BOWMAN BD206-0012 Assembly Instructions

Product Description:
• Kit Includes:
- RS005-0512 Respiratory Hygiene Station - Locking
◦ Holds two boxes of face masks, one or two boxes
of facial tissues or one box of gloves, and one hand
sanitizer dispenser
◦ Made of Quartz Beige Powder-Coated Aluminum
- MP-075 Sign Holder - Horizontal
◦ Holds 11" x 8.5" signage horizontally (Cover Your
Cough signage can be downloaded at
www.BowmanDispensers.com)
◦ Made of Clear PETG Plastic
• All hardware included for assembly as a free standing unit
Primary Area for Product Usage:
• Emergency and admitting departments, all ports of entry,
outpatient radiology/MRI, outpatient labs and pharmacies
Dispenses:
Respiratory Hygiene Station holds most brand name boxes:
• Two boxes of face masks up to 7.75"W x 5.00"H x 4.75"D
(19.7 cm x 12.7 cm x 12.1 cm)
• One large or two small boxes of tissues or one box of gloves up
to 5.50"W x 10.00"H x 4.75"D (13.7 cm x 25.4 cm x 12.2 cm)
• One hand sanitizing gel or foam dispenser - mountable
area 8.35"W x 14.75"H x 5.00"D (21.2 cm x 37.5 cm x 12.7
cm) [Note: Refer to automatic dispensing specifications on
detection distance requirements.]
Product Specifications
(overall assembled dimensions)
• 22.3"W x 21.9"H x 5.0"D (56.5 cm x 55.7 cm x 12.7 cm)
• 5.4 lbs (.4 kg) - approximated
Package Specifications:
• Package Quantity: 1 complete kit per case
• 24"L x 16"W x 6"H (61.0 cm x 40.6 cm x 15.2 cm)
• 8.0 lbs (3.6 kg) - approximated
BD2060012TDSc
Information subject to change without notice. Consumables not included.
© 2017 BOWMAN® Manufacturing Company, Inc. All rights reserved.
Sanitizer, face masks,
and tissues not included
Mounting Specifications:
:
BD206-0012
Cover Your Cough Compliance Kit
1.33 Ø.19 (2x)
Ø.13 (2x)
BOWMAN Manufacturing Company, Inc.
20325 71st Ave NE, Suite D, Arlington, WA 98223
T 1.800.962.4660 • F 360.435.7426
1.65
10.05
www.BowmanDispensers.com
