- Page 1 97681B Load Convenient Test Stand Electric Vertical Type User's Manual Please read carefully before use. Before its use, please read carefully "Safety Precautions" along with Handling Instructions and use appropriately.
- Page 2 Before Installation, Operation, Maintenance-inspection, be sure to read carefully this Instruction Manual and use the equipment appropriately. Use the equipment after carefully reading all the caution items, safety information, and other discriminations. In this User's Manual, the Safety Precautionary Items are divided into different Ranks viz. "Danger", "Warning"...
- Page 3 CAUTION Do not install at the place with excessive If the place of installation or installation situation humidity or the place with direct water contact. is bad, it is feared that the noise may increase Fire due to Electric Shock, Electric Leakage as and hence install it appropriately.
- Page 4 Before Use From Force Gauge Installation to Measurements. Confirmation of Accessories. Specifications List of All Parts Names and Functions of Operation Panel. Preparation Installation of Force Gauge. Operation. Basic Operations. Mode Shifting. Operation Mode. Jogging Mode. (JOG) Manual Mode. (MANU) 1 Cycle Mode.
- Page 5 Before Use. From Force gauge Installation to Measurements. This Stand is installed on Digital Force Gauge (FGP Series, FGPX Series) made in this company and is set to perform all types of Load Tests. Related to its utilization, execute it from installation to measurement with the following procedure. When you are in difficulty, deal it with the Trouble Shooting. Installation of Force Gauge.
- Page 6 Specifications Series Model Low Speed Specifications High Speed Specifications Measuring Load Load Resistance Forwarding Speed Speed Settings Set the Speed through Operation panel. Stroke Display Parts LCD 3 Digits indicates movement speed, Operation Mode. Movement speed Display Operation Mode Manual (MAU), Jogging (JOG), 1 Cycle (SIG), Continuous (CON). Over Load Input Input Stops by FGPX (FGP) Over Load Signal...
- Page 7 Names of Parts Cable Clip Upper Limit knob Force Gauge Force Gauge Installation Board Lower Limit knob Measuring Table Emergency Stop Switch Operation Panel Names of Operation Panel and their Functions...
- Page 8 Names Function Speed Setting Key (UP) Perform the Setting of Movement Speed at Manual (MANU), JOGGING (JOG) Mode and Movement Speed at PUSH/PULL Operation at 1 Cycle (SIG), Continuous (CON) Mode. If pressed continuously, the movement speed increases/decreases continuously at the rate of 10 digits. Speed Setting Key (DOWN) At the time of Manual (MANU), Jogging (JOG) Mode operation, during the pressed condition, the movement speed becomes maximum.
- Page 9 Preparation Installation of Force Gauge Using the Allen Key Spanner provided in the Accessories, remove the installation bolts, and thus remove the Force Gauge Installation Board. Install the Force Gauge to the Force Gauge Installation Board. With Installation Bolts, Install to the Stand. Set the Force Gauge to the Installation Board.
- Page 10 Movement. Basic Movement. While aligning, take sufficient care, as there is a fear of catching of hand, finger, and clothes and may cause injury. Force Gauge Power Supply ON. (Example) Tension Test of Wire. Stand FGS-50E Power Supply ON. Power Supply Switch of Stand Back-side to be put to ON. Remove your hands from the Stand Moveable Parts or the Force Gauge and then put the Power Supply to "ON".
-
Page 11: Manual Mode
Transition Mode. If you want to perform Load Test Manually by pressing PUSH or PULL key. Examples. Pressing the PULL Key at one time only, if you want to make move the Force Gauge up to PULL Limit Dog. Select Movement Mode. By only Pressing the PUSH Key as required, if you want to make move the Force Gauge. - Page 12 Jogging Mode (Jog) Content Jogging Movement is performed While the PUSH Key or PULL Key is in pressed condition, it moves towards PUSH or PULL. If you release the PUSH Key or PULL Key, it stops. Movement speed It changes by UP, DOWN Key. The speed setting of JOG Mode and MANU Mode becomes common. Speed Variation is also possible during the movement.
- Page 13 1 Cycle Mode (SIG) Contents 1 Cycle (Compression. Expansion) Movement is performed. In between the Limit Switches, it repeats movement for 1 time only. As regards PUSH Direction and PULL Direction, it moves with its respective advanced speed setting and by memorizing the movement speed, If either PUSH Key or PULL Key is pressed, it starts moving towards PUSH or PULL Direction When STOP Key is pressed, the movement stops.
- Page 14 Continuous Mode (CON) Contents Performs movement of Continuous Mode. It performs the continuous repeated movement in between the Limit Switches. When the PUSH Key or PULL Key is pressed, it moves towards PUSH or PULL Direction. When STOP Key is pressed, the movement stops. Stops by Limit Switch in ON position.
- Page 15 Speed Setting The Movement Mode becomes either 1Cycle Mode (SIG) or Continuous Mode (CON) and during the Stop Movement, with pressing the MAX Key, it enters/turns into the Speed Setting. Setting the PUSH Direction Movement Speed by UP/DOWN Key, if the MAX is pressed, it turns into the PULL Direction Movement Speed Setting.
- Page 16 Error Display. Lower Limit knob is in ON position. In the normal movement also, this Sub Display, LMT and MODE display Display is generated... light -up alternately. Main Display becomes PUSH. Upper Limit knob is in ON position. In the normal movement also, this Display is generated.
-
Page 17: Outer Dimensions
Outer Dimensions. Force Gauge Installation Bracket Parts Details. Cable Clip. Measuring Table Parts Details. Depth 9. Force Gauge Installation Bracket. Stro Force Gauge (sold separately). 400. Measuring Table.
