INSTALLATION, OPERATION,

AND MAINTENANCE MANUAL

FMR 60M–450M

TWIN ALTERNATING

METERED 1-1/2" SXT SERIES

COMMERCIAL WATER CONDITIONERS

COMPLETE FOR FUTURE REFERENCE:

MODEL NO:

SERIAL NO:

DATE INSTALLED:

DEALER:

Table of Contents

Need help?

Do you have a question about the SXT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CleaverBrooks SXT Series

Page 1 CLICK ANYWHERE on THIS PAGE to RETURN to WATER SOFTENERS at InspectApedia.com INSTALLATION, OPERATION, AND MAINTENANCE MANUAL FMR 60M–450M TWIN ALTERNATING METERED 1-1/2” SXT SERIES COMMERCIAL WATER CONDITIONERS COMPLETE FOR FUTURE REFERENCE: MODEL NO: SERIAL NO: DATE INSTALLED: DEALER:...
Page 2 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED Please Circle and/or Fill in the Appropriate Data for Future Reference: Softener Model: System Size: Twin Alternating - Twin Tank Configuration: Timeclock/Electromechanical Metered/SXT Metered/XT Metered BW/Regen Time: ________________ AM/PM or OFF Additional Notes: ______________________________________________________________________________ _____________________________________________________________________________________________ _____________________________________________________________________________________________ _____________________________________________________________________________________________...
Page 3: Table Of Contents
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED TABLE OF CONTENTS SYSTEM INFORMATION Product Warranty ................................1 General Arrangement Drawings ...........................2 Dimensional Data .................................3 Specification Table ................................4 INSTALLATION General Information ...............................5 Loading Softener ................................6 Mounting Control Valve ..............................7 Piping Installation .................................7 OPERATION Start-Up Procedure ...............................7 SXT Timer Features ..............................9 Controller Operation ..............................10...
Page 4: System Information
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED SYSTEM INFORMATION COMMERCIAL AND INDUSTRIAL PRODUCT WARRANTY Manufacturer warrants all commercial and industrial water treatment products manufactured and/or distributed by it to be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. The fiber- glass mineral tank(s) alone have a warranty for a period of five (5) year from the date of shipment.
Page 5: General Arrangement Drawings
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED SYSTEM INFORMATION...
Page 6: Dimensional Data
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED SYSTEM INFORMATION DIMENSION CHART TANK SIZE INLET SIZE LENGTH WIDTH HEIGHT* MODEL SOFTENER BRINE (Inches) (Inches) (Inches) (Inches) (Inches) (Inches) 1-1/2 12x52 18x40 1-1/2 14x65 18x40 1-1/2 16x65 24x40 1-1/2 18x65 24x50 1-1/2 21x62 24x50 1-1/2...
Page 7: Specification Table
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED SYSTEM INFORMATION SPECIFICATION CHART MODEL 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 VALVE SIZE (IN) MAX CAPACITY (KILOGRAINS) MIN CAPACITY (KILOGRAINS) SERVICE - CONTINUOUS (GPM) SERVICE - PEAK (GPM) BACKWASH & FAST FLUSH (GPM) BRINE DRAW &...
Page 8: Installation
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED INSTALLATION INSTALLATION INSTRUCTIONS GENERAL INFORMATION 1. Minimum operating pressure is 30 psi. If pressure less than 30 psi is encountered, a regulator must be installed NOTE: The control valve will not operate correctly if feeding into an atmospheric tank. A pressure control device must be added to the outlet to maintain the minimum pressure.
Page 9: Loading Softener
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED INSTALLATION INSTALLATION INSTRUCTIONS LOADING TANK NOTE: If the system is skid mounted, it will be prepiped and preloaded at the factory. Skip the following instructions and go to the section of “Installation of connection piping”. 1.
Page 10: Mounting Control Valve
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED INSTALLATION INSTALLATION OF CONNECTION PIPING NOTES: • Use thread sealing tape on all threaded piping connections. • Install the piping conforming to federal, provincial, and local codes. • Unions or flanges are recommended at the control valve’s inlet and outlet connections• To enhance the monitoring of the system’s performance sample valves and pressure gauges can be installed at the inlet and outlet piping of the softening unit (not provided).
Page 11: Operation
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION START-UP (continued) REGENERATION STEPS • Backwash: The cycle duration is factory set at 10 minutes for clean feed water applications. Increase time duration to 15 minutes when turbidity is present in the feed water. •...
Page 12: Sxt Timer Features
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION TIMER FEATURES Parameter Data Display Display Indicator Error/ Information Icon Flow Indicator Service Icon x1000 Indicator Programming Icon Extra Cycle Down Button Button Button FEATURES OF THE SXT: • Power backup that continues to keep time and the passage of days for a minimum of 48 hours in the event of power failure.
