DISHWASHER USER MANUAL

( WQP4-6204 )

E very applia nce have passed the water test in f actory.

It i s normal i f you f ound some water l eave in appliance.

Pl ease f eel f ree to use it

Please read this instruction carefully before using and keep it safe.

Table of Contents

Need help?

Do you have a question about the WQP4-6204 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hissun WQP4-6204

Page 1 DISHWASHER USER MANUAL ( WQP4-6204 ) E very applia nce have passed the water test in f actory. It i s normal i f you f ound some water l eave in appliance. Pl ease f eel f ree to use it...
Page 2: Table Of Contents
CONTENTS Important Safety Instructions A-01 Product Overview Parts of D ishwasher B-01 Technica l Inf ormation B-02 Packag e List B-02 Installation Instructions Installation diag ra m C-01 Installation steps C-01 Operating Instructions Control panel D -01 Overview of prog rammes D -02 D -02 Adding deterg ent...
Page 3: Important Safety Instructions
Important Safety Instructions Warning There are some important safety instructions in this manual, Please read carefully before installing and using , This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and other working environments; –...
Page 4 Please keep the appliance at room temperature for 8 hours after receiving the product ● in winter, To aviod the droplets appearing on the surface of the glass, and it may damage the appliance. The appliance is to be connected to the water mains using new hose sets and that old ●...
Page 5: Product Overview
Product Overview Parts of D ishwasher Filter assembled D i shwasher interior Lower spray arm Basket Cutlery basket （Pictures for reference only, The actual product shall govern.） B- 01...
Page 6 Technical Inf ormation Capacity 2 Place settings + 6 Serving pieces Waterproof IPX1 Nominal voltage AC120V 785W Frequency Rated power 60Hz Water pressure 5.8~145PSI Water temperature Outline size W440 X D413 X H424mm Implementation UL749 standards *Due to the continuous improvement of products, such as the technical parameters in this manual are modified without prior notice.
Page 7: Installation Instructions
Installation Instructions Instal lation diag ram Running water inlet This is the default installation mode. It is recommended that this mode be selected for installation in good installation conditions. Refer to Steps for installation. NOTICE:When the first time that water in ,the water in appliance turns yellow which is normal;...
Page 8 Installation of drain pipe Drain pipe connector Clamping band Drain pipe 1.Connect the drain and drain 2.The drain pipe should 3.Please put the free end port be fixed by the clamping of the drain pipe into the band sink or sewer. N otes：...
Page 9: Operating Instructions
Operating Instructions Control panel i nstruction Lock Program Start/Pause Power Delay start Button Button Indica tor la mps Operate the dishwasher Close the door of the Change wash programme with dishwasher and start the button. Please select a appliance by pressing suitable programme .
Page 10 Overview of prog rammes Special dishwasher detergent will remove oil and food residues. It is a must every time you use the appliance. Detergent dosage depends on the amount of and type of soiling. Consumption of detergent Time cycle Type of soiling Programme washing powder washing tablet...
Page 11: Tableware Placement Attention
Utensi ls selection Dishwasher-proof utensils: Ceramic tableware Glassware Stainless steel tableware Utensils notes： 1. Precious metal, aluminium and colored glaze utensils may turn cloudy after being washed in a dishwasher. 2. Cutlery made of bamboo or wood: It may come loose orcrack at high temperatures. 3.
Page 12 Loading the basket D -04...
Page 13: Clean The Filter Assembly
Maintenance and Cleaning Clean the filter assembly After appliance ran a while, there will be some residue and other things left in it. Please clean it when you see the residue and things, also clean the appliance immediately. Make sure the power Use flowing water to flush filter is off.
Page 14: E Rror Code List
Service Information E rror code list Error code Cause Remedy Thermistor short circuit Please contact the after-sales service department Thermistor open circuit Please contact the after-sales service department 1. Please make sure the utensils be placed correctly. Water will The machine is not be lack if it is in the plate/bow.
Page 15 Problem Cause Remedy 1.If all the lights were off and no reflection when you press the button, there are Please plug the power in and make sure possibilities that you didn't plug in the the power have no issue. power or the power was blackout. No reflection after turn Clean plug the power in and make sure 2.power or the power was blackout...
Page 16: Circuit Diag Ram
Circuit diag ram control E G N D E G N D CN 1 9 White Floodcock K-YL Heat Flowmeter Heat FUSE D oor DOOR Thermistor E V-Z1 Inlet valve E V-Z Washer pump Draining pump PS B F -03...
Page 17: Af Ter Sales Service
Af ter sales service Warranty requirements *Provide valid vouchers for purchasing products during the warranty period： Invoice or product SN code. *Free warranty within 12 months based on the date of SN code of the product leaving the factory. *The following conditions do not fall within the scope of free maintenance during the warranty period, ：...
Page 18 STATEMENT : With the innovation and improvement of product technology, the product specifications of the same model as this product may be changed, and the change part will be notified without further notice. The pictures of the products in the instruction are all borrowed from the appearance of the dishwasher, and the pictures are only used as an example.
