Henley SUMMERHOUSE HENSUM01 Quick Start Manual

7
45mm
45mm
ROOF IS COMPLETE
Slot the loose roof boards into the roof sections and
secure each board in place using 2 x 45mm screws,
screwing through the board into the rafters.
8
Tack
E
CUT INDIVIDUAL TILES TO
COVER THE EDGES.
9
REPEAT UNTIL
TURN AROUND THE FIRST
LAYER OF SHINGLES SO
THAT THERE IS A STRAIGHT
EDGE AT THE OVERHANG
COVER EACH ROOF PANEL
STARTING AT THE BOARD
FURTHEST FROM THE
CENTRE. REPEAT UNTIL
ROOF IS COMPLETELY
COVERED
Fixing for the
door furniture
are supplied
with each item.
Eye
Hook
45mm
1381mm
2393mm
1381mm
2763mm
The Henley Summerhouse
IMPORTANT :
ASSEMBLY OF THIS must be built on a level
SHED REQUIRES THREE
concrete base approximately
ADULTS
RETAIN FOR FUTURE REFERENCE, PLEASE
READ CAREFULLY
REQUIRED TOOLS : (NOT SUPPLIED)
DRILL
POZI DRIVE SCREWDRIVER
SHARP KNIFE TO
CUT ROOF FELT
SPIRIT LEVEL
TAPE MEASURE
HAMMER
X1
Door Panel Plain Panel
HENSUMPPV2
HENSUMDPCV2
X6
103191431A2
Loose roof board 1431mm
103191532A2
Rafter
Loose roof board 1532mm
HENSUMRAFV2
FIXING PACK (HENSUMFIXP)
X4
Felt tile pack
20 tiles per pack
HENSUMSHINP
Forest Garden Ltd Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
HENLEY SUMMERHOUSE
HENSUM01
3040mm
100 to 150mm thick.
T hank you for choosing this garden building manufactured by the UK's largest manufacturer of
timber garden products. In order to gain the most benefit from it, please note the following:
- Exercise particular care and follow instructions whilst cutting felt tiles. If they are cut incorrectly,
additional felt tiles can be purchased from most good DIY retailers or garden centres.
- This building is pressure treated to ensure the longevity of all timber components and protect
against rot. This may leave a colour difference on some parts that will even out as the moisture
contents stabilize.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of
damaged parts may be deemed to be acceptance and this may affect the remedies you are entitled
to. If the product is not constructed in accordance with the instructions, or is altered in anyway (eg
painted), the manufacturer cannot be held liable for any resulting damage.
- Timber is a natural material. It will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of
suffocation.
- Important Note : Do not lean or stand on roof during assembly. Roof is not load bearing.
- If there are any technical queries with the product, please contact our customer help line on 0333
7777 089 between the hours of 8.30 am and 5.00 pm Monday to Friday.
X2
X3
PROFILE
HENSUMUPV2
Window Panel
HENSUMWPCV2
X6
X1
X6
Floor Plug
HENSUMFLPV2
HENSUMFINV2
45mm Screws Qty 48
Shingle Nails Qty 700
Hook & Eye Qty 2
70mm Screws Qty 84
ISSUE 0214
X6
X6
Upright
Roof Section
HENSUMRFV2
X1
X6
Finial Floor Section
HENSUMFSV2
120mm Screws Qty 7
Handles & Catch Plate
Tack
Lock & Keys
