Asus ROG STRIX B650E-I GAMING WIFI Manual

Hide thumbs Also See for ROG STRIX B650E-I GAMING WIFI:
Table of Contents

Advertisement

Quick Links

ROG STRIX
B650E-I
GAMING
WIFI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROG STRIX B650E-I GAMING WIFI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus ROG STRIX B650E-I GAMING WIFI

Summary of Contents for Asus ROG STRIX B650E-I GAMING WIFI

  • Page 1 ROG STRIX B650E-I GAMING WIFI...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... iv About this guide ......................v ROG STRIX B650E-I GAMING WIFI specifications summary ......... vi Package contents ......................x Installation tools and components ................xi Chapter 1: Product Introduction Before you proceed ................... 1-1 Motherboard layout ..................1-2...

  • Page 4: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 5: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 6: Rog Strix B650E-I Gaming Wifi Specifications Summary

    ROG STRIX B650E-I GAMING WIFI specifications summary AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* * Refer to www.asus.com for CPU support list. AMD B650 Chipset Chipset 2 x DIMM, Max. 64GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC and Non-ECC, Un-...
  • Page 7 ROG STRIX B650E-I GAMING WIFI specifications summary ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording...
  • Page 8 ROG STRIX B650E-I GAMING WIFI specifications summary 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) Internal I/O Connectors 1 x 10-1 pin System Panel header 1 x Thermal Sensor header Extreme Engine Digi+ - 5K Black Metallic Capacitors ASUS Q-Design - M.2 Q-Latch...
  • Page 9 Form Factor 6.7 inch x 6.7 inch (17 cm x 17 cm) • Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications. • MyAsus offers a variety of support features such as helping to troubleshoot issues, optimizing product performance, integrating ASUS software, and recovery drive creation.

  • Page 10: Package Contents

    Package contents Check your motherboard package for the following items. Motherboard 1 x ROG STRIX B650E-I GAMING WIFI motherboard 2 x SATA 6Gb/s cables Cables 1 x ROG USB2.0 splitter cable 1 x Panel cable Additional Cooling Kit 1 x Thermal pad for M.2...

  • Page 11: Installation Tools And Components

    Installation tools and components Phillips (cross) screwdriver PC chassis Power supply unit AMD AM5 CPU AMD AM5 compatible CPU Fan DDR5 DIMM SATA hard disk drive SATA optical disc drive (optional) Graphics card (optional) M.2 SSD module (optional) Screws The tools and components in the table above are not included in the motherboard package.

  • Page 13: Chapter 1: Product Introduction

    • The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector. • For more information on installing your motherboard, please scan the QR code below: ROG STRIX B650E-I GAMING WIFI...