Page 13: Controller Operation
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION TIMER FEATURES SETTING THE TIME OF DAY 1. Press and hold either the Up or Down buttons until the programming icon replaces the service icon and the parameter display reads TD. 2. Adjust the displayed time with the Up and Down buttons.When the desired time is set, press the Extra Cycle button to resume normal operation.
Page 14 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION CONTROLLER OPERATION (continued) DAY OF THE WEEK CONTROL This control regenerates the system on a weekly schedule. The schedule is defined in Master Programming by setting each day to either “off” or “on.” The control will initiates a regeneration cycle on days that have been set to “on” at the specified regeneration time.
Page 15: Master Programming Mode Chart
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION MASTER PROGRAMMING MODE CHART Master Programming Options Abbreviation Parameter Option Options Abbreviation Gallons Display Format Liters Cubic Meters St1b Standard Downﬂow/Upﬂow Single Backwash St2b Standard Downﬂow/Upﬂow Double Backwash Valve Type Fltr Filter UFbF Upﬂow Brine First Othr...
Page 16: Master Programming Mode
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION MASTER PROGRAMMING MODE ENTERING MASTER PROGRAMMING MODE Set the Time Of Day display to 12:01 P.M. Press the Extra Cycle button (to exit Setting Time of Day mode). Then press and hold the Up and Down buttons together until the programming icon replaces the service icon and the Dis- play Format screen appears.
Page 17 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION MASTER PROGRAMMING MODE (continued) 4. Number of Tanks (Display Code NT) Press the Extra Cycle button. Use this display to set the Number of Tanks in your system. This option setting is identified by “NT”...
Page 18 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION MASTER PROGRAMMING MODE (continued) 8. Reserve Selection (Display Code RS) Press the Extra Cycle button. Use this display to set the Safety Factor. Use this display to select the type of reserve to be used in your system. This setting is identified by “RS” in the upper left-hand corner of the screen. SF - Safety Factor The reserve selection parameter is only available if the control type has been set to one of the metered options.
Page 19 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION MASTER PROGRAMMING MODE (continued) 12. Regeneration Time (RT) Press the Extra Cycle button. Use this display to set the Regeneration Time. This setting specifies the time of day the control will initiate a delayed, manually queued, or day override triggered regeneration. This option setting is identified by “RT”...
Page 20 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION MASTER PROGRAMMING MODE (continued) 16. Flow Meter Type (Display Code FM) Press the Extra Cycle button. Use this display to set the type of flow meter connected to the control. This option setting is identified by “FM”...
Page 21: User Programming Mode
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION USER PROGRAMMING MODE USER PROGRAMMING MODE OPTIONS ABBREVIATIONS PARAMETER DESCRIPTION Day Override The timer’s override setting Regeneration Time The time of day that the system will regenerate (meter delayed, timeclock, and day-of-week systems) Feed Water Hardness The hardness of the inlet water - used to calculate system capacity for metered systems...
Page 22: Diagnostic Programming Mode
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION DIAGNOSTIC PROGRAMMING MODE USER PROGRAMMING MODE OPTIONS ABBREVIATIONS PARAMETER DESCRIPTION Day Override The timer’s override setting Regeneration Time The time of day that the system will regenerate (meter delayed, timeclock, and day-of-week systems) Feed Water Hardness The hardness of the inlet water - used to calculate system capacity for metered systems...
Page 23 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION DIAGNOSTIC PROGRAMMING MODE 6. Press the Up button. Use this display to view the Reserve Capacity. This option setting is identified by “RC” in the upper left hand corner of the screen. 7.
Page 24: Flow Diagrams
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION FLOW DIAGRAMS 1 - SERVICE POSITION Hard water enters the unit at the valve inlet, flows around the lower piston, and down through the mineral in the first tank. Conditioned water enters the center tube through the bot- tom distributor, flows up through the center tube,around the lower piston, through the meter, and out the valve outlet.
Page 25 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION FLOW DIAGRAMS 3 - BACKWASH Conditioned water from the second mineral tank flows around the lower piston, around the upper piston, through the center of the lower piston, down the center tube, up through the mineral, around the upper piston, and out the drain line.
