PROTIUM-375
ECO MARATHON PACKAGE
USER GUIDE
VERSION 2.1 JANUARY 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROTIUM-375 and is the answer not in the manual?

Questions and answers

Related Manuals for Spectronik PROTIUM-375

Summary of Contents for Spectronik PROTIUM-375

  • Page 1 PROTIUM-375 ECO MARATHON PACKAGE USER GUIDE VERSION 2.1 JANUARY 2023...

  • Page 2: Safety, Handling & Support

    Do not use PROTIUM-375 in any other way than the one recommended in this manual. Spectronik reserves the right to change system specifications, appearance or discontinue the product at any time.
  • Page 3 OVERVIEW 1.1 PROTIUM-375 SYSTEM OVERVIEW Figure 1.1.1 Top, Front, Left and Right views of PROTIUM-375 ITEM DESCRIPTION Power/Signal receptacle gas outlet connector Cooling fan (x3) Gas purge solenoid valve Pressure sensor (x2) gas inlet connector Protective mask Gas supply solenoid valve...

  • Page 4: Electronic Controller

    1.2 ELECTRONIC CONTROLLER Figure 1.2.1 Top, Left and Right views of Electronic Controller ITEM DESCRIPTION DC-DC converter Radio telemetry transmitter Power/Signal header Unregulated stack power out receptable Mounting hole (x4) Programming port DC-DC power out (XT-60 female) On-Off push button External power supply receptable Status LED CHAPTER 1 | OVERVIEW...

  • Page 5: Standard Accessories

    1.3 STANDARD ACCESSORIES Figure 1.3.1 Supercapacitors pack ITEM DESCRIPTION Supercapacitor (x24) DC-DC power out connector (XT-60 male) Load connector (XT-90 female) External power supply connector (XT-60 female) CHAPTER 1 | OVERVIEW...
  • Page 6 1.3 STANDARD ACCESSORIES 0287020.PXCN 0FHA002ZXJ Figure 1.3.2 External power supply cable, power/signal extension cable *In compliance with Shell Eco Marathon competition rules, the fuel cell power output cable comes with ATOF®- series 20A, 32V fast acting Blade Fuse (Part No. 0287020.PXCN) and fuseholder (Part No. 0FHA0002ZXJ). ITEM DESCRIPTION External power supply header USB connector to PC...
  • Page 7 1.4 MECHANICAL DIMENSION – PROTIUM-375 ALL DIMENSIONS IN MM 236.80 31.00 142.00 40.00 112.50 86.80 CHAPTER 1 | OVERVIEW...
  • Page 8 1.5 MECHANICAL DIMENSION – ELECTRONIC CONTROLLER ALL DIMENSIONS IN MM 163.40 113.00 15.30 145.00 131.40 44.22 42.20 43.10 M 63.20 16.25 68.60 85.00 3.20 (4x) 55.58 102.10 CHAPTER 1 | OVERVIEW...
  • Page 9 1.6 MECHANICAL DIMENSION – STANDARD ACCESSORIES ALL DIMENSIONS IN MM 323.00 150.00 62.50 1.0 135.50 104.50 2.40 73.00 73.00 20.00 104.50 135.50 140.00 33.00 1.0 CHAPTER 1 | OVERVIEW...
  • Page 10 1.6 MECHANICAL DIMENSION – STANDARD ACCESSORIES ALL DIMENSIONS IN MM 1000 1800 1000 1000 CHAPTER 1 | OVERVIEW...
  • Page 11 Mount PROTIUM-375 in the recommended orientation above, using the mounting brackets provided. For optimal oxidant and cooling airflows, it is also recommended that there is at least 15cm unobstructed clearance in front of the protective mask and 30cm unobstructed clearance behind the cooling fans’...
  • Page 12 1.8 MECHANICAL DIMENSION – MOUNTING AND CLEARANCE Figure 1.8.1 Dimensions of the mounting holes ALL DIMENSIONS IN MM 312.20 312.20 299.70 252.20 35.00 90.10 4.50 CHAPTER 1 | OVERVIEW...

  • Page 13: Specifications

    SPECIFICATIONS 2.1 TECHNICAL DATA SHEET Fuel Cell PROTIUM-375 Type No. of cells Architecture Open cathode Coolant Air cooled Rated/gross power 375/450W Rated/gross current 12.5/15A Voltage output 30-45VDC Start-up time <30s Operating ambient temperature [0,35] Operating altitude without power derating 1500m AGL...
  • Page 14 The output voltage (Vset) and output current (Iset) of the DC-DC converter can be changed according to the user’s needs. This provides flexibility for the PROTIUM-375 to be compatible with various DC motor’s voltage input range. To protect against current overdraw or to maintain the fuel cell’s output at its most optimum power level, Iset can also be configured to limit the maximum allowable current output.
  • Page 15 Iset can only be changed via the PC DAQ GUI app. Follow the instructions on Section 3 until step no.1 of section 3.2. After the welcome header appears in the message box of the GUI, use the keyboard function of the GUI and type the following command: ‘i’...
  • Page 16 Supercapacitor detailed technical datasheet is attached in Annex A. motor. The standard pack consists of 24pcs of Supercapacitors in series, and suitable for use up to For higher motor voltages, contact Spectronik for custom solutions. CHAPTER 2 | SPECIFICATIONS...

