Field Installation Guide for RFMAX "Meter-Max" Antenna, magnetic mount and coaxial connector.
*Always begin by powering down your mobile data collector/vehicle gateway base station*
1. Place the RFMAX magnetic antenna mount in the center of your vehicle roof. (Note: If your vehicle has an aluminum
body, then use an RFMAX adhesive steel mounting plate, part # RASP4x4)
2. Secure the RFMAX "Meter-Max" antenna to the magnetic mount by properly seating it on the threads and turning
clockwise until the base of the antenna is secured tightly against the magnetic mount.
3. Route the coaxial cable from the roof through a bulkhead gland in the vehicle body or through a window or door into
the vehicle cabin.
4. Use the coaxial connector chart to identify which connection you require for mobile data collector/vehicle gateway
base station. See chart below.
Pay attention to the center pin – they can be confusing!
5. Take the proper coaxial adapter and install it on your mobile data collector/vehicle gateway base station and hand-
tighten.
6. Connect the coaxial cable to your mobile data collector/vehicle gateway base station via the coaxial adapter and
hand-tighten.
7. Power up your mobile data collector/vehicle gateway base station and hand-tighten.
8. Start your drive-by collection with the additional power and ruggedness of your Meter-Max!!!
For the latest datasheets and installation guide, follow this QR code to our website:
To order the antenna kit, follow this QR code:
See next page for Cable Connection Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Meter-Max and is the answer not in the manual?

Questions and answers

Summary of Contents for RF-Max Meter-Max

  • Page 1 RFMAX adhesive steel mounting plate, part # RASP4x4) 2. Secure the RFMAX “Meter-Max” antenna to the magnetic mount by properly seating it on the threads and turning clockwise until the base of the antenna is secured tightly against the magnetic mount.
  • Page 2 COAXIAL CONNECTOR CHART WITH IMAGES If your mobile data collector / vehicle Then attach this coaxial adapter… gateway base station has this connector… RSF: Reverse-Polarity SMA Female RSM: Reverse-Polarity SMA Male Has Center Pin RTF: Reverse-Polarity TNC Female RTM: Reverse-Polarity TNC Male Has Center Pin SNF: Standard N Female SNM: Standard N Male...
