- Page 1 LEXA SUPERIOR WHIRLPOOL OWNER'S MANUAL...
- Page 2 Safety, Operation, Maintenance, And Warranty Safety Guidelines This manual contains information for YOUR SAFETY and will also help in PREVENTING PROBLEMS. To help you recognise these items of importance, this document uses the following symbols. PLEASE read the manual and pay special attention to these sections.
- Page 3 SAVE THESE INSTRUCTIONS! Urgent Safety Information DANGER ! A Hazard That Will Cause Serious Injury Important Safety Information WARNING A Hazard That Might Cause Serious Injury Information To Prevent CAUTION Damage To Equipment Important Instructions and References Owner's Record Date of Installation: Model: Name of Installer: Serial/ Invoice No.:...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS Basic precautions to be taken to prevent fire hazards, electrical shocks, personal injury or damage when using your unit. READ AND FOLLOW ALL INSTRUCTIONS! DANGER ! READ AND FOLLOW ALL INSTRUCTIONS • Risk of lethal electric shock in Hydroelectric product. To reduce risk of electric shock, connect your product only to circuits protected by a Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device (RCD)-sensitivity not more than 30 Milliamp (mA) •...
- Page 5 WARNING IMPORTANT SAFETY INFORMATION • Persons under a doctor's care, pregnant women, persons with high or low blood pressure, heart disease, diabetes, or any serious illness, should not use this unit without prior consultation with their physician. Never use this unit while under the influence of any drug or alcohol. •...
- Page 6 Dear Product Owner, Thank you for choosing an Artize product. The minute you sit back and relax in your new product you'll see and feel the difference. In your whirlpool, jets are strategically placed to create a soothing, swirling flow of relaxing water.
-
Page 7: Table Of Contents
CONTENT Whirlpool Specifications------------------------- 07 Artize Whirlpool Components-------------------- 17 Product Dimensions----------------------------- 08 Skirt With Removable Panel-Field Installed----- 18 LEXA superior Bathtub With Ms Frame Ecu Terminal Connection Diagram-------------- 19 LEXA superior Bathtub 190 X 140 With Superior Whirlpool Operating The Controls-------------------------- 20... -
Page 8: Whirlpool Specifications
Chromotherapy Yes (2) WARRANTY Headrest Body 5 years Overflow Cum Filler Electrical 2 years Keypad Jets 5 years Power Rating (Max) 3.55KW LEXA SUPERIOR WHIRLPOOL (ARTIZE190X140) S. No. DESCRIPTION REMARKS Packing Weight 120Kg Dry Weight 95Kg Water Capacity (Ltr) 580Ltr... -
Page 9: Product Dimensions
PRODUCT DIMENSIONS LEXA SUPERIOR BATHTUB WITH MS FRAME ABT-WHT-LEXA190FX : ARTIZE LEXA 1900 x 1400 X 530 BUILT-IN BATHTUB WITH POWDER COATED MS FRAME Top View Side View... -
Page 10: Lexa Superior Bathtub 190 X 140 With
LEXA SUPERIOR BATHTUB 190 X 140 WITH SUPERIOR WHIRLPOOL AWL-WHT-LEXA190CX : ARTIZE LEXA 1900 x 1400 X 530 SUPERIOR WHIRLPOOL AND AIRPOOL COMBI SYSTEM Top View Side View... -
Page 11: Installation Legend Diagram
Legend for installation or product placing Area for drainage sunken in floor. Area for hot water pipe outlet from the house. Water mains in case ARTIZE taps are installed on tub edge Area for cold water pipe outlet from the house.Water mains in case ARTIZE taps... -
Page 12: Pre-Installation Requirements
PRE-INSTALLATION REQUIREMENTS Tools for Installation Tools Required For Installation: (Not Included) Safe use of tools: Drill • Wear safety glasses or a face shield (with safety glasses or goggles) and well-fitting 3/16" gloves for safety. Drill Bit • Ensure that users are properly trained in the Pencil safe use of hand tools. -
Page 13: Before You Start
Before You Start Earth Wire The earth wire must be connected and fixed permanently IMPORTANT: Observe all governing codes with a 3 mm dia. core conductor to the electrical system. and ordinances. Electrical Supply and safety devices. Proper installation is your responsibility. Ensure a qualified/Jaquar technician installs your product. -
Page 14: Installation Procedure
INSTALLATION PROCEDURE Place your whirlpool/bathtub on flat surface & check level for water flow towards drain. Water drain may be adjusted by leg adjustment Pictures used above for reference only. For product placement check dimensions of required model. - Page 15 Connecting drain pipe : Use a flexible pipe of diameter 40 mm - not supplied with the product. Fill a minimum 4 litres of water in the bathtub to check proper drain flow Pictures used above for reference only. For product placement check dimensions of required model.