  • Page 14: Motherboard Layout

    Motherboard layout 17.0cm(6.7in) RGB_HEADER DRAM CPU_OV BOOT CPU_FAN CHA_FAN ADD GEN 2 AIO_PUMP ATX_12V DIGI+ SOCKET AM5 U32G2_C1 U32G2_234 U32G2X2_C6 LAN_U32G2_11 M.2(WIFI) Ethernet BIOS_FLBK FLBK_LED FLEXKEY Audio B650 Codec SPDIFO 2280 AAFP Super PCIEX16 M.2_2(SOCKET3) PCIE SATA 4.0 X4 2260 2280 Chapter 1: Product Introduction...
  • Page 15 1-16 15. Clear CMOS header 1-17 16. CPU Over Voltage jumper 1-16 17. Front Panel Audio header 1-18 18. System Panel header 1-19 19. Thermal Sensor header 1-20 20. BIOS FlashBack 1-20 21. Q-LEDs 1-21 ROG STRIX B650E-I GAMING WIFI...
  • Page 16 Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related.
  • Page 17 (Double Data Rate 5) memory modules. A DDR5 memory module is notched differently from a DDR, DDR2, DDR3, or DDR4 module. DO NOT install a DDR, DDR2, DDR3, or DDR4 memory module to the DDR5 slot. Recommended memory configurations ROG STRIX B650E-I GAMING WIFI...
  • Page 18 (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • Visit the ASUS website for the latest QVL, and memory frequency support depends on the CPU types. Chapter 1: Product Introduction...
  • Page 19 Expansion slots Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. PCIEX16 ROG STRIX B650E-I GAMING WIFI...
  • Page 20 Fan and Pump headers The Fan and Pump headers allow you to connect fans or pumps to cool the system. CPU_FAN A B C AIO_PUMP CHA_FAN • DO NOT forget to connect the fan cables to the fan headers. Insufficient air flow inside the system may damage the motherboard components.
  • Page 21 We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. ROG STRIX B650E-I GAMING WIFI...
  • Page 22 M.2 slots The M.2 slots allow you to install M.2 devices such as M.2 SSD modules. M.2_2(SOCKET3) M.2_1(SOCKET3) • AMD Ryzen™ 7000 Series Desktop Processors: - M.2_1 supports PCIE 5.0 x4 mode M Key design and type 2242 / 2260 / 2280 storage devices.
  • Page 23 If you installed SATA storage devices to the SATA6G_1-2 ports, you can create a RAID 0 and 1 configuration through the onboard AMD B650 chipset. Before creating a RAID set, refer to the RAID Configuration Guide. You can download the RAID Configuration Guide from the ASUS website. ROG STRIX B650E-I GAMING WIFI 1-11...
  • Page 24 USB 3.2 Gen 2 Type-C Front Panel connector ® The USB 3.2 Gen 2 Type-C connector allows you to connect a USB 3.2 Gen 2 ® Type-C module for an additional USB 3.2 Gen 2 Type-C port on the front panel. The ®...
  • Page 25 USB_1415 USB_P15+ USB_P14+ USB_P14- USB_P15- USB+5V USB+5V PIN 1 DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. ROG STRIX B650E-I GAMING WIFI 1-13...
  • Page 26 Addressable Gen 2 header The Addressable Gen 2 header allows you to connect individually addressable RGB WS2812B LED strips or WS2812B based LED strips. ADD GEN 2 PIN 1 The Addressable Gen 2 header supports WS2812B addressable RGB LED strips (5V/ Data/Ground), with a maximum power rating of 3A (5V), and the addressable headers on this board can handle a combined maximum of 500 LEDs.
  • Page 27 RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up when the system is powered on. • The LED strip is purchased separately. ROG STRIX B650E-I GAMING WIFI 1-15...
  • Page 28 RTC Battery header This connector is for the lithium CMOS battery. BATT_CON +BAT PIN 1 CPU Over Voltage jumper The CPU Over Voltage jumper allows you to set a higher CPU voltage for a flexible overclocking system (depending on the type of the installed CPU). Set to pins 2-3 to increase the CPU voltage setting, or set to pins 1-2 to use the default CPU voltage setting.
  • Page 29 If the steps above do not help, remove the onboard button cell battery and move the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the button cell battery. ROG STRIX B650E-I GAMING WIFI 1-17...
  • Page 30 Front Panel Audio header The Front Panel Audio header is for a chassis-mounted front panel audio I/O module that supports HD Audio. Connect one end of the front panel audio I/O module cable to this header. AAFP PIN 1 HD-audio-compliant pin definition We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability.
  • Page 31 (depending on the operating system settings). • Reset button header (RESET) The 2-pin header allows you to connect the chassis-mounted reset button. Press the reset button to reboot the system. ROG STRIX B650E-I GAMING WIFI 1-19...
  • Page 32 Thermal Sensor header The Thermal Sensor header allows you to connect a sensor to monitor the temperature of the devices and the critical components inside the motherboard. Connect the thermal sensor and place it on the device or the motherboard’s component to detect its temperature.
  • Page 33 CPU (RED) DRAM (YELLOW) VGA (WHITE) BOOT (YELLOW GREEN) The Q-LEDs provide the most probable cause of an error code as a starting point for troubleshooting. The actual cause may vary from case to case. ROG STRIX B650E-I GAMING WIFI 1-21...
  • Page 34 Chapter 1: Product Introduction 1-22...

  • Page 35: Building Your Pc System

    DO NOT force the CPU into the socket to prevent bending the pins and damaging the CPU. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user.
  • Page 36 Chapter 2: Basic Installation...

  • Page 37: Cooling System Installation

    CPU before you install the cooling system, if necessary. We recommend using AM5 compatible coolers with stock AM5 backplate to prevent potential damages to the pins in the socket. CPU heatsink and fan assembly Type 1 ROG STRIX B650E-I GAMING WIFI...
  • Page 38 CPU heatsink and fan assembly Type 2 When using this type of CPU fan, remove the screws and the retention module only. Do not remove the plate on the bottom. Chapter 2: Basic Installation...
  • Page 39 To install an AIO cooler If you wish to install an AIO cooler, we recommend installing the AIO cooler after installing the motherboard into the chassis. AIO_PUMP CPU_FAN ROG STRIX B650E-I GAMING WIFI...

