IMMOTOR PORTABLE
POWER STATION
BAY500
PRODUCT MANUAL
Type-c
USB-A
LIGHT ON/OFF
ON/OFF
DC ON/OFF
DC OUTPUT
DC INTPUT(12-28V)
* It is a portable energy storage power supply, DO NOT let children play.
* Please read the product instructions carefully before using.
* If it is stored for a long time (more than a month), please charge the product to about 70% of the electricity.
* Do not charge, use or place the product near the source of fire or overheating.
* Products and accessories are subject to change without notice.
Advertisement
Summary of Contents for IMMOTOR BAY500
- Page 1 IMMOTOR PORTABLE POWER STATION BAY500 PRODUCT MANUAL Type-c USB-A LIGHT ON/OFF ON/OFF DC ON/OFF DC OUTPUT DC INTPUT(12-28V) * It is a portable energy storage power supply, DO NOT let children play. * Please read the product instructions carefully before using.
-
Page 2: Table Of Contents
CATALOG 1. Product introduction 2. Product diagram 3. Product parameters 03 - 04 4. Operating instruction for the products 5. Precaution 07 - 08 6. Solution for the common problems 08 - 09 7. Trouble shooting 8. Package Contents... -
Page 3: Product Introduction
1. Product introduction This product is a portable multi-functional power source that can store energy, and it is equipped with high-efficiency power lithium-ion battery, safe lithium battery management system (BMS), high-efficiency energy conversion circuit, and it is wrapped by high-strength aluminum alloy with refined leathered handle. The top design and mature production control, the products are safe and reliable, which can be powered by solar power, vehicle power generation, and electric supply charging. -
Page 4: Product Diagram
USB-C PD 100W output port * 2 USB, DC, AC, LED light switch Wireless charging Intelligent Ambient Light AC output socket * 2 (with cover) 3. Product parameters Project Parameter BAY500 Battery class Lithium ion battery Battery capacity 542.9Wh Battery Cycle life 1000 cycles... -
Page 5: Operating Instruction For The Products
USB-A QC3.0, 18W (MAX) USB output USB-C PD 100W (MAX) Wattage LED light Adapter 20-22V, 5A 13V8A Charge 18V/100W Net weight 13lb (TBD) Product weight Gross weight 7.5KG (TBD) Host 9.5*7.8*6.2inch Product volume Packing 12.7*10.2*9.2inch Charge 0-45℃ （32~113℉） Temperature Discharge -20~60℃... - Page 6 4.1.2 Adapter charging STEP 1. Insert the adapter AC input plug into the electric supply. STEP 2. Insert the adapter DC output plug into the “DC input” interface, when charging is started, the system will automatically detect the input power, the remaining time will change dynamically, which is normal.
- Page 7 check whether the peripheral electrical equipment exceeds the power or short circuit occurs, restart the machine to check whether there is power. After the power is used up, in order to save the power, please manually shut down the machine after using, if there is any malfunction, please contact the manufacturer or dealer.
-
Page 8: Precaution
5. Precaution Please read the precautions that indicate “Danger”, “Warning” and “Caution” levels. “Danger” indicates it will cause the personal Danger injury. “Warning” indicates it will happen the dangerous Warning things. “Caution” indicates it will cause the damage to Caution the product or shorten the service life. -
Page 9: Solution For The Common Problems
· Q：How long does it take to fully charge the product? A： BAY500 can be charged to 80% in 3 hours with the standard adapter+type-c; · Q：Can the product be discharged while being charged (output used)? -
Page 10: Trouble Shooting
A：This product supports discharging while charging, and it can be used at the same time. When the output power is greater than the input power, the battery power is slowly reduced, and when it is reduced to the low battery state, the output is turned off. -
Page 11: Package Contents
(2) Check if the current device has started temperature protection because the temperature is too high or too low. 8. Package Contents Name Accessories description Portable Powerstation IMMOTOR BAY500 Adapter Charging products with municipal electricity Power cord Adapter to connect to city power Car charger cable... - Page 12 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 13 IC Caution: ’ This device complies w it h Indust ry Canada s licence-exempt RSSs. Operat ion is subject to t he follow ing t wo condit ions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference t hat may cause undesired operat ion of t he device.
- Page 14 CONTACT US Shenzhen Immotor Technology Co., Ltd. Web: www.immotor.com E-mail: support@immotor.com Add: T1-Building 12/F, Qianhai Kerry Business Center, Shenzhen, China MADE IN CHINA...
