Command Light Please take the time to read this manual before installing or operating the Traffic Flow Board. Save this guide for future reference. CONTENTS COMMAND LIGHT ..................................1 1. BREAKAGE OR DAMAGE DURING SHIPMENT ........................ 3 2. GENERAL DESCRIPTION AND SPECIFICATIONS......................4 3. -
Page 3: Breakage Or Damage During Shipment
User Guide 1. Breakage or Damage During Shipment The transportation company is fully responsible for all shipping damage and will resolve problems promptly if you handle it correctly. Please read these instructions carefully. Examine the contents of all shipping cases. If you find any damage, call your transportation agent at once and have them make a description on the freight or express bill describing the damage and the number of pieces. -
Page 4: General Description And Specifications
Command Light 2. General Description and Specifications The COMMAND LIGHT Traffic Flow Board LIFT is designed to provide the means to elevate a high-intensity light bar for emergency scene lighting with quick precision. As with any electromechanical device, take precautionary steps to assure safe operation. -
Page 5: Operation
“on” position to actuate the unit. The TRAFFIC FLOW BOARD has an override system that precludes rotation of the light bar until the lower stage has elevated ≈24” from the nested position. When the lower stage is below 24” a... -
Page 6: Installation
All safety precautions must be thoroughly understood before installation. Please consult the factory for additional installation information assistance. Installation Kit Included with the TRAFFIC FLOW BOARD is an installation kit. Verify that the contents of the kit includes the following items: (1) Pre-wired controller box with pocket... -
Page 7: Mounting
Slowly lift the TRAFFIC FLOW BOARD and check for balanced lifting. Lower and make any necessary adjustments to the lift points. Lift and place the TRAFFIC FLOW BOARD into position above the spacers. Before placing the full weight of the unit on the spacers, align spacers with the holes in the end frame. -
Page 8: Control Box Pocket Mounting
8. Power Failure The TRAFFIC FLOW BOARD can be retracted manually if power to the unit is lost. If power loss is temporary, reestablishing power may be easier than manually retracting the lift. If this is not feasible it is recommended that you disconnect 12VDC power sources from the TRAFFIC FLOW BOARD before proceeding. -
Page 9: Retract The Lift Arm
User Guide Using a 3/4 inch wrench or other suitable tool remove the upper pivot bolt from the main assembly. Manually rotate arrow board to the centered position. Secure arrow board using elastic stretch cords or other suitable means. Retract the lift arm. Support the lift arm with temporary blocking to relieve the tension on the actuator pivot pins. -
Page 10: Parts Breakdown
Command Light 9. Parts Breakdown USER-GUIDE_Traffic_Flow_Board.doc... -
Page 11: Technical Specifications
User Guide 10. Technical Specifications Dimensions, without board: Height(Depth) Length Width 7.5” 47” 23” Retracted 40” 52” 23” Extended 5” 52.5” 24” Minimum Recessed installation Weight: 136 pounds Wiring: 12 VDC 12/2 PVC jacketed cord Operation 14/18 PVC jacketed cable Control wiring 22/20 PVC jacketed cable Relay protection:... - Page 12 Command Light USER-GUIDE_Traffic_Flow_Board.doc...
-
Page 13: Wiring Schematic
User Guide 11. Wiring Schematic Last printed 1/3/2006 9:23:00 AM... - Page 14 Command Light USER-GUIDE_Traffic_Flow_Board.doc...
-
Page 15: Limited Warranty
COMMAND LIGHT at the above address indicating the model number, serial number and type of defect. No parts or equipment will be received by COMMAND LIGHT for repair or replacement under this warranty without specific written authority from COMMAND LIGHT in advance.
