- Page 1 INSTRUCTION MANUAL UMC200D UHF Diversity Antenna Multicoupler Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com...
- Page 2 UMC200D LECTROSONICS, INC.
-
Page 3: Table Of Contents
Rack Mount Multicoupler The UMC200D system is a high quality, multicoupler for The integral RF/Power distribution module provides Lectrosonics UHF compact diversity receivers. Multi- convenience of operation from a common antenna channel problems such as interaction of receivers, system and power supply without degrading the perfor- intermodulation and desensitization, etc. -
Page 4: General Technical Description
UMC200D General Technical Description The Multi-Channel Wireless Systems consist of two A precision splitter/isolator divides the RF signal into sub-systems; the frame which contains the receivers four isolated signals preventing spurious RF coupling and the receiver mounting hardware, and the RF/power between receivers. -
Page 5: Front Panel Description
Rack Mount Multicoupler Front Panel Description The front panel contains only one control - the Power Many different receivers can be mounted within the switch. frame. Please refer to the separate receiver manual for a description of the controls and features of each individual receiver. -
Page 6: Assembly And Installation
UMC200D Assembly and Installation Assembly of the unit consists of installing the receivers WARNING: The receivers installed in the unit in the frame and connecting the antenna leads and must fall between the frequencies indicated on power cables to each receiver. -
Page 7: Installing The Wire Cover
Rack Mount Multicoupler 4. Secure the receivers into the frame by tightening Run the power cords over the top, and feed them between the five counter-sunk phillips head screws in the the receivers as shown. This rectangular metal rod. Don’t overtighten! will help prevent accidental 5. -
Page 8: Troubleshooting
UMC200D Troubleshooting Symptom Possible Cause NO POWER LEDs OR AUDIO 1) Power switch in the OFF position. Switch to ON. POWER AND MODULATION LEDs ON, 1) No audio connection to recorder or mixer. BUT NO AUDIO Check connections. POWER LEDs ON, NO MODULATION LEDs 1) Transmitters not on or in mute position. -
Page 9: Antenna Use And Placement
FR4 fiberglas in a rugged assembly. It is the same frequency band. Two unique models are available in several models, offered by Lectrosonics to help optimize reception in a standard version, one any location or installation. with a built-in amplifier and... -
Page 10: Specifications
UMC200D Specifications RF Gain: 0.5 to 1.5dB Bandwidth Ceramic resonators, 50 MHz bandwidth, 470 to 865 MHz. RF Outputs: Eight outputs, 50 Ohm, BNC Output Isolation: 25dB min, any output to any output. Any output can be open, shorted, or terminated without affecting other outputs. -
Page 11: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping. - Page 12 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
