S I N A P S I S . r . l .

V i a d e l l e Q u e r c e 1 1 / 1 3

0 6 0 8 3 B a s t i a U m b r a ( P G ) I t a l y

T . + 3 9 0 7 5 8 0 1 1 6 0 4 F . + 3 9 0 7 5 8 0 1 4 6 0 2

w w w . s i n a p s i t e c h . i t

i n f o @ s i n a p s i t e c h . i t

SIN.EQRPT868X

W.M-Bus 868 MHz

EN13757

unidirectional EXTENDER

User Guide

Rev 1.3

Table of Contents

Need help?

Do you have a question about the SIN.EQRPT868X and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinapsi SIN.EQRPT868X

Page 1 . s i n a p s i t e c h . i t i n f o @ s i n a p s i t e c h . i t SIN.EQRPT868X W.M-Bus 868 MHz...
Page 2: Table Of Contents
SIN.EQRPT868X – User Guide Rev. 1.3 TABLE OF CONTENTS INTRODUCTION ............................... 3 Purpose of the document ........................3 Content of the package ......................... 3 SIN.EQRPT868X TECHNICAL SPECIFICATIONS..................... 4 ASPECT OF SIN.EQRPT868X ........................... 5 Description of the SIN.EQRPT868X ...................... 5 SIN.EQRPT868X device ........................... 6 WALL MOUNTING AND PASSING OF CABLES .....................
Page 3: Introduction
This document is the complete guide for installation, configuration, and commissioning of single HOP wireless extender for W. M-Bus (EN13757-4) / OMS protocol meters, code SIN.EQRPT868X hereinafter also called Extender, able to acquire the signal from one or more communicating meters according to the 868 MHz W.M-Bus standard and retransmit received data to a SIN.RTU1X or SIN.RPT868XT in order...
Page 4: Sin.eqrpt868X Technical Specifications
• W. M-Bus mode supported: S, T, C, T+C • Max distance between SIN.EQRPT868X and W.M-Bus devices in buildings: 15 m in the same floor • and 6 m in different floors W. M-Bus area coverage: diameter 500 mt in free field – diameter 30 meters in building •...
Page 5: Aspect Of Sin.eqrpt868X
USB, thus making it possible to move around while searching for the best signal/distance compromise. Figure 1 – Example of application of the SIN.EQRPT868X coupled with Smart Gateway SIN.EQRPT868XM and to a SIN.EQRPT868XT and a SIN.EQRTUEVO1T Below find the summary of the main operational features, which will be described in this document: Extender for W.
Page 6: Sin.eqrpt868X Device
SIN.EQRPT868X – User Guide Rev. 1.3 3.2 SIN.EQRPT868X device Below find an image of the SIN.EQRPT868X device with indications regarding its operational parts: A. Cable compartment lid B. LED Figure 2 - RPT868X view Figured 3 – Connections/buttons/LEDs 1. 100..240Vac power supply input (screw clamps) 2.
Page 7: Wall Mounting And Passing Of Cables
SIN.EQRPT868X – User Guide Rev. 1.3 4. WALL MOUNTING AND PASSING OF CABLES Before making any connection, remove the power supply, complete the wiring, close the lid of the device and the power the Extender. Figure 4 – Wall mounting and passage of cable 1.
Page 8: Usb Connection To The Pc, Connection Via Radio To The Smart Gateway Sin.eqrpt868Xm And To Datalogger Sin.eqrtuevo1T, Distance And Positioning
DISTANCE AND POSITIONING Figure 5 - Connections 1. Fix the SIN.EQRPT868X extender on fastening wall at minimum distance of 20 cm from the ceiling and from the adjacent wall. 2. The maximum operating distance between W.M-Bus and SIN.EQRPT868X devices installed on the same floor is approximately 15 meters, evaluated in the absence of important obstacles such as: walls, columns or reinforced concrete beams, metal or other metal structures.
Page 9: Configuration Of The Extender
RTU and extender is consistent with that of the devices you intend to obtain. 3. Power SIN.EQRPT868X extenders. 4. Check that the W. M-Bus devices you want to receive reach the SIN.EQRPT868X through the WEB interface of the SIN.EQRTUEVO1T.
Page 10: Troubleshooting
Settings Tool 3. Not all meters are detected: • Verify that the unrecognized meters are not too far away from the SIN.EQRPT868X or that the radio signal from reinforced concrete / metal walls is not too attenuated • Verify that the SIN.EQRPT868X operating mode is set correctly using the SIN.EQRPT868X - RX Settings Tool •...