  • Page 17: Test Conditions

    2.2 VI CURVE & HYDROGEN EFFICIENCY CURVE 10.0 12.0 14.0 16.0 Current (A) Figure 2.2.1 Nominal polarization curve for a fully conditioned PROTIUM-375 at its Beginning-of-Life (BOL). TEST CONDITIONS • Ambient temperature: 24 • Relative humidity: 60% • H supply pressure: 10psig •...
  • Page 18 Figure 2.2.2 Hydrogen consumption and efficiency for a fully conditioned PROTIUM-375 at BOL. NOTES • Hydrogen consumption is instantaneous reading taken from mass flowmeter at STP. • PROTIUM-375 is most efficient in the 100-250W range which is the typical nominal cruising power of Eco-Marathon vehicles. CHAPTER 2 | SPECIFICATIONS...

  • Page 19: System Block Diagram

    2.3 SYSTEM BLOCK DIAGRAM Protium-375 Fuel Cell Stack Fuel Cell Supercapacitors Electronic Pack Controller DC-DC LOAD e.g. DC Motor 36V, 8.33A (300W) External power supply (Supercapacitors Pack) DC-DC regulated output (0-60VDC user configurable Vset, 375W max) iii. Stack unregulated output (30-45VDC, 375W max) NOTE 1.

  • Page 20: Operating Procedures

    5. Connect the power/signal receptacle (1) of the PROTIUM-375 to the power/signal header (11) of the electronic controller, using the power signal extension cable (26/27).
  • Page 21 Hydrogen gas flow rate of more than 5L/min. 4. PROTIUM-375 will do a series of gas purging and internal diagnostic checks. If everything is normal, the fuel cell will enter its “Running Phase” – indicated by the message in the GUI and a solid white LED.
  • Page 22 3.3 POWERING YOUR LOAD WITH PROTIUM-375 1. Turn ON your load and draw power as per normal. Caution: never draw power beyond 375W. If Iset is implemented, the fuel cell will not deliver more than the Iset current to the load. Excess power required by the load would then be supplied by the supercapacitors pack.
  • Page 23 ON/OFF push button for more than 2s. The message “Shutdown Initiated” will appear in the GUI and PROTIUM-375 will enter its “Shutdown Phase”. The system is now OFF. LED will blink at 60% on standby awaiting the next start-up command.
  • Page 24 “start” and “end” command via the GUI. 4.2 SYSTEM WARNING & PROTECTIONS PROTIUM-375 has several in-built protections. The LED will flash and error message will appear in the GUI. Follow the basic troubleshooting guide below. Most errors should be rectified once the suggested corrective action has been done and the system restarted.
  • Page 25 Stack open circuit voltage is too low. Check and ensure sufficient hydrogen supply and correct delivery pressure. Restart after 1 min. ◉ Emergency Shutdown = "Abnormal Shutdown" would be activated * with purchase of optional Spectronik accessories (gas tank and pressure regulator) CHAPTER 4 | SYSTEM MONITORING & PROTECTIONS...
  • Page 26 Please check for abnormalities. ◉ Emergency Shutdown = "Abnormal Shutdown" would be activated ● LED flashing at 80% to alert warning in the running * with purchase of optional Spectronik accessories (gas tank and pressure regulator) CHAPTER 4 | SYSTEM MONITORING & PROTECTIONS...
  • Page 27 4.2 SYSTEM WARNING & PROTECTIONS (Cont.) Other messages: Message Meaning Fan PWM auto Cooling fans control is in auto mode Mileage Cumulative Watt-Hour of the system Shutdown initiated Entering “Normal Shutdown Phase” Abnormal Shutdown initiated Entering “Abnormal Shutdown Phase” due to an error System off System is turned off and ready to restart at the next command LED status:...

  • Page 28: Maintenance And Storage

    When not in use, Spectronik recommends that PROTIUM-375 is reconditioned at least once a month. 1. Set up PROTIUM-375 as per instructions in Section 3, taking note of the following differences: Use a DC power supply instead of the Supercapacitors pack. Set the DC power supply to 30V 2A.
