TECHNICAL MANUAL
V-Reader
Reader

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-Reader and is the answer not in the manual?

Questions and answers

Summary of Contents for Vauban Systems V-Reader

  • Page 1 TECHNICAL MANUAL V-Reader Reader...
  • Page 2 www.vauban-systems.fr...
  • Page 3: Table Of Contents

    PRODUCT INFORMATION 03.2 POWER SUPPLY FEATURES 03.3 FEATURES 03.4 OPERATING TEMPERATURE Buzzer / Led Anti-pullout function Connection of the reader on a VERSO + control unit ® Configuration on VISOR ® 07.1 V-READER 07.2 V-READER KP Fixation Dimensions Free installer hotline...
  • Page 4: Thank You

    Thank You Dear client, We would like to thank you for purchasing a "V-READER" reader created by the French company, VAUBAN SYSTEMS ® Shown in our products. To find out more about our range, please visit our website at www.vauban-systems.fr.
  • Page 5: Information And Recommendations

    Pour le V-Reader : V2.0.0.30 minimum and the › firmware of the control unit must be V3.5 at a minimum. Pour le V-Reader KP : V2.0.0.33 minimum and the › firmware of the control unit must be V3.8 at a minimum This device complies with Part-15 of the FCC and with the ›...
  • Page 6 This device complies with security norms regarding the › exposure to RF, in compliance with RSS-102 issue 5 for conditions of use. In conformity with regulations of the Environment Code › (sub-section 1, paragraph 1, art. R 543-171 and following), the manufacturer finances the collection, clean-up and recycling network from DEEE established by ESR-RECYLUM to which the manufacturer has adhered and to which he...
  • Page 7: Technical Characteristics

    Technical characteristics 03.1 PRODUCT INFORMATION Connector Cable exit Brown Grey Blue Yellow Green Orange White 03.2 POWER SUPPLY FEATURES Use AC/DC supply, LPS-type, Limited power source (according to IEC EN 60950-1 Ed2) or ES1, PS1-type (according to IEC EN 62368-1) Power supply: Range: +7 Vdc to +28 Vdc | Typical: 12 Vdc Max consumption at 12 Vdc: 140 mA...
  • Page 8: Features

    03.3 FEATURES Communication: RS485 (L+ &L-) Connector exit: > 8 female contacts 28-22 AWG to be crimped (Wurth Electronik 62400113722DEC) > Double-row female connector with 8 points (Wurth Electronik 624008213322) (Use a crimping tool: WURTH ELEKTRONIK 600624228220) Cable exit: TRANXALARM - 8 x 0,22 mm2 – Length 3,05 Protection: IP65 level without Buzzer connections 03.4 OPERATING TEMPERATURE Operating room temperature: -20 °C to +70 °C...
  • Page 9: Anti-Pullout Function

    Anti-pullout function The pullout is detected by an accelerometer. Once it is detected: The reader will perform the operations configured in › VISOR ® Note: turn on the reader when it is in its final position to start the accelerometer in the right position.
  • Page 10: Connection Of The Reader On

    Connection of the reader on a VERSO + control unit ® NOTE: If you are using an external power supply to pow- er your proximity scanners, ensure that you connect all grounds to the ground on the control unit.
  • Page 11 The connection of an end-of-the-line resistance of 120Ω › must be performed on the V-READER side, the 2 resistors of 1.5KΩ must be installed on the central unit side. A and B signals of the RS485 bus must be connected on the ›...
  • Page 12 All cables and bus cable pairs that are not used must › be connected to the GND in each end. The connection of the cables to the GND and to each end is › mandatory. The supply GND must be connected to the GROUND. ›...
  • Page 13: Configuration On Visor

    Configuration on VISOR® 07.1 V-READER Note : Configuration on VISOR : V2.0.0.30 minimum and the ® firmware of the control unit must be V3.5 at a minimum. 07.2 V-READER Note : Configuration on VISOR ® V2.0.0.33 minimum and the firmware of the control unit must be V3.8...
  • Page 14: Fixation

    Fix the reader with 2 screws and the connec- Fix the reader with 2 screws and the connec- › › tor that was provided. tor that was provided. Dimensions V-READER fixation base...
  • Page 15 V-READER KP fixation base...
  • Page 16: Free Installer Hotline

    Free installer hotline A technical question? Contact our free hotline!