-
Page 16: Electrical Supply And Safety Devices
It is recommended that the product be kept filled for 24 hours to check for leakages in plumbing/drain connections. Electrical supply and safety devices The equipment must be connected to single phase 220 ~ 240 V and 50hz supply. The equipment must be connected to the equipotential/ differential switches of the room and duly fastened to the specified clamp/ terminals that can be found on the product. -
Page 17: Components Identification
Component Identification These drawings represent only the major components of the system; the position of the components may vary depending on the bath model. These pictures represent Combined Systems; Whirlpool Systems components are identified with “Component Identification”. AIR JET WATER JET DIVERTER KNOB DRAIN KNOB REGULATOR KNOB... -
Page 18: Artize Whirlpool Components
PATENTED WHIRLPOOL JETS Artize Whirlpool Bathtubs are not ordinary jetted tubs. Jet location in our tubs is designed to give you the very best in whirlpool bathing. The nozzle is directionally adjustable and swivels over a 30°... -
Page 19: Skirt With Removable Panel-Field Installed
FILLER/ MIXER AND HAND SHOWER Not standard package items.Designed for convenience and functionality and installed by Artize on requirement. The shower is non-adjustable and set on full spray stream. Turn knob of diverter to change from tub fill to handshower. -
Page 20: Ecu Terminal Connection Diagram
ECU TERMINAL CONNECTIONS DIAGRAM WHIRLPOOL CONTROL TYPE 240 9028A - S90 S1 S2 S3 S4 56 57 58 59 60 61 62 mains voltage supply Vcc2 common D5 D6 D7 disinfection Jumper filling filling J56 J7 J58 J59 J60 J61 J62 heater light Vcc1... -
Page 21: Operating The Controls
OPERATING THE CONTROLS Touchpad with 1 Button (Light Air Jet (+/-) Water Jet (+/-) Filler First press of button Switching on the colourlights Second press of button Stop-function of the colour wheel Third press of button Switching off the colourlights Keep button pressed Change into mode. -
Page 22: After Blow Or Dry Out Function
After Blow or Dry Out function ELECTRONIC CONTROL Artize whirlpool and systems Note: The system stops automatically after 20 minutes. Advanced function: A one-minute drying cycle starts up 20 minutes after complete stoppage of the blower (Air system). -
Page 23: How To Use Your Whirlpool
HOW TO USE YOUR WHIRLPOOL BEFORE TAKING YOUR FIRST BATH, READ AND APPLY THE "IMPORTANT SAFETY INSTRUCTIONS". To reduce the risk of injury, do not permit children to use the oxypool unless they are closely supervised at all times. Those requiring supervision for any reason, should never be allowed to use the whirlpool unattended. -
Page 24: User Maintenance Instructions
A drop or two of a biodegradable liquid soap will cover you and the tub with bubbles. Most people enjoy having a few bubbles floating around them. Artize does not recommend using use oil based products because the oil will settle in the whirlpool system. The oil can also create an environment conducive to bacterial growth. -
Page 25: Troubleshooting
TROUBLESHOOTING Whirlpool System Pump is not functioning smoothly • Adjust jet nozzle direction • Unscrew the filter from the suction fitting and clean. Never obstruct the suction filter • Make sure that pipe connections to the motor are tightened enough (tighten by hand) •... -
Page 26: Air System
AIR SYSTEMS BLOWER DOES NOT TURN ON • Make sure that the electric connection between the pump, electronic box and the electronic control panel is well established and that all fuses are functional. Reconnect if necessary • Verify that electricity is supplied to blower via electronic unit and circuit breaker/safety device (i.e. RCCB/GFCI Breaker) Blower operates, but no air is coming through certain jets •... - Page 27 Save this manual for future reference NOTICE FOR INSTALLER: Owner's Manual shall be left with the home owner or with the tub after installation. Important safety instructions, warranty information and the product registration card are contained within. TAPE THIS PACKET TO THE TUB OR LEAVE IN AN OBVIOUS PLACE...
- Page 28 NOTES:_________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________...
- Page 29 For any installation and maintenace related enquiry please call Customer Care at 1800 121 6808 (Toll Free) or email us at info@artize.com...
- Page 30 Rev. No.: 23-10-21...
