Alvey 62G4 Quick Start Manual

Key Part Description
1 R6B10 Spindle Tension Knob
2 R6C7 Spindle Spring
3 R6D4 D Washer
4 R6T1 Nitrile Washer
5 R6R2 Fibre Washer
6 R4F15 Handle Assembly
7 R4H2 Handle Plug
8 R4E15 Handle Screw
9 R4D7 Handle Only
10 R4B Spool with Handles
11 R5B4 Fish Alert Cog
12 R6A20 Spindle
Key Part Description
13 R6R2 Fibre Washer
14 R1A Back Plate Assembly
15 R5H2 Fish Alert Spring
16 R5E10 Fish Alert Button
17 R2G12 Base Lock Spring
18 R6F3 Spindle Dome Nut
19 R2D2 Base Bolt
20 R2A1 Base Plate Assembly
21 R2L1 Base Washer
22 R2F1 Base Bolt Nut
23 R2H1 Base Lever & Rivet
62G4
CONGRATULATIONS and thank you for purchasing one of our Australian
made graphite backed reels as your choice of fishing reel.
reels are constructed from the highest quality materials to ensure your
reel will last for many years.
Plus, all these other
advantages -
Long, accurate casts:

Special Features

Now, with only the minimum
of practise you will be able to
→ Graphite Back
cast further and more
accurately than ever before.
→ Direct Wind
Control large fish with
→ Metal Side Cast
ease: Powerful one-to-one
wind means you only need
System
about a quarter of the effort
required to lift a similar
→ Fish Alert
weight on a spinning reel.
→ High Recovery
You can fish harder and
shallow Fiberglass
longer: Simple, rugged
construction means you can Spool with
forget that fiddly
Stainless Steel
Maintenance, because your
Bush
Alvey reel will resist the
effects of saltwater and
sand.
Reel Icon Pty Ltd Trading as
Alvey Reels Australia ABN 57 625 261 707
2-6 Antimony Street Carole Park Qld 4300
t: +61 7 3271 2844 f: +61 7 3271 2451
These
More comfortable fishing:
Low winch-mount rods let you
fish with your arms in a
relaxed position.
No line twist: Use a small
free-running swivel as the last
piece in any rig and you'll
minimise any line twist.
(See illustrations inside)
Alvey 10 Year Guarantee:
Any faulty Alvey part or reel
will be replaced at no charge
providing the manufacturer
finds the part or reel has had
normal usage and attention.
For more hints and tips on maintenance,
please visit the spare parts page at
www.alvey.com.au