  • Page 40: Dimm Installation

    2.1.3 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 41: Installation

    Use a Phillips screwdriver when removing or installing the screws or screw stands mentioned in this section. • The M.2 is purchased separately. To install an M.2 to M.2_1 slot Completely loosen the screws on the heatsink. Lift and remove the heatsink. ROG STRIX B650E-I GAMING WIFI...
  • Page 42 Install your M.2 to your M.2 slot. The steps may differ between installing M.2 of different lengths, please refer to the different types and their installation steps below: For 2280 length A. Rotate and adjust the M.2 Q-latch at the 2280 position so that the handle points away from the M.2 slot.
  • Page 43 Follow this step only if you wish to install a single sided M.2 storage device to type 2260. Thermal pad M.2 Q-Latch Thermal pad Bundled rubber for M.2 backplate E. Install your M.2 to the M.2 slot. F. Rotate the M.2 Q-Latch clockwise to secure the M.2 in place. ROG STRIX B650E-I GAMING WIFI...
  • Page 44 Remove the plastic film from the thermal pads on the bottom of the heatsink. If the thermal pad on the M.2 heatsink becomes damaged, we recommend replacing it with the bundled thermal pad or a thermal pad with a thickness of 1.25mm. Replace the heatsink.
  • Page 45 For a 2242 storage device, use the bundled 2242 mounting kit. • Before installing a 2242 M.2 SSD module, ensure that the mounting kit is properly installed with the bigger screw hole on the 2260 standoff. ROG STRIX B650E-I GAMING WIFI 2-11...
  • Page 46 For 2260 and 2280 length The M.2 is purchased separately. Chapter 2: Basic Installation 2-12...

  • Page 47: Motherboard Installation

    I/O panel. Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT over tighten the screws! Doing so can damage the motherboard. ROG STRIX B650E-I GAMING WIFI 2-13...

  • Page 48: Atx Power Connection

    2.1.6 ATX power connection Ensure to connect the 8-pin power plug. 2.1.7 SATA device connection Chapter 2: Basic Installation 2-14...

  • Page 49: Front I/O Connector

    Push the connector until it clicks into place. To install USB 3.2 Gen 1 connector To install USB 2.0 connector USB 2.0 USB 3.2 Gen 1 To install front panel audio connector To install system speaker connector AAFP ROG STRIX B650E-I GAMING WIFI 2-15...

  • Page 50: Expansion Card Installation

    2.1.9 Expansion card installation To install PCIe x16 cards Chapter 2: Basic Installation 2-16...

  • Page 51: Wi-Fi Moving Antenna Installation

    2.1.10 Wi-Fi moving antenna installation Installing the ASUS Wi-Fi moving antenna Connect the bundled ASUS Wi-Fi moving antenna connector to the Wi-Fi ports at the back of the chassis. • Ensure that the ASUS Wi-Fi moving antenna is securely installed to the Wi-Fi ports.

  • Page 52: Bios Update Utility

    • Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service Center. Chapter 2: Basic Installation...
  • Page 53 For more information on using the BIOS FlashBack™ feature, please refer to https://www.asus.com/support/, or by scanning the QR code below. ROG STRIX B650E-I GAMING WIFI 2-19...

  • Page 54: Motherboard Rear And Audio Connections

    Motherboard rear and audio connections 2.3.1 Rear I/O connection Rear panel connectors USB 2.0 ports 5 and 16 USB 3.2 Gen 2 Type-A ports 2, 3, 4 and 11 Intel 2.5Gb Ethernet port* ® LED-illuminated audio jacks** HDMI port ® USB 3.2 Gen 2 Type-C port C1 (supports USB Type-C display outputs)

  • Page 55: Audio I/O Connections

    The rear panel Lime (Line out) port does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis. ROG STRIX B650E-I GAMING WIFI 2-21...
  • Page 56 Connect to 2-channel Speakers Connect to 4-channel Speakers Connect to 5.1-channel Speakers Chapter 2: Basic Installation 2-22...
  • Page 57 Connect to 7.1-channel Speakers ROG STRIX B650E-I GAMING WIFI 2-23...

  • Page 58: Starting Up For The First Time

    Starting up for the first time After making all the connections, replace the system case cover. Ensure that all switches are off. Connect the power cord to the power connector at the back of the system chassis. Connect the power cord to a power outlet that is equipped with a surge protector. Turn on the devices in the following order: Monitor External storage devices (starting with the last device on the chain)

  • Page 59: Chapter 3: Bios And Raid Support

    Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 60: Bios Setup Program

    BIOS setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST).

  • Page 61: Asus Ez Flash 3

    ASUS EZ Flash 3 The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.

  • Page 62: Asus Crashfree Bios 3

    ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file.

  • Page 63: Raid Configurations

    For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support, or by scanning the QR code. RAID definitions Volume provides the ability to link-together storage from one or several disks, regardless of the size of the space on those disks.
  • Page 64 Chapter 3: BIOS Setup...
