OPERATORS INSTRUCTIONS
Engine Hoist and Carrier Cart
READ AND UNDERSTAND THE OPERATOR'S SAFETY MANUAL THOROUGHLY
BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.
Death or serious injury could occur if this machine is used improperly.
Machine specifi c Operator's Instruction Manuals are off ered at edcoinc.com/customer-support/parts-and-manuals
EQUIPMENT DEVELOPMENT COMPANY, INC.
Phone: 800-638-3326 or 301-663-1600 • Fax: 800-447-3326 or 301-663-1607
800-638-3326 • edcoinc.com • techsupport@edcoinc.com
AND PARTS LIST MANUAL
MODEL EH1500
SKU #
99500
100 Thomas Johnson Drive, Frederick, MD 21702-4600 USA
Website: www.edcoinc.com • E-mail: techsupport@edcoinc.com
MODEL #
EH1500
E-EH1500-IPL-0123
REVISED STARTING
SERIAL # 230110001
Printed in USA
©2022
KJK
Page 1
Advertisement
Table of Contents
Related Manuals for Edco EH1500
Summary of Contents for Edco EH1500
- Page 1 E-EH1500-IPL-0123 REVISED STARTING SERIAL # 230110001 OPERATORS INSTRUCTIONS AND PARTS LIST MANUAL MODEL EH1500 Engine Hoist and Carrier Cart SKU # MODEL # 99500 EH1500 READ AND UNDERSTAND THE OPERATOR’S SAFETY MANUAL THOROUGHLY BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT. Death or serious injury could occur if this machine is used improperly.
-
Page 2: Safety Information
SAFETY INFORMATION E-EH1500-IPL-0123 SAFETY MESSAGES ELECTRICAL POWERED EQUIPMENT CONTINUED • plug, not the cord. • Unplug power cord at the machine when not in use and before servic- Indicates an imminent hazard which, if not avoided, ing. • Switch motor OFF before disconnecting power. -
Page 3: Table Of Contents
FILL IN INFORMATION BELOW HOW TO ORDER REPLACEMENT PARTS To insure product safety and reliability, always use genuine EDCO replacement parts when making Date of Purchase ______________________________ repairs to the equipment. When calling for parts, specify the MODEL and ... -
Page 4: Weights And Dimensions
E-EH1500-IPL-0123 DIMENSIONS AND WEIGHT 75 in. 1,905 mm 8 in. 19 in. 54 in. 203 mm 482 mm 1,372 mm Dimensions and Weight are approximate and 92 in. / 2,336 mm subject to change. Maximum Weight 267 lb / 121 kg 66 in. - Page 5 E-EH1500-IPL-0123 DIMENSIONS AND WEIGHT Height Height Length Length Width Width Dimensions and Weight are approximate and subject to change. Loaded Carrier Unloaded Carrier Length 37.5” / 953 mm 37.5” / 953 mm Width 20” / 508 mm 20” / 508 mm Height 77”...
-
Page 6: Part Descriptions
E-EH1500-IPL-0123 PARTS DESCRIPTIONS Crane Boom (decal 6) Jack Top Pivot Block Push Hydraulic Handle Jack (decal 1) Hoist Hook Mast (decal 2) Outrigger Latch Hoist Frame Caster Left Outrigger (decal 4) Hoist Frame (decal 3) Outrigger Wheel (nut Right Outrigger... -
Page 7: Safety Guidelines
Replace damaged or missing decals immediately. • The EDCO Engine Hoists are designed to lift up to 1500 points on a fl at, horizontal fi rm surface. They are designed to be operated by a single informed operator from a safe position near the piece of equipment that is safe from a dropped load. -
Page 8: Loading/Unloading Guide
E-EH1500-IPL-0123 INSTRUCTIONS Unloading Carrier & Assembling Hoist 1. Familiarize yourself with the descriptions on page 6 of this manual. Following the sequence below will allow for ease of hoist assembly (see illustrations on facing page and below). 2. Remove crane boom (decal 6) from carrier, set aside. - Page 9 E-EH1500-IPL-0123 INSTRUCTIONS Dismantling Hoist and Loading Carrier 1. Familiarize yourself with the descriptions on page 6 of this manual. Following the sequence below will allow for ease of hoist dismantling and loading of the carrier. Orientation of the pieces is important to note.
-
Page 10: Utilizing Hoist/ Operating Instructions
E-EH1500-IPL-0123 UTILIZING HOIST, OPERATION INSTRUCTIONS Securing load on Engine Hoist Swivel Hook 1. Always ensure the load is balanced evenly on the swivel hook, this will prevent slipping of the lifted item once lifted. An uneven load could cause the engine hoist to tip and cause severe bodily injury, possibly death, as well as property damage. -
Page 11: Maintenance Instructions
E-EH1500-IPL-0123 MAINTENANCE INSTRUCTIONS Maintaning Engine Hoist and components 1. Hydarulic Jack: Refi ll Hydraulic Jack with recommended Jack Oil. Never use a substitute. Use only HAND JACK OIL, 5W to 10W grade 15 with ram COMPLETELY collapsed, fi ll to the bottom of the fi... -
Page 12: Illustration 1: Crane Boom And Mast
E-EH1500-IPL-0123 ILLUSTRATION 1: CRANE BOOM & MAST ILLUSTRATION 1: CRANE BOOM & MAST 800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 12... - Page 13 E-EH1500-IPL-0123 PARTS LISTING - ILLUSTRATION 1: CRANE BOOM AND MAST PARTS LISTING - ILLUSTRATION 1: CRANE BOOM AND MAST Item # Part # Part Description 101241 HOIST MAST WELDMENT 101261 SPRING, COMP. .845”OD X 2”FL 101256-1 JACK, TUBE (PROVIDED WITH #7, 101256)
-
Page 14: Illustration 2: Outrigger And Hoist Frame
E-EH1500-IPL-0123 ILLUSTRATION 2: OUTRIGGER AND HOIST FRAME ILLUSTRATION 2: OUTRIGGER AND HOIST FRAME 800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 14... - Page 15 E-EH1500-IPL-0123 PARTS LISTING - ILLUSTRATION 2: OUTRIGGER AND HOIST FRAME PARTS LISTING - ILLUSTRATION 2: OUTRIGGER AND HOIST FRAME Item # Part # Part Description 101238 HOIST FRAME WELDMENT 101253 WHEEL, CASTER 4X2 10213 WASHER, FLAT 5/16 SAE ZINC 10151...
-
Page 16: Illustration 3: Carrier Cart
E-EH1500-IPL-0123 ILLUSTRATION 3: CARRIER CART ILLUSTRATION 3: CARRIER CART PART #: 99501 PART #: 99501 800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 16... - Page 17 E-EH1500-IPL-0123 PARTS LISTING - PARTS LISTING - ILLUSTRATION 3: CARRIER CART ILLUSTRATION 3: CARRIER CART Item # Part # Part Description 101246 CARRIER WELDMENT 28003 WHEEL 10 X 2-1/4 X 3/4”BRG 10306 PIN, COTTER 3/16 X 1-1/2 101248 CARRIER HANDLEBAR...
-
Page 18: Decal Sheet
E-EH1500-IPL-0123 DECAL SHEET DECAL SHEET 800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 18... -
Page 19: Limited Equipment Warranty Of Sale
E-EH1500-IPL-0123 800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 19... -
Page 20: Stop - Before Using This Product
EDCO Product Training Videos show how to use products, install tooling, and perform basic maintenance. FIND: Somewhere on this product is an EDCO QRC Training Decal. Scanning this code provides owner’s information, videos, and other training content anywhere/anytime on your mobile device.
