Summary of Contents for Thermorail SV24
- Page 1 SV24 / SV35 / SV43 / SV68 Thermorail Swivel Rails 240Volt Heated Towel Rail Installation Guide...
-
Page 2: Table Of Contents
Contents What’s in the box? Installation Safety & Care Information Warranty Technical Specifications Contact Us... -
Page 3: What's In The Box
What’s in the box? Check you’ve got everything: • Thermorail Swivel Rail • Screw Kit including: - 4 x Wall plugs - 4 x Screws - 1 x Concealed wiring cap Screw Wall Plug Concealed Wiring Cap Please note these parts are not to scale You will also need: •... -
Page 4: Installation
5 Screw 6 Wall Bracket The Thermorail models in this guide can be installed with either concealed or exposed wiring, with the electrical supply connected at the bottom. For concealed wiring follow the three below steps. For exposed wiring (plug-in) follow only step 1 and 3. - Page 5 Installation Unscrew the grey plastic screw cap from Pull the connection capsule through the back under the lower bracket. of the lower bracket. Remove the plastic grommet completely and Open up the terminal block and unwire the push the concealed wiring cap into the hole lead.
-
Page 6: Safety & Care Information
600mm from the floor and with a 300mm clearance from permanent fixtures. Where possible the Thermorail Heated Towel Rail should be screwed into studs or if fixing to hollow walls suitable anchors should be used to ensure rail is secure. -
Page 7: Warranty
All of the Thermorail Heated Towel Rails – Swivel Range have a 10 year warranty. To use the warranty, repair or service the customer must provide purchase invoice/receipt, and completed warranty registration form. -
Page 8: Technical Specifications
Contact Us Technical Speci cations SIZE (MM) STOCK CODE NO. OF BARS OUTPUT (W) IP RATING SV24 W600 x H540 x D99 IP44 SV35 W600 x H540 x D99 IP44 SV34 W675 x H740 x D99 IP44 SV68 W570 x H1260 x D99...
