Summary of Contents for NHT Power5
- Page 1 Power user guide Now Hear This.. 6400 Goodyear Road, Benicia, CA 94510 800-NHT-9993...
- Page 2 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. WARNING: THIS APPARATUS MUST BE EARTHED. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
-
Page 3: Important Safety Instructions
Important Safety Instructions Read These Instructions • Retain These Instructions • Heed All Warnings • Follow All Instructions • Water and Moisture - Do not use this product near water. Do not place any objects filled with liquids, such as •... -
Page 4: Table Of Contents
Safety Information Getting started Introduction Unpacking Parts List Specifications / Features Placement Connections Audio Connections Speaker Connections Control Connections Connections with NHT Controller Power Connection Front Panel Operation Care and Maintenance Troubleshooting Warranty Statement... -
Page 5: Getting Started
Power 5 at all! Job done. If you have any technical questions, please visit nhthifi.com or call 800-NHT-9993. Unpacking Carefully unpack the Power Store all packing materials for later use, if possible. You... -
Page 6: Specifications / Features
Ideally, the Power should be placed in close proximity to the NHT Controller or surround processor. Minimizing cable lengths reduces the chance of noise pickup. Note: Due to the placement of the Power on the rear panel, do not install the Power box or similar enclosure where access to the power switch is blocked or inconvenient. -
Page 7: Connections
Where audio wires and AC power cords inter- sect, cross them at right angles. The Power5 has five inputs. It’s best before you set up your system to decide what channels are used for what speakers. Here’s a typical 5 channel configuration:... -
Page 8: Speaker Connections
The gold plated binding posts on all NHT products will accept raw wire or virtually any type of special purpose terminal. If you plan to use raw wire, strip 1/2" to 3/4" of insulation from the ends, twisting the exposed wire strands tightly. -
Page 9: Control Connections
When connected to the NHT Controller it controls on/standby/mute, just like the 12 volt trigger. NOTE: when using the NHT Bus, do not use the 12 volt trigger. The Controller can also turn on and off channels when you are listening to five channel surround or just 2 chan- nel stereo. -
Page 10: Connections With Nht Controller
Chances are you bought the Power5 with a NHT Controller and possibly NHT speakers. Here’s an exam- ple of how the system should be connected. See the NHT Controller User Guide for more information on connect- ing your NHT system. -
Page 11: Power Connection
Power Connection CAUTION: Before connecting anything make sure the Power and all your other electronic components are turned off. The Power 5 amplifier receives power via the detachable IEC style power cord. Note: Due to the placement of the Power 5’ s power switch on the rear panel, do not install the Power 5 in a wooden box or similar enclosure where access to the power switch is blocked or inconvenient. -
Page 12: Front Panel
Care and Maintanance You may need to dust or clean the Power5 every once in a while to maintain its beautiful finish. WARNING: Make sure the power cable is unplugged before cleaning. -
Page 13: Troubleshooting
Warranty Period For a period of 3 years for parts and 3 years for labor from the date this product is first purchased from an authorized NHT dealer, Now Hear This (NHT) warrants that if it fails to function properly due to a manufacturing defect, despite its being installed and operated according to these instructions and used under normal conditions, it will be either replaced or repaired with new or rebuilt parts (both at NHT's option) with a unit of comparable value without charge to you.
