MiCOM H35x
Technical Manual
Global Documentation
Version:
Publication Reference:
2
H35x/EN GL/D23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MiCOM H35x and is the answer not in the manual?

Questions and answers

Summary of Contents for Alstom MiCOM H35x

  • Page 1 H35x/EN GL/D23 © - ALSTOM 2013. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is provided without liability and is...

  • Page 3: Table Of Contents

    Handling of Electronic Equipment Packing and Unpacking Guarantees Copyrights & Trademarks 1.9.1 Copyrights 1.9.2 Trademarks Warnings regarding use of Alstom Grid products 1.9.3 INTRODUCTION MiCOM Switches Product Range Naming of MiCOM Ethernet Switches MiCOM H35x FUNCTIONAL DESCRIPTION MiCOM H35x Product Range Fast redundant ring capability 3.2.1...
  • Page 4 Address lookup 3.6.2 Auto-negotiation and speed-sensing 3.6.3 Forwarding 3.6.4 Priority tagging 3.6.5 SNMP v2 TECHNICAL DATA MiCOM H35x Range CONFORMITY Ethernet Port Characteristics 4.3.1 10/100BaseTx Port 4.3.2 100BaseFx Multimode Port (H352) 4.3.3 100BaseFx Single Mode Port (H354) 4.3.4 100BaseFx Multimode Port (H356, H358) 4.3.5...
  • Page 5 Global Documentation H35x/EN GL/D23 MiCOM H35x Page 3/38 Ethernet Connection 7.5.1 Ethernet cable type 7.5.2 Ethernet optical fiber SETTINGS Dip switch description Address of the repeater 8.2.1 Configuring the address 8.2.2 Example: defining address “10” IP Address of the repeater...
  • Page 6 FIGURE 18: ETHERNET OPTICAL FIBER – ST FIGURE 19: ETHERNET OPTICAL FIBER – SC FIGURE 20: DIP SWITCHES FIGURE 21: DIP SWITCHES EXAMPLE FIGURE 22: IP ADDRESS FIGURE 23: MiCOM H35X LABEL FIGURE 24: POWER SUPPLY CONNECTOR FIGURE 25: FIBER BUDGET FIGURE 26: FIBER BUDGET EXAMPLE...

  • Page 7: Safety And Handling

    However, the manuals cannot cover all conceivable circumstances or include detailed information on all topics. In the event of questions or specific problems, do not take any action without proper authorization. Contact the appropriate Alstom technical sales office and request the necessary information.

  • Page 8: Symbols

    H35x/EN GL/D23 Global Documentation Page 6/38 MiCOM H35x Symbols For safety reasons the following symbols which may be used on the equipment or referred to in the equipment documentation, should be understood before it is installed or commissioned. Caution: refer to equipment documentation...

  • Page 9: De-Commissioning And Disposal

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 7/38 The recommended minimum protective conductor (earth) wire size is 2.5 mm² (3.3 mm² for North America) unless otherwise stated in the technical data section of the equipment documentation, or otherwise required by local or country wiring regulations.

  • Page 10: Technical Specifications For Safety

    H35x/EN GL/D23 Global Documentation Page 8/38 MiCOM H35x Technical specifications for safety Unless otherwise stated in the equipment technical manual, the following data is applicable. 1.5.1 Protective fuse rating The recommended maximum rating of the external protective fuse for equipments is 16A, high rupture capacity (HRC) Red Spot type NIT, or TIA, or equivalent.

  • Page 11: Packing And Unpacking

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 9/38 More information on safe working procedures for all electronic equipment can be found in IEC 60147-0F and BS5783. If you are making measurements on the internal electronic circuitry of any equipment in service, it is preferable that you are earthed to the case with a conductive wrist strap.

  • Page 12: Copyrights & Trademarks

    H35x/EN GL/D23 Global Documentation Page 10/38 MiCOM H35x Copyrights & Trademarks 1.9.1 Copyrights Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical, including photocopying, recording, storing in an information retrieval system, or translating, in whole or in part, without the prior written consent of 1.9.2...

  • Page 13: Introduction

    On the media side, MiCOM H35x supports 10BaseT, 100BaseTX and 100BaseFX as specified by the IEEE 802.3 standard. The MiCOM H35x is a plug-and-play device. It can run with the factory settings. However, to adapt the switch to your application, you only need to configure the switch number using the...

  • Page 14: Functional Description

    The MiCOM H35x is designed to be an Ethernet switch with a DIN RAIL mounting. MiCOM H35x Product Range The MiCOM H35x range is dedicated to ultra fast redundant Ethernet rings, and is defined by the type of Ethernet connector. All the MiCOM H35x equipment range has at least two copper connections via RJ45 connectors, with speed automatically adjusted by the external emitters to 10 or 100 Mbps.

