Rolls SX21 Owner's Manual

LIMITED WARRANTY
This product is warranted to the original consumer purchaser to be
free from defects in materials and workmanship under normal installation, use
and service for a period of one (1) year from the date of purchase as shown on
the purchaser's receipt.
The obligation of Rolls Corporation under this warranty shall be
limited to repair or replacement (at our option), during the warranty period of
any part which proves defective in material or workmanship under normal
installation, use and service, provided the product is returned to Rolls Corpora-
tion, TRANSPORTATION CHARGES PREPAID. Products returned to us or to
an authorized Service Center must be accompanied by a copy of the purchase
receipt. In the absence of such purchase receipt, the warranty period shall be one
(1) year from the date of manufacture.
This warranty shall be invalid if the product is damaged as a result of
defacement, misuse, abuse, neglect, accident, destruction or alteration of the
serial number, improper electrical voltages or currents, repair, alteration or
maintenance by any person or party other than our own service facility or an
authorized Service Center, or any use violative of instructions furnished by us.
This one-year warranty is in lieu of all expressed warranties,
obligations or liabilities. ANY IMPLIED WARRANTIES, OBLIGATIONS, OR
LIABILITIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICU-
LAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE ONE YEAR
DURATION OF THIS WRITTEN LIMITED WARRANTY. Some states do not
allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
IN NO EVENT SHALL WE BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS
OR ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, WHATSO-
EVER. Some states do not allow the exclusion or limitation of special,
incidental or consequential damages so the above limitation or exclusion may
not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
SX21
Tiny Two-Way Crossover
The SX21 is a unique frequency dividing device for small
sound reinforcement applications. The unit features a 24
dB/Octave rolloff rate, a frequency dividing range of
100Hz to 5kHz, an external power supply for noise
reduction, and a power supply Loop-through for powering
additional units. All this in a compact package with a
compact price.
• 24 dB/Octave rolloff
• 1/4" unbal. Input and Outputs
• 100Hz to 5 kHz crossover range (may be
factory modified)
• External power supply for low noise operation
SPECIFICATIONS
Input Impedance:
Output Impedance:
Headroom:
Power Requrements:
Size:
Weight:
Rolls Corporation
Salt Lake City, UT
8/99
10KW
1KW
+10 dBV
12 - 16 VDC, 150 mA
4.25" x 3.625" x 1.5"
1 lb.