Page 26 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION FLOW DIAGRAMS 5 - SLOW RINSE Conditioned water from the second mineral tank flows around the lower piston, around the upper piston, into the injector housing, down through the nozzle and throat, around the upper piston, down through the mineral, into the cen- ter tube through the bottom distributor, up the center tube, through the center of the lower piston,through the center of...
Page 27: Wiring Diagram
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED OPERATION SXT WIRING DIAGRAM...
Page 28: Maintenance
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE SXT TIMER ASSEMBLY Item No. Quantity Part No. Description 1 ....1 ....13881 ......BRACKET, HINGE TIMER 2 ....2 ....11384 ......SCREW, PHIL, 6-32 X 1/4 3 ....1 ....42732 ......BRACKET, TIMER, 9000SXT 4 ....
Page 29: Powerhead Assembly
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE POWERHEAD ASSEMBLY...
Page 30 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE POWERHEAD PARTS LIST Item No. Quantity Part No. Description 1 .......2 ......18728 ......Nut, Tinnerman, U Type, 8-32 2 .......1 ......11838 ......Power Cord, 6’ Fleck 11839 ......Power Cord, 12’ Fleck 40084-12 .......Power Cord, 12’ U.S., Round, 120V Sys 5, 6, 7 & 2900/3150/3900 #4 11545-01 .......Power Cord Assy, 4’...
Page 31: 9500 Control Valve Assembly
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE 9500 CONTROL VALVE ASSEMBLY...
Page 32 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE 9500 CONTROL VALVE PARTS LIST Item No. Quantity Part No. Description 1....1 ..... 16919-01......Valve Body 2....16 ....16101 ......Seal 3....12 ....16638-01......Spacer ..........16638 ......Spacer Hot Water 4....1 ..... 17110 ......Upper Piston 5....2 .....
Page 33: Second Tank Adapter Assembly
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE 9500 SECOND TANK ASSEMBLY Item No. Quantity Part No. Description 1 ....1 ....13577 ......O-ring, -226 2 ....1 ....16455 ......O-ring, -347 3 ....8 ....10231 ......Screw, Slot Hex, 1/4 - 20 x 1/2 4 ....
Page 34: Meter Assemblies
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE 1-1/2” INLINE PLASTIC METER ASSEMBLY Item No. Quantity Part No. Description 1 ....1 ....17542 ......Flow Straightener 2 ....2 ....40576 ......Clip, H, Plastic, 7000 3 ....1 ....40577 ......Turbine Meter Assy, 7000 4 ....
Page 35 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE 1-1/2” PLASTIC PADDLE METER Item No. Quantity Part No. Description 1 ....1 ....17569 ......Body, Meter, 2850/9500 2 ....1 ....13882 ......Post, Meter Impeller 3 ....1 ....13509 ......Impeller, Meter 4 ....
Page 36: Brine Tank Assemblies
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE BRINE SYSTEM - FMR 60M-90M TUBING KIT Item Description Part Number Number Brine Tank 18”x40”/Black Molded Cover - FMR 60M - 90M A2042028 Brine Valve Assembly 474 w/ Aircheck - FMR 65M - 90M B1179005 5”...
Page 37 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE BRINE SYSTEM FOR FMR 120M-300M Item Description Part Number Number Brine Tank 24” x 41” w/ Holes - FMR 120M B1002039 Brine Tank 24”x50” w/ Holes - FMR 150M-300M B1002016 24” Diameter 5BW Plastic Grid Plate A2284007 Brine Valve (474) for FMR 120 B1180014...
Page 38 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE BRINE SYSTEM FOR FMR 450M Item Description Part Number Number Brine Tank 30” x 50” w/ Holes - FMR 450M B1002041 5” x 48” Drilled Brine Well B1015005 Brine Valve Assembly 16-1/4” x 24” B1042007 5”...
Page 39 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE 9500 SERVICE ASSEMBLIES 9500 SERVICE ASSEMBLIES Item Quantity Part Number Description valve body 9500 NPT, mechanical base 16919-01 valve body 9500 NPT, mechanical base, nickel-plated 16919-01NP valve body 9500 BSP/Metric, mechanical base 16919-21 valve body 9500 BSP/Metric, mechanical base, nickel-plated 16919-21NP...
Page 40: Service Assemblies
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE SERVICE ASSEMBLIES COVERS A2103128 Designer with Left Window BRINE LINE FLOW CONTROLS A2389001 BLFC, .25 GPM, 1600 A2389002 BLFC, .50 GPM, 1600 A2389004 BLFC, 1.0 GPM, 1600 BRINE VALVE ASSEMBLY 60039-XX Brine Valve, 9500/1700, Cold & HW 180° A2005085 Brine Valve 9500/1700 Blank A2005025...
Page 41: Troubleshooting
FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE TROUBLESHOOTING ERROR CODES NOTE: Error codes appear on the In Service display. ERROR CODE PROBABLE CAUSE RECOVER & RESETTING [Err0] Drive motor is stalled Unplug the unit from the power source[ [Err1] Drive motor is running continuously When power is restored to the unit, the Err _ display code clears.
Page 42 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE TROUBLESHOOTING 2900 VALVE PROBLEM CAUSE CORRECTION Softener Fails To Regenerate. A. Electrical Service To Unit Has A. Assure Permanent Electrical Ser- Been Interrupted. vice (Check Fuse, Plug, Pull Chain or Switch). B. Timer Is Defective. B.
Page 43 FMR 60M–450M SXT 1-1/2” TWIN ALTERNATING METERED MAINTENANCE TROUBLESHOOTING 2900 VALVE (CONTINUED) PROBLEM CAUSE CORRECTION 7. Excessive Water In Brine Tank. A. Plugged Drain Line Flow Control. A. Clean Flow Control. B. Plugged Injector System. B. Clean Injector and Screen. C.
Page 44 221 Law Street - Thomasville, GA 31792 Printed in the U.S.A Copyright Cleaver-Brooks, Inc. 414-359-0600 - 800-250-5883 750-00321 09/2010 info@cleaver-brooks.com - cleaverbrooks.com...
