, air, and moisture Hydraulic equipment is composed of a combination of precise rotational parts, perturbation parts, tight contact parts, and minute gaps, so if foreign substances are mixed, the function will immediately deteriorate or become inoperative.
Page 19: Operation Steps
4. Operation steps ① Engine operation - Start the vanguard engine from the main board (instrument panel) or remote control. - While using the pump, use the RPM control switch on the main board to adjust the output. - After use, be sure to turn off the engine in reverse order. ②...
Page 20 ③ Side nozzle -Turn on the engine from the remote control and set it to an appropriate RPM. Turn on the side nozzle and high pressure pump switch on the remote control. -Turn off the engine in reverse order after use. ④...
Page 21 실린더 수축 실린더 신장 전방 후방 아우트리거 매뉴얼밸브 ⑤ Reel hose -Turn on the engine from the main board or remote control and adjust the RPM to an appropriate level. -Turn on the high pressure pump switch. -Open the valve connected to the reel hose. -Turn off the engine in reverse order after use.
Page 22: Inspection And Maintenance
5. Inspection and maintenance 1) Inspection of each part (daily inspection) ※ For inspection and maintenance of the vehicle and the control unit, be sure to turn off the engine and apply the parking brake on a flat terrain. check list Check contents 1.
Page 23 2) Inspection before starting the engine (1) oil leak Make sure there are no oil spills or traces of oil under this machine. (2) the amount of oil in the engine If the engine oil is insufficient, the engine may become crushed or damaged, causing a serious accident.
Page 24 -The fuel for this machine is unleaded gasoline for automobiles. -Do not use similar gasoline or modified gasoline. -Never open the fuel cap or refuel while the engine is on or when the engine is hot. -When fuel is injected, securely close the fuel cap and wipe off excess fuel.
Page 25 3) Inspection after engine start (1) Do not check while the engine is started. Contact with the rotating parts such as the engine rotating part belt may result in an injury that may be caught or caught. In addition, it is dangerous because there is a risk of electric shock (shock) if it touches the electric system of the spark plug.
Page 26 4) Maintenance tips (1) belt Maintain the belt tension so that the width is 8-12mm when pressed with a 10kg load as shown in the figure below. If the tension is loose, the belt will slip. (2) GX-100A high pressure pump Check whether the amount of oil is appropriate through the oil gauge (oil gauge) attached to the crankcase cover (rear part of the pump).
Page 27: First Aid Measures
6. First aid measures 1) When the blowing engine does not start (1) Check if the fuel and lubricant are adequate. (2) Check the wiring of the fuse and ignition key. (3) Check if the start motor wiring is disconnected. (4) Check if the battery terminal is too loose and tighten it sufficiently.
Page 28 4) When the ventilator is operated up and down and the fan does not work (1) Check if the coupling between the engine and hydraulic pump is damaged. (2) Check the operation of the solenoid valve connected to the hydraulic hose (check the lamp). (3) Check that there is no abnormal noise, overheating or vibration from the hydraulic pump.
Page 29: Vehicle Inspection
7. Vehicle inspection For safety, we check before driving once a day. check list Check contents Check for ⦁Is the part where there was an abnormality abnormalities when driving the previous day? ⦁ Is it easy to start and is there sufficient fuel, engine oil and coolant? ⦁...
Page 30 1. If you load water in a vehicle and drive it at more than 60km/h, the vehicle may overturn due to the ripples of the water, so please proceed slowly. 2. Be careful that the brake braking distance is longer than usual when the vehicle is loaded with water.
