Dracast
The DRX Series LED Smart Panel Light uses high powered LEDs, giving it advantages such as high luminous
efficiency, long life, high CRI & TLCI, etc. The solid aluminum housing allows efficient heat dissipation, while still
enabling it to be ultra-thin, stable and easy to carry. It can be controlled manually, or via Bluetooth with a smart phone APP.
This light can be used in a wide variety of applications such as digital or film photography, videos, film and TV
shooting, studio photography, and much more.
Ⅰ. Main Light Structure
(1)
Three-Way Power Switch
(4)
LCD Display
(7)
Side Yoke Knob
(10)
Bottom Yoke Knob
II. In The Box
1.
Light body with yoke
3.
DC15V power adapter
III. Digital Display Features
① CCT: (corrected color temperature )
② DIM: (light intensity/brightness)
③ Light No.
④ Group No.
⑤ Master/Slave Indicator
⑥ Battery indicator
DRX Series LED Smart Panel Light
(2)
Power Input
(5)
Power/Color Temperature Button
(8)
Accessory Mounting Hole
2.
Power cable
4.
Manual
(3)
Dual-NPF Battery Plate
(6)
LED Surface
(9)
Holder
Advertisement
Table of Contents
Summary of Contents for Draco DRX Series
- Page 1 DRX Series LED Smart Panel Light The DRX Series LED Smart Panel Light uses high powered LEDs, giving it advantages such as high luminous efficiency, long life, high CRI & TLCI, etc. The solid aluminum housing allows efficient heat dissipation, while still enabling it to be ultra-thin, stable and easy to carry.
- Page 2 IV. Light Operation Powering up the light Connect the power adapter to an AC power outlet, insert the adapter cable end into to the power input (2), turn on the power switch (1) to DC port, adjust brightness and color. The light can also use 2 x NP-F batteries to power up.
- Page 3 9. Do not touch the power cord with wet hands. 10. When removing the power plug, always pull the plug rather than the power cord. 11. Do not attempt to repair the light. If there are any problems, turn off the light and contact Draco Broadcast. VII. Product SpecificationS...
- Page 4 VIII. Troubleshooting When using this product, you may encounter the following problems: Description Cause Trouble-shooting Dimmer knob on 0% Rotate the dimmer knob clockwise. Power adapter does not match specifications Use standard adapter. No reaction after power on Install new battery or charge the Low battery batteries before use.