  • Page 15: Micom Hx5X Ethernet Switch With Self-Healing Ring Facilities

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 13/38 3.2.2 MiCOM Hx5x Ethernet switch with self-healing ring facilities The MiCOM Hx5x is a standard IEEE802.3 Ethernet switch enhanced with the self-healing manager (SHM). The diagram below shows the internal architecture of such a device.

  • Page 16: Performance

    H35x/EN GL/D23 Global Documentation Page 14/38 MiCOM H35x Primary fiber switch switch switch switch switch Secondary fiber S0206ENa FIGURE 3: NOMINAL REDUNDANT ETHERNET RING ARCHITECTURE WITH MiCOM HX5X SWITCHES Primary fiber switch switch switch switch switch Secondary fiber S0207ENa FIGURE 4: ETHERNET RING ARCHITECTURE WITH MiCOM HX5X SWITCHES AFTER FAILURE 3.2.4...

  • Page 17: Benefits

    The copper ports are half/full duplex and auto-sense the transmission speed. They will auto- negotiate with the connected device to determine the optimal speed. When the connected device is only capable of transmitting at 10 Mbps, the MiCOM H35x follows at 10 Mbps.

  • Page 18: 100Base Fx

    Address lookup Each Ethernet device inserts its unique “MAC address” into each message it sends. The port on the MiCOM H35x used for a given MAC address is automatically learnt when a frame is received from that address. Once an address is learnt, the MiCOM H35x will forward frames to the appropriate port.
  • Page 19 *Port number: 1 to 6 for the RJ45, port 7 management, port 8 ring 3.6.5.2 SNMP Software Various “SNMP Client software” tools can be used with the MiCOM H35x range. does not provide such tools. Any MIB Browser Software performing the basic SNMP operations (such as GET,...

  • Page 20: Technical Data

    H35x/EN GL/D23 Global Documentation Page 18/38 MiCOM H35x TECHNICAL DATA MiCOM H35x Range 100 BaseFx 100 BaseFx Ports 10/100BaseTx Copper Single Mode Multimode (ring) (ring) MiCOM H352-V2 2 (ST) MiCOM H354-V2 2 (SC) 100 BaseFx 10/100Base 10/100BaseFx 100 BaseFx Ports...

  • Page 21: 100Basefx Multimode Port (H356, H358)

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 19/38 4.3.4 100BaseFx Multimode Port (H356, H358) Fiber port connector 62.5/125 µm or 50/125 µm Optimal fiber cable Center wavelength 1310 nm TX output power -19 dBm RX input sensitivity -31 dBm Maximum distance...

  • Page 22: Ethernet Management

    H35x/EN GL/D23 Global Documentation Page 20/38 MiCOM H35x 4.4.4 Ethernet Management Standards IEEE802.3, 802.3u, 802.3x, 802.1p Forwarding mode Store and forward Memory bandwidth 2 Gbps MAC Address Address learning Automatic Broadcast storm protection Limited to 5% Illegal frame Dropped per 802.3...

  • Page 23: Climatic

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 21/38 4.5.3 Climatic Type Test Name Conditions Type Test Standard Extended dry heat – Test Ca: +55 °C / 20d, +70 °C IEC 60068-2-2 / 1993 Operating Cold Test - Operating Test Ab: -40 °C / 96h...

  • Page 24: Mechanical

    H35x/EN GL/D23 Global Documentation Page 22/38 MiCOM H35x 4.5.5 Mechanical Type Test Name Conditions Type Test Standard Free Fall Test 2 falls of 5 cm (not powered) IEC 60068-2-31 Free Fall Packaging Test 25 falls of 50 cm (Packaging) IEC 60068-2-32 Vibration Response –...

  • Page 25: Human Machine Interface (Hmi)

    H35x/EN GL/D23 MiCOM H35x Page 23/38 HUMAN MACHINE INTERFACE (HMI) Several LEDs are used to indicate the status of the MiCOM H35x ports and links. H352-V2 HMI L1 to L6 Port activity L7 and L 10 Link status on the ring...

  • Page 26: H35X Leds

    H35x/EN GL/D23 Global Documentation Page 24/38 MiCOM H35x H35x LEDs The table below indicates the function of each LED: N° Color Description Comments Power GREEN Power is Applied Power is OFF Alarm power supply Power supply fault No default Alarm Ring RsEp...

  • Page 27: Installation

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 25/38 INSTALLATION The MiCOM H35x can be easily mounted on a standard DIN Rail.

