HONEY JOY CHILDREN'S ELECTRONIC TOY ATV Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Please read all instructions carefully and keep it for future reference.
Warnings:
Attention! Use it with protective equipment.
Attention! Not use it in the traffic.
Attention! The product is not suitable for the children under 3 years.
General Warnings:
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can lead to a danger.
We recommend that, where possible, all items are assembled near to the area in which they
will be placed in use, to avoid moving the product unnecessarily once assembled.
Ensure a secure surface during construction, und place the product always on a flat, steady
and stable surface.
Please use the product carefully, as the product requires great skill, avoid accidents by the
user or others, by fall or collision.
Please wear suitable protective equipment during use, e.g. protective helmet, gloves, knee
pads, elbow pads etc.
CHILDREN'S
ELECTRONIC TOY ATV
OWNERS MANUAL
with Assembly Instructions
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important information.
Before first time use, charge the battery for at least 8-12 hours.
• Suitable for 3+ Years
• Maximum user weight: 110 lbs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHILDREN'S ELECTRONIC TOY ATV and is the answer not in the manual?

Questions and answers

Summary of Contents for HONEY JOY CHILDREN'S ELECTRONIC TOY ATV

  • Page 1 CHILDREN’S ELECTRONIC TOY ATV Please read all instructions carefully and keep it for future reference. Warnings: Attention! Use it with protective equipment. Attention! Not use it in the traffic. Attention! The product is not suitable for the children under 3 years. General Warnings: The product must be installed and used under the supervision of an adult.

  • Page 2: Parts List

    About Your New Vehicle Parts List On the purchase of your new Ride-On. Q’TY (PCS) This ride-on car will provide your child with many miles of riding of enjoyment. To help assure REMARK PART NAME you and your rider a safe ride we ask you to please read this manual carefully, and keep it for future reference.

  • Page 3: Parts Diagram

    Parts Diagram Safety PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. ADULT DIRECT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.

  • Page 4: Attach The Front Wheels

    Attach the Front Axle Attach the Front Wheels Front bottom view Front axle 1. Slide a Φ12 washer onto the front axle. 2. Slide a wheel onto the front axle. 3. Slide a Φ12 washer onto the front axle. Hole on the front 4.
  • Page 5 Attach the Handle bar & Front Luggage Carrier Attach the Rear Driving Wheels Tools required: Rear bottom view Long nose pliers & screwdriver. Semicircular part Cut off the rubber band over the rear gear boxes. 1. Slide a wheel onto the rear axle. Ensure the wheel match up with the gear box. Turn the vehicle body over.
  • Page 6 Attach the Front Roll Bar & Back Rest Attach the Rear Luggage Carrier & Rear Roll Bar Front view Rear view 1. Turn the luggage carrier upside down. Fit the rear roll bar to the luggage carrier as shown. 1. Fit the front roll bar to the vehicle body. 2.
  • Page 7 Use your New Ride-on Connect the Power Supply & Attach the Seat Seat inside view IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damaging the gears and motor. Red vehicle connector WITH R/C, 4WD B a t t e r 1.
  • Page 8 Use the Remote Controller (IF EQUIPED) Charging WARNING! ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! Brake button Forward button WARNING! Right button Reverse button This product with Charging Protection: when charging, all functions will be cut off! Only an adult can charge and recharge the battery! •...

  • Page 9: Troubleshooting Guide

    Maintaining Troubleshooting Guide Possible Cause Solution Problem • It is parents' responsibility to check main parts of the toy before using, Vehicle does not run Battery low on power Recharge battery. must regularly examine for potential hazard, such as the battery, charge,cable or cord, plug, screws are fastening enclosure of other parts Thermal fuse has tripped Reset fuse, see <Fuse>...

  • Page 10: Disposal Of Battery

    Fuse The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for 20 seconds and then turned ON again.
