Advel SPS-D Series Quick Start Manual

Din rail ac/dc power supplies and dc/dc converters
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

ALIMENTATORI AC/DC E CONVERTITORI DC/DC
AC/DC POWER SUPPLIES AND DC/DC CONVERTERS
SPS151DX
150W
SPS201DX
200W
SPS251DX
250W
Dimensioni / Dimensions
L x H x P / W x H x D
145 x 155 x 105 mm
Peso 1.8kg /Weight
Main Features:
● Versioni AC/DC e DC/DC /versions
● Vasta gamma V
e V
/wide range
in
out
● Diodo di parallelo interno /internal parallel diode
● Current sharing attivo /active current sharing
● Contatto allarme /alarm contact
● Hold up fino a 100ms /hold up time up to 100ms
● Test points frontali Vout /front test points
● Morsetti estraibili /plug-in terminal boards
SPS301DX
300W
SPS351DX
350W
Dimensioni / Dimensions
L x H x P / W x H x D
145 x 155 x 120 mm
Peso 2.0kg /Weight
Main Features:
● Versioni AC/DC e DC/DC /versions
● Vasta gamma V
e V
/wide range
in
out
● Diodo di parallelo interno /internal parallel diode
● Current sharing attivo /active current sharing
● Contatto allarme /alarm contact
● Hold up fino a 100ms /hold up time up to 100ms
● Test points frontali Vout /front test points
● Morsetti estraibili /plug-in terminal boards
__________________________________________________________________________________
www.advel.it
GUIDA DIN - DIN RAIL
SPS151DX ÷ SPS351DX
Datasheet
Segrate
MILANO
ITALY
www.advel.it
Rev.2 (11/16)
Pag. 1/6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPS-D Series and is the answer not in the manual?

Questions and answers

Related Manuals for Advel SPS-D Series

Summary of Contents for Advel SPS-D Series

  • Page 1 Segrate MILANO ITALY www.advel.it ALIMENTATORI AC/DC E CONVERTITORI DC/DC GUIDA DIN - DIN RAIL AC/DC POWER SUPPLIES AND DC/DC CONVERTERS SPS151DX 150W SPS201DX 200W SPS251DX 250W Dimensioni / Dimensions L x H x P / W x H x D 145 x 155 x 105 mm Peso 1.8kg /Weight...

  • Page 2: Power Rating

    Contatto allarme RMT: pulito SPDT (relè 10A) Mounting: DIN-rail 35x15/7.5 according to EN60715 Fissaggio: guida DIN 35x15/7.5 normalizzata EN60715 Mechanic: anodized aluminium case and heatsink. Meccanica: contenitore e dissipatore in alluminio anodizzato __________________________________________________________________________________ SPS151DX ÷ SPS351DX Pag. 2/6 Datasheet Rev.2 (11/16) www.advel.it...

  • Page 3: Troubleshooting

    Remove the load. If the V doesn’t go high, try to rotate the Vout ADJ. trimmer clockwise. If V continues to stay low, then the power supply is in failure. _________________________________________________________________________________ SPS151DX ÷ SPS351DX www.advel.it Datasheet Rev.2 (11/16) Pag. 3/6...
  • Page 4 Advel Technical Dpt. (supposed a 2mt maximum cables length). ingresso e uscita suggeriti da Advel (supposta una lunghezza dei cavi pari ad un massimo di 2mt).
  • Page 5 × × ≥ × ≥ × – 20%) – 20%) in MIN in-rated of the power supply in MIN in nominale dell’alimentatore _________________________________________________________________________________ SPS151DX ÷ SPS351DX www.advel.it Datasheet Rev.2 (11/16) Pag. 5/6...
  • Page 6 - the wiring cables are well sized, - i cavi di cablaggio siano dimensionati correttamente, - sufficient convection is guaranteed ! - sia garantita la corretta circolazione dell’aria! ADVEL Srl Via Miglioli 13, Segrate ● Milan ● ITALY Web: www.advel.it ●...

This manual is also suitable for:

Sps151dxSps201dxSps251dxSps301dxSps351dx
