Euro-Pro Shark UV610NW Quick Start Manual

Replacement Battery Pack

Item # XBP610N
for Model UV610NW

TO MAXIMIZE THE LIFE OF YOUR NI-CD BATTERIES

1. Charge for a minimum of 20 hours before initial use. Failure to do so will reduce the product's
battery life significantly.
2. Do not store the unit with the charging adaptor attached and plugged in.
3. Only recharge when the batteries are fully discharged (or as close to fully discharged as
possible).
4. Do not store in areas of high temperature or humidity.
5. After three (3) months of storage, the product should be fully discharged and then recharged
to maximize battery power.
6. Use only the charger supplied with the product. If other chargers are used, the batteries can
fail causing damage to the battery, product or personal property. Ni-Cd batteries have a long
useful life but at some time they will need to be replaced. To purchase replacement batteries
visit www.shark-vac.com.
NOTE:
1. The on/off switch must be in the "OFF" position in order to charge the unit. If the
charging indicator does not light, depress the on/off switch once.
2. If the product has never been used or has been stored for an extended period of
time without use – it will take several complete charge and discharge cycles to
realize the full operational time of your product.

CHARGING THE CORDLESS SWEEPER

1. Connect the charger plug to the charging jack or hole on the back of the sweeper. Plug the
the charging adapter into the wall outlet. (120V.,60Hz.) Use only TechWorld Charger
AD-0920-UL, rated output DC 9V,200mA.
2. This cordless sweeper is powered by Ni-Cd batteries. Before first use, they must be charged
for a minimum of 20 hours.
3. Once the batteries are fully charged, the cordless sweeper will run for approximately 35 to 45
minutes before recharging is required.
4. When recharging the unit, the "On/Off" switch must be in the "OFF" position.
5. The charging light indicator on the top of the sweeper will illuminate to indicate that the
sweeper is properly charging.
6. To recharge, repeat step #1 above. Charging times will vary depending upon the amount of
usage between charging cycles.
NOTE:
If, when you place the sweeper to recharge and the charging indicator light does NOT
illuminate, then press the On/Off button once to turn the sweeper off. The charging indicator light
should now light up.
NOTE:
Peak performance may only be realized after the unit has been charged and discharged
two (2) or three (3) times.
IMPORTANT:
To maintain peak performance of your cordless sweeper, it is recommended that
the unit be fully discharged, then completely re-charged at least once a month.
CAUTION
• Use only with the battery pack supplied with the unit.
• Do not attempt to remove the battery pack from the unit to charge it.
• Never attempt to throw the battery pack or unit into a fire or incinerate it.
• Do not attempt to remove or damage the battery casing.
• Battery must be recycled or disposed of properly at the end of it's service life.
USA: EURO-PRO Operating LLC
94 Main Mill Street, Door 16
Plattsburgh, N.Y., 12901
Tel: 1 (800) 798-7398
Printed in China
Canada: EURO-PRO Operating LLC
4400 Bois Franc
St. Laurent, QC H4S 1A7
www.sharkvac.com
Rev. 09/05
