User's Manual
Portable 45 ℓ Sandblaster
63369
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further
developments.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.
Advertisement
Related Manuals for XPOtool 63369
Summary of Contents for XPOtool 63369
- Page 1 User’s Manual Portable 45 ℓ Sandblaster 63369 Illustration similar, may vary depending on model Read and follow the operating instructions and safety information before using for the first time. Technical changes reserved! Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further developments.
- Page 2 To allow for a trouble-free complaint or return, it is important to contact our customer service team before returning your goods. Retourenabteilung WilTec Wildanger Technik GmbH Königsbenden 28 52249 Eschweiler – Germany E-mail: service@wiltec.info Tel: +49 2403 55592–0 Fax: +49 2403 55592–15 https://www.XPOtool.com Item 63369 Page 2 The Tool Experts 09 2022-1...
- Page 3 Hexagon bolt Hose clamp Safety valve Sand hose O-ring Adapter Filler cap Gasket Connection pipe Nozzles Intake socket Nozzle union nut Pressure gauge Hopper Fitting connection Cover hood Water separator filter https://www.XPOtool.com Item 63369 Page 3 The Tool Experts 09 2022-1...
- Page 4 Item 63369 Page 4 The Tool Experts 09 2022-1...
- Page 5 2. Then fix the connector (19) on the other side of the air valve. 3. If you are ready to put the sandblaster into operation, the air hose of your compressor is fixed to the connector (19). https://www.XPOtool.com Item 63369 Page 5 The Tool Experts 09 2022-1...
- Page 6 Step 4 – assembly of the sand outlet valve to the tank floor 1 = tank Mount the following components in the given order: Fitting connection (16) 2. Sand dosing valve (18B) 3. Fitting connection (16) 4. Sand outlet tube (22) https://www.XPOtool.com Item 63369 Page 6 The Tool Experts 09 2022-1...
- Page 7 The axle (5) is pushed through the holes on the side of the handlebars (6). 2. Place one wheel (2) on either end of the axle (5), then fix both wheels with the help of the splints (3). https://www.XPOtool.com Item 63369 Page 7 The Tool Experts 09 2022-1...
- Page 8 Only search for the pressure problem of the sandblaster after the gauge (15) shows zero pressure. https://www.XPOtool.com Item 63369 Page 8 The Tool Experts 09 2022-1...
- Page 9 Item 63369 Page 9 The Tool Experts 09 2022-1...
- Page 10 Volume (ℓ) Weight (㎏) Hose length (m) Max. operation pressure (bar) 6–8 (125 psi) Air consumption ( ℓ ⁄ 350–600 Nozzle size (㎜) 2 / 2.5 / 3.2 / 3.5 https://www.XPOtool.com Item 63369 Page 10 The Tool Experts 09 2022-1...
- Page 11 WilTec Wildanger Technik GmbH Königsbenden 12 / 28 52249 Eschweiler Germany Important Note: Reproduction and any commercial use (of parts) of this operating manual, requires a written permission of WilTec Wildanger Technik GmbH. https://www.XPOtool.com Item 63369 Page 11 The Tool Experts 09 2022-1...
