CONTENTS:
A
x1
Enclosure
INSTALLATION:
1.Removing enclosure top :
B
1A. Align the security star keys x2 (D) and insert it
one in the front screw (B) and one in the Back
screw (C) as shown.
A
1C. Separate front part of enclosure (A) as shown.
Acrylic Security VESA Enclosure
PAD-ASVEB / PAD-ASVEW
INSTALLATION - MANUAL
D
B
Flat Head
Star Screw
x4
C
Rounded Head
Star Screw
x4
B
1B.While holding the back security star key (D) tight in
place Turn the front security star key (D) counter
clock-wise until all 4 Screws(B) are unscrewed.
D
Security
Star Key
x2
D
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CTA PAD-ASVEB
Summary of Contents for CTA PAD-ASVEB
- Page 1 Acrylic Security VESA Enclosure PAD-ASVEB / PAD-ASVEW INSTALLATION - MANUAL CONTENTS: Flat Head Star Screw Rounded Head Security Enclosure Star Screw Star Key INSTALLATION: 1.Removing enclosure top : 1A. Align the security star keys x2 (D) and insert it 1B.While holding the back security star key (D) tight in...
- Page 2 2.Inserting the tablet : 2A. Using one of the compatible listed tablets, insert into the foam adapters for a secure and tight fit.Insert tablet in back part of enclosure (A) as shown. Watch out orientation of tablet. 3. Attach enclosure top : 3A.