  • Page 28: Connection

    H35x/EN GL/D23 Global Documentation Page 26/38 MiCOM H35x CONNECTION MiCOM H3xx must be connected to the earth according to product safety standard EN60255-27:2005 clause 5.1.5, using the protective conductor (earth) terminal located on the bottom of the case. Connection of the protective conductor (earth) The MiCOM H3xx must be earthed, for safety reasons, by connecting the protective conductor (earth) to the M4 threaded stud which is marked with the symbol shown.

  • Page 29: Power Supply Wiring

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 27/38 Power supply wiring Connection to the power supply (main and/or redundant) requires 4 mm² screw type terminals. The diagram is identical for AC and DC power. Both power supplies are isolated from each other.

  • Page 30: Fail-Safe Contacts

    H35x/EN GL/D23 Global Documentation Page 28/38 MiCOM H35x Fail-safe contacts The screw type terminals are 4 mm 1 C 2 3 Fail-safe Self-healing Rp-Es 1 Self-healing Rs-Ep 2 Power S0521ENb FIGURE 16: FAIL-SAFE CONTACTS WIRING Pin No. Contact meaning Power supply Alarm (see section 9.2 for configuration)

  • Page 31: Ethernet Connection

    Page 29/38 Ethernet Connection The Ethernet-based communication available in the MiCOM H35x uses either optical fiber media (ST/SC/LC connector) or 4 twisted pair cable. If the equipment is located at a long distance (>100 m for RJ45) from the communication equipment or multiplexer, or if the cables run through a noisy area, then optical communication should be used to interconnect the IEDs and the communication equipment.

  • Page 32: Figure 19: Ethernet Optical Fiber - Sc

    H35x/EN GL/D23 Global Documentation Page 30/38 MiCOM H35x The H354-V2 P/N 2071684 A02 (single mode fiber) has a type SC connector. FIGURE 19: ETHERNET OPTICAL FIBER – SC The H356-V2 P/N 2071767 A03 (multimode fiber) has a type LC connector.

  • Page 33: Settings

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 31/38 SETTINGS Dip switch description 8 - Power Supply Alarm ON = 0 OFF = 1 1 to 7 - Repeater Address S0522ENb FIGURE 20: DIP SWITCHES Name Function Repeater address Define the repeater address on the ring...

  • Page 34: Ip Address Of The Repeater

    When positioned to “ON”, “Fail-safe” contact 1 indicates the redundant power supply status. When positioned to “OFF”, “Fail-safe” contact 1 is unused. Label A rectangular label on top of MiCOM H35x behind Auxiliary Power input J1 J2, gives two major indications: •...

  • Page 35: Maintenance

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 33/38 MAINTENANCE Scope This chapter describes the maintenance procedure for the MiCOM H3xx. Recommendation before maintenance operations BEFORE CARRYING OUT ANY WORK ON THE EQUIPMENT, THE USER SHOULD BE FAMILIAR WITH THE CONTENTS OF THE...

  • Page 36: Diagnosis Facilities

    H35x/EN GL/D23 Global Documentation Page 34/38 MiCOM H35x Diagnosis facilities When a maintenance action is planned, the operator should prepare, act and report. The minimum preparation is to obtain the commissioning Record Sheet of installed device in order to check the product configuration and its history. The user should also apply personal experience in addition to this manual.

  • Page 37: Applications

    Global Documentation H35x/EN GL/D23 MiCOM H35x Page 35/38 APPLICATIONS 10.1 Fiber Optic budget calculations Optical power is expressed in Watts. However, the common unit of power measurement is the dBm, defined by the following equation: Power (dBm) = 10 log Power (mW) / 1 mW.

  • Page 38: Example 1: Between Repeaters

    H35x/EN GL/D23 Global Documentation Page 36/38 MiCOM H35x 10.1.1 Example 1: between repeaters Link budget 12 dB 19 dB Connector loss 0.8 dB 0.8 dB Safety Margin 4 dB 4 dB Allowed link attenuation 6.4 dB 13.4 dB Typical cable attenuation 1 dB/km 0.4 dB/km...

  • Page 39: Glossary

    100Base TX device to determine the optimal speed. When the connected device is only capable of transmitting at 10 Mbps, the MiCOM H35x follows the 10 Mbps. Cat. 5 Category 5 unshielded twisted pair (UTP) cabling. An Ethernet network operating at 10 Mbits/second (10BASE-T) will often...
  • Page 40 H35x/EN GL/D23 Global Documentation Page 38/38 MiCOM H35x BLANK PAGE...
