LUBRICATION
The parts shown in the assembly for proper
operation of your air tools are identified as
follows:
1. Air filter.
2. Regulator.
3. Lubricator.
4. Emergency shut-off valve.
5. Hose diameter.
6. Thread size.
7. Coupling.
8. Safety Air Fuse.
9. Oil.
10. Grease (During assembly).
TECHNICAL DATA
SQUARE DRIVE
AIR CONSUMPTION
RECOMMENDED AIR PRESSURE
AIR INLET
HOSE INTERNAL DIAMETER
NO LOAD SPEED
MAXIMUM TORQUE
WEIGHT
E N G L I S H •
48h
90 psi
PI612
1" (25,4 mm)
11,6 CFM
90 PSI
1/2" NPT
3/8" NPT
4 000 r/min
1 400 lb-ft (1900 Nm)
19 kg (40 lb)
U se r ' s m an ua l
24h
