ODW-1S
COMPACT DISHWASHER WITH BASIN
COMPACT DISHWASHER ONLY
ODW-1
ODW-1S
ODW-1
TM
User Guide
1
Item Supplied in Package
Including parts information
4
3
2
ODW-1S
1. Main Dishwasher Unit with Basin
2. Removable basin strainer
3. Faucet mounting hole with caps
4. Dishwasher lid with controls
5. Rotating Spray arm
6. Removable Dishwasher Drainer basket
5. Cutlery basket
8. Two-piece drain pipe
9. Inlet pipe hose
1
2
ODW-1
1. Dishwasher lid with controls
2. Rotating Spray arm
3. Removable Dishwasher Drainer basket
4. Cutlery basket
5. Two-piece drain pipe
6. Inlet pipe hose
Warranty & Product Enquiries:
All warranty and product enquiries,
contact ONEX : 03 83545500
(English)
8
7
9
6
5
5
4
6
3
Advertisement
Summary of Contents for ONEX ODW-1S
- Page 1 ODW-1 1. Dishwasher lid with controls 2. Rotating Spray arm 3. Removable Dishwasher Drainer basket 4. Cutlery basket 5. Two-piece drain pipe 6. Inlet pipe hose Warranty & Product Enquiries: All warranty and product enquiries, contact ONEX : 03 83545500...
- Page 2 Setting up dishwasher for first use Applicable to both ODW-1S & ODW-1 A. Water inlet & Drainage B. Filter • Install the water inlet and the • Ensure that the main filter and fine filter drainage pipe as shown below.
- Page 3 Using the Dishwasher Powering dishwasher for use (ii) MAINS A. Plumbing check POWER 1. Once the dishwasher has been installed, check and ensure that (i) WATER all the water inlet pipes and the VALVE drainage pipes are properly installed and tested for any leakage.
- Page 4 240V AC, 50 Hz Power Rating 1650 Watts Ingress Protection IPX1 Rated Water Pressure 0.03-0.6 Mpa Dimensions 516 mm x 514mm x 500mm Weight 16.5 kg Warranty & Product Enquiries: All warranty and product enquiries, contact ONEX : 03 83545500...
