Summary of Contents for Suyncll AMD005284
- Page 1 Operator’s Manual HIGH PRESSURE CLEANER AMD005284 WARNING: Read the instructions before using the machine.
- Page 2 Within 12 months, we will provide timely and effective online after-sales service after your purchase. 2.How to install the machine? ✔ Search Suyncll on Facebook Or Youtube to get installation videos and troubleshooting; ✔ Follow the instructions below to install;...
-
Page 3: Table Of Contents
Contents Page Section Important Safety Precautions, Tips Warnings, and Usage Instructions Assembly Instructions 7-11 Operating Instructions 11-13 Using Detergents 14-15 Clean-up and Storage 15-16 Cleaning Tips 16-17 Technical data Troubleshooting Tips CE Declaration... -
Page 4: Important Safety Precautions, Tips
IMPORTANT SAFETY TIPS Never point the high-pressure nozzle at people or animals. Never drink alcohol or use drugs while operating the pressure cleaner. Never operate the pressure cleaner while standing in water. Never touch the electrical plug with wet hands. Never let electrical connections rest in water. -
Page 5: Warnings, And Usage Instructions
GENERAL SAFETY PRECAUTIONS Intended for outdoor household use only. High-pressure hose can develop leaks from wear, abuse, kinking etc. Do not use a damaged hose. Do not use the pressure cleaner in areas near combustible materials, combustible fumes, or dust. Some chemicals or detergents may be harmful if inhaled or ingested causing severe injury. - Page 6 Do not hold hoses or fittings. To reduce the risk of injury from kickback, hold the spray lance securely with both hands when the machine is on. Failure to use in dry conditions and to observe safe practices can result in electric shock.
- Page 7 USE OF EXTENSION CORDS Use of an extension cord with this product is NOT RECOMMENDED. If you must use an extension cord, use only extension cords that are intended for outdoor use. These cords are identified by a marking “ACCEPTABLE FOR USE WITH OUTDOOR APPLIANCES, STORE INDOORS WHILE NOT IN USE.”...
-
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS Unpacking The Carton After opening the carton, please remove all parts and check them against the following list of components that are included: 1. Handle 2.Holder 3.Switch 4. Cleaning pot hook 5. Cleaning pin 6. Water inlet connector 7. - Page 9 Due to transportation and packaging, some of the accessories may be supplied disassembled. Please follow the assembly instructions. Step 1 Install gun hook and power cord hook,(For both model A/B&C/D) Step 2 Screw the washer handle tight to the main body as below fig. The screws will be packed together with the main body, pls kindly check and find it when unpacked.
- Page 10 B，Insert the spray adjustable nozzle(D) into the extension wand(K) , as quick-connect type , you just need push it onto extension wand(K) directly and powerful until hand tight to lock it in place. When the pieces are joined properly, you cannot separate the two components by pulling straight out on the extension wand(K) .
- Page 11 Step 6 Connect the garden hose adaptor (female coupler) to the water inlet of the pressure washer, then thread your garden hose (male end) into the garden hose adaptor . The garden hose must have an internal diameter of at least 13 mm (1/2 in.) and must be reinforced.
-
Page 12: Operating Instructions
OPERATING INSTRUCTIONS THIS UNIT IS INTENDED TO BE USED WITH COLD WATER ONLY! DO NOT USE HOT WATER IN THIS PRESSURE CLEANER! Starting Up After connecting the pressure cleaner to your cold water supply, proceed as follows: Make sure that the on/off switch is in the off position. Connect the garden hose to the inlet fitting. - Page 13 using the pressure cleaner, release the trigger and switch the unit to the OFF position. The unit should be turned completely OFF while not in use or while unattended. Bleeding the Gun It is very important to bleed the gun before using the pressure cleaner. Refer to the “Assembly Instructions”...
- Page 14 Adjustable Spray Nozzle Diagram1 Diagram 2 The adjustable nozzle will allow you to use any variety of spray patterns from a full fan spray (Diagram 1) to a direct stream spray (Diagram 2). When using the pressure washer to clean wood decks, siding, vehicles etc., always start using the fan spray and begin spraying from a minimum 36”...
-
Page 15: Using Detergents
USING DETERGENTS THE PRESSURE CLEANER WILL DISPENSE DETERGENT AT LOW PRESSURE. USE THE ADJUSTABLE SPRAY NOZZLE TO RINSE CLEAN. BIODEGRADABLE DETERGENTS ARE SPECIFICALLY FORMULATED TO PROTECT THE ENVIRONMENT AND YOUR PRESSURE CLEANER. THESE DETERGENTS WILL NOT CLOG THE FILTER AND WILL PROTECT THE INTERNAL PARTS OF THE PRESSURE CLEANER FOR A LONGER LIFE. -
Page 16: Clean-Up And Storage
WARNING: NEVER USE PRODUCTS WITH BLEACH OR CHLORINE OR ANY OTHER CORROSIVE MATERIALS, INCLUDING LIQUIDS CONTAINING SOLVENTS (I.E. GAS, OILS ETC), TRI-SODIUM PHOSPHATE PRODUCTS, AMMONIA, OR ACID-BASED CLEANERS. THESE CHEMICALS WILL HARM THE UNIT AND CAUSE DAMAGE TO THE SURFACE BEING CLEANED. ALWAYS READ THE LABEL. E. -
Page 17: Cleaning Tips
After disconnecting the water supply, and before disconnecting the high-pressure hose, turn the pressure cleaner on for 2-3 seconds, until any remaining water in the pump exits. TURN UNIT OFF IMMEDIATELY. CONTINUED USE OF THE PRESSURE CLEANER WITHOUT WATER SUPPLY ATTACHED WILL CAUSE SEVERE DAMAGE TO THE UNIT! Always store the pressure cleaner, parts, and accessories in an area with a temperature ... -
Page 18: Technical Data
1-3 inches from the cleaning surface. Maintain a further distance from the cleaning area when using a direct spray. TECHNICAL DATA Model AMD005284 Main Voltage AC 120V Main Frequency 60 Hz... -
Page 19: Troubleshooting Tips
Pump bypass valve or gun is Please email to: itself together with sharp noise leakage support@suyncll.com technical assistance, we will guide maintenance based on actual situation Machine can start, but no water Water left in pump, hoses or Put machine outdoor and wait ... -
Page 20: Ce Declaration
EU's consistent policy. The statement will prove ineffective if the device is being modified without our approval. Type of instrument: Pressure Cleaner AMD005284 Anwenbare EU guidelines: • EU Machinery Directive 2006/42/EC •...
