BETAFLIGHT Cetus X FPV Kit Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

QUICK START GUIDE
Cetus X FPV Kit (Betaflight Firmware Version)
ExpressLRS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cetus X FPV Kit and is the answer not in the manual?

Questions and answers

Summary of Contents for BETAFLIGHT Cetus X FPV Kit

  • Page 1 QUICK START GUIDE Cetus X FPV Kit (Betaflight Firmware Version) ExpressLRS...
  • Page 2 1. Angle Mode ANGL is displayed in the OSD. Pilot needs to control the flight altitude by operating the throttle joystick. The quadcopter will maintain a horizontal attitude when the direction joystick is moved to the center. The operation is relatively simple. Novice pilot can achieve simple flight with a little practice because the drone keeps its levelled position once the pilot lets go of the stick.
  • Page 3 2. Horizon Mode HOR is displayed in the OSD. Pilot needs to control the flight altitude by operating the throttle joystick. The quadcopter will maintain a horizontal attitude when the direction joystick is moved to the center. Unlike Angle mode, you can do flips and rolls when the stick is at full deflection in Horizon mode.
  • Page 4 3. Air Mode Air is displayed in the OSD. The altitude and attitude of the quadcopter are manually controlled by pilot. The quadcopter will maintain its current attitude when the direction joystick is moved to the center. Acrobatic flight is possible. The operation is difficult and pilot needs a lot of practice.
  • Page 5 4. Turtle Mode CRASH FLIP SWITCH is displayed in the OSD. If the quadcopter crashes into the ground and the fuselage is flip, the turtle mode can be activated to reverse the motor and turn the quadcopter back to the front. Ground...
  • Page 6 5. VTX Frequency and Power Switching The Cetus X (Betaflight Version) uses M04 VTX with a maximum power of 400mW. Changing frequency and output power value through buttons is not supported by this VTX, which requires OSD Menu of Betaflight firmware.
  • Page 7 Watch a tutorial video on how to get started: https://www.youtube.com/watch?v=LkBWRiEGKTI NOTE: Cetus X FPV Kit (Betaflight firmware version) has no auxiliary function for both vertical and horizontal flight. If you want auxiliary flight function for easy start, please check the Cetus X FPV Kit (Cetus firmware version).
